Trailed Mowers TM 600/TM700/TM800

Trailed Mowers TM 600/TM700/TM800

Product catalog summary

Introduction
The document introduces the Vermeer Rebel Series Trailed Mowers, highlighting their ease of operation, maintenance, and transport. These mowers are designed to overcome common issues associated with 3-point mowers, such as difficult mounting and excessive weight on tractors.

Key Features

Hydraulic Swing Cylinder: Facilitates maneuvering around obstacles and easy transport.
Low Horsepower Requirement: Offers more transport stability and requires less horsepower than traditional systems.
Quick-Clip™ Blade Retention System: Allows for quick and easy replacement or reversal of cutting blades without tools.
Rubber Torsion Suspension: Absorbs shock loads, allowing the mower to float over obstacles.

Specifications

Models: TM600, TM700, TM800 with varying dimensions and weights.
Dimensions: Transport and working dimensions vary slightly between models, with transport width ranging from 8'3" to 10'9".
Tractor Requirements: Requires 540 rpm drive, 50-60 hp, and specific hydraulic requirements.
Cutterbar: Features include adjustable angles, self-contained units, and heat-treated blades for durability.

Standard Features

Includes side pull rotary disc mower, rubber torsion suspension, hydraulic swing cylinder, and Quick-Clip™ Blade Retention System.
Complies with SAE J232 and ASABE S474 safety standards.

Company Overview
Vermeer Manufacturing Co., based in Pella, Iowa, is a family-owned business founded in 1948. They specialize in agricultural and industrial products, with a focus on hay equipment. The company emphasizes customer support and innovation in product development.

Catalog excerpts

BLADE RETENTION SYSTEM >

Open the catalog to page 1

Just drop in and lock the pin, hook up the PTO and hydraulic hoses and youre ready to go!* Standard hydraulic swing cylinder > for maneuvering around obstacles & easy transport from field to field.* > Standard on all Vermeer Disc-Style Mowers and Mower Conditioners.* Follow all applicable laws regarding the use of lights, slow-moving vehicle sign, safety chain, and other possible requirements for road use. size="-1">

Open the catalog to page 2

Adjustable cutterbar angle 0 to 6Ű Easy as the drop of a pin! > TRACTOR REQUIREMENTS DIMENSIONS TM600 TM700 TM800 Drive: 540 rpm 540 rpm 540 rpmDraw bar Horsepower: 50 hp (37kW) 55 hp (41 kW) 60 hp (45 kW) Hydraulic requirements: 2 sets of work ports 2 sets of work ports 2 sets of work ports (single optional) (single optional) (single optional) Flow rate: 6 gpm (min.) 6 gpm (min) 6 gpm (min) (22.7 L/min) (22.7 L/min) (22.7 L/min) Hydraulic pressure: 1,250-3,000 psi 1,250-3,000 psi 1,250-3,000 psi (86-270 bar) (86-270 bar) (86-270 bar) Side pull rotarydisc mower features hydraulic swing cylinder...

Open the catalog to page 3

WR220 Rake 5410 Rebel Baler Rebel > Vermeer Manufacturing reserves the right to make changes in engineering, design, and specifications, add improvements, or discontinue manufacture at any time without notice or obligation. Equipment shown is for illustrative purposes only and may display optional accessories or components. 2007 Vermeer Manufacturing Co. All rights reserved. VERMEER, VERMEER logo, Rebel and Quick-Clip are trademarks of Vermeer Manufacturing Company in the U.S. and/or other countries. LF 8681 05/07 HG (15K) / PN#510505022 Rebel BP5000 Bale Processor >

Open the catalog to page 4
