EXTERNAL GROOVE TURNING I n n o v a t i v e G r o o v i n g & Tu r n i n g S o l u t i o n s MAIN CATALOG | METRIC INTERNAL GROOVE TURNING GROOVE MILLING

Company Profile VARGUS is a world leading developer, manufacturer and supplier of high-quality, precision threading, grooving, turning and hand deburring tools. Established in 1960, VARGUS is the cutting tools division of the NEUMO Ehrenberg Group, a multinational organization headquartered in Germany. With 13 international subsidiaries, and a network of distributors, warehouses and certified ISO 9001 manufacturing facilities, VARGUS Ltd. serves customers in more than 100 countries around the globe. A customer-focused organization, VARGUS Ltd. is committed to providing products and solutions...

This updated and extended version of the MAIN GROOVEX CATALOG now includes the newest GROOVEX products and expansions, followed by the GROOVEX MAIN CATALOG, Edition 07. Index 2022 PRODUCTS AND EXPANSIONS

2022 NEW PRODUCTS AND EXPANSIONS micrObroach

Dedicated broaching tools for Hexagon and TorX sockets r® Features and Benefits: • Unique VARGUS design • Fits popular driven tools • Sockets range: Hexagon sockets Torx® sockets

Spare Parts Shank Type DCONWS Ordering Code ' BE holders are specially designed for EWS-Slot and BENZ LinA broaching devices

ST-CUT Precise Tools for Small Parts Machining Back Turning and Front Turning Applications Vargus is pleased to introduce the expansion of the Line - front and back turning applications for external machining of small parts on Swiss type machines. FRONT TURNING TURNING BACK BACK TURNING TURNING TURNPARTING OFF FRONT TUR PARTING OFF Features and Benefits: • Outstanding chip control • Unique insert replacement system • Quick and easy change of insert inside the machine from both sides of the tool • High repeatability of the cutting edge on all axes • Excellent rigidity for stable machining • Insert...

Ordering Code | • In stock ° Available upon request | See the complete range of ST-Cut tools in pages: 45 - 62 mmvargus N-9

Back Turning LH Insert Ordering Code | • In stock ° Available upon request | See the complete range of ST-Cut tools in pages: 45 - 62

scopeNew Microscope Chip Breaker for Internal Grooving Applications New chip breaker design offers a unique solution in a wide range of groove widths • Advanced chip control, producing shorter chips • Reduced cutting forces • VTX grade for wide range of materials • Wide range of grooving widths 1.00 mm - 2.00 mm • Superior surface finish • Exceptional chip evacuation • Improved tool life • Excellent for blind holes • Minimum bore diameter - 5.2 mm

Right hand shown | See the complete range of microscope tools in pages: 141 - 181

Right hand shown | See the complete range of microscope tools in pages: 141 - 181

EXTERNAL GROOVE TURNING I n n o v a t i v e G r o o v i n g & Tu r n i n g S o l u t i o n s MAIN CATALOG | METRIC INTERNAL GROOVE TURNING GROOVE MILLING

ssure High Prelant Coo R T OF I TA B I L I EXTERNAL GROOVE TURNING Semi Finishing Complete Range of Turning Solutions Precise Tools for Small Parts Machining Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 8 Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 12 Ordering Code System.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ....

Laydown Grooving For Shallow Grooves

Reinforced Alloy Steel Shank.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 136 Carbide Shank.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 137 Reinforced Carbide Shank.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 138 Carbide Shank for Sleeves.. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 138 V-CAP Holders . . . . . . . . . . . . . . . . . . . . . . . ....

EXTERNAL GROOVE TURNING Semi Finishing

Deep Grooving, Threading, Turning, Parting Off & Face Grooving Applications

Complete Range of Turning Solutions Deep Grooving, Threading, Parting Off, Boring and Face Grooving VG-Cut tools provide a wider range of applications and options within the same insert pocket of Deep Grooving, Parting Off, Turning, Profiling, Boring, Face Grooving and Threading. VG-Cut inserts also offer a variety of chip formers and carbide grades, making the VG-Cut program a distinctly versatile system. VG-Cut inserts are designed with a unique multifunctional and diverse geometry, starting at 1.5mm, to minimize inventory for the end-user. VG-Cut tools cover a wide range of Threading Standards...

Insert, Tool and Cutting Data Selection Guide Identify the Application Identify the Designated Workpiece Material Designated Chip Former Geometry for Selected Applications Designated Carbide Grade for Desired Application Alloy Steel Stainless Steel Material Group Selecting Insert and Tool as Required by Operation Cutting Data According to Selected Items Cast Iron Non Hardened Low Alloy Steel Hardened (alloying elements≤5%) 6 Hardened 7 High Alloy Steel Annealed 8 (alloying elements>5%) Hardened Cast Steel Low Alloy (alloying elements <5%) High Alloy (alloying elements >5%) 11 Stainless Steel...

Material Group Standard Conditions Extreme Conditions P choice for machining alloy and stainless steel. Positive rake chip former leads to low cutting forces during cutting. A multifunctional chip former for parting, grooving and turning. Recommended choice for machining cast iron, for interrupted cuts and for unstable applications where accuracy and overall machining stability are not clear. Reinforced cutting edge for parting off and grooving. Stainless Heat Steel Resistance Grooving Recommended choice for stainless steel. Positive sharp cutting edge decreases buildup on edge for parting off...
