General Catalog
General Catalog
Value Plastics adheres to ISO 9001:2000 standards, integrating quality from the start to exceed customer expectations and support cost-saving dock-to-stock programs.
Advanced equipment and methodologies like finite element analysis and rapid prototyping are used to design fluid management products, focusing on healthcare OEM needs.
All-electric injection molding presses ensure consistency, with process monitoring and controlled environments for molding, secondary operations, and packaging.
Products are manufactured in an ISO 14644-1 Level 8 environment, ensuring production readiness.
Over 3,100 styles and material combinations of plastic connectors for low-pressure fluid management, custom components, and TUBESETTER® fitting inserters are offered.
Located in Fort Collins, Colorado, the facility manages all aspects from design to packaging, supported by global customer service.
Full traceability is maintained, with customer audits invited to ensure compliance with medical device standards.
Innovations include online ordering, new BPF Series fittings, and expanded panel mount fittings. The Design Center offers custom design services.
Partnerships with companies like Promepla and The West Group enhance regional service capabilities.
Detailed technical specifications, performance data, and instructions for product lines are included, emphasizing single barb designs over multi-barb fittings.
Single barb designs create a secure connection by allowing tubing relaxation, whereas multi-barb designs can compromise pressure and tensile capacities.
- 900 Series: For flexible tubing, expands tubing 8-17% above nominal ID, recommended with hose clamps.
- 600 Series: For silicone, C-Flex®, and PVC tubing, expands tubing 18% above nominal ID.
- 500 Series: Features blended radii, accommodates various tube sizes, considers flow restriction and pressure capability.
- 400 Series: Easy assembly, for semi-rigid tubing, expands tubing 15% above nominal ID.
- 300 Series: High-pressure capabilities, expands tubing 15% above nominal ID.
- 200 Series: High-pressure capabilities, expands tubing 50% above nominal ID.
- Classic Series: Longer barb for extended sealing surface, expands tubing 18-69% above nominal ID.
Conform to ISO 594-1 standards, available in over 100 configurations and materials, offering secure connections with features like rotating locks and tapered cone seals.
Materials for luer fittings include nylon, polypropylene, polycarbonate, and Kynar PVDF, each offering different properties for specific applications.
Details on ordering, including minimum order quantities and special order items, with online ordering available for inventoried parts.
- Materials: Connectors available in White Nylon, Natural Nylon, Natural Polypropylene, Clear Polycarbonate, and Natural Kynar PVDF.
- Sizes: Connectors for tubing IDs from 1/16” to 1”.
- Types of Connectors: Includes straight through, elbow, tee, Y connectors, and press-in plugs.
- Online ordering available 24/7 with no minimum order requirements, except in regions served by regional partners.
- Minimum package quantities vary by tube IDs, special order items noted in red text.
- Thread Series: Describes various thread series with specifications for thread length and diameter.
- Consult a sealant specialist for critical seal applications.
- Volume pricing available for quantities of 5,000 and over.
- Contact details for ordering and inquiries provided, including phone, fax, and website for online orders.
Outlines solvent bonding technique, advising a small gap for solvent and rotation to final position after application. For long manifolds, alignment against a flat surface is recommended before solvent sets.
Configuration table lists bondable junction blocks with different axis configurations, indicating male or female, using Polysulfone and Lace White ABS materials.
Details bondable barbs and elbows, specifying series, tubing ID, and materials like Polysulfone and Lace White ABS.
Lists bondable thread types, including 10-32 UNF, 1/4-28 UNF, and NPT threads, with hex sizes and materials.
Covers check valves, clamps, injection sites, stopcocks, spikes, and tubing, with specifications like flow rates, pressure ratings, and materials such as Polycarbonate and ABS.
Describes types of tubing, including PVC, Polyurethane, and Low-Density Polyethylene, with dimensions, durometer ratings, and sterilization methods.
Various kits available, including Assorted, Luer, Tube-to-Tube, and Bondable Kits, each containing components for different applications.
Details on bondable kits and Tubesetter assembly tools, including components like luers, elbows, tees, and junction blocks, available in materials such as White ABS or Polysulfone.
Designed for high-volume requirements, assembling 400 to 500 tubesets per hour, accommodating tubing from 3/32” to 3/8” OD, requiring 120 VAC, 60 Hz, and compressed air at 80 psi.
Suitable for lower-volume manufacturing, does not require electricity or pneumatic power, made of acetal plastic, handling volumes up to 1,000 assemblies per month, accommodating tubing from 3/32” to 3/8” OD.
Includes detailed barb dimensions and performance data, including tensile pull and hydrostatic burst tests, providing comparative performance data for various barb styles and sizes.
Instructions for mounting panel-mounted female luers, with details on threaded and non-threaded panel openings, emphasizing testing products in specific applications for suitability.
Table outlines compatibility of materials (ABS, Acetal, PVDF, Nylon, etc.) with chemicals at specified temperatures, indicating performance as excellent, satisfactory, or unsatisfactory.
Comparative analysis of chemical resistance with different resins, advising testing in specific applications as no warranty or guarantee is provided.
Details physical properties of resins, including tensile strength, elongation at break, tensile yield strength, flexural modulus, hardness, deflection temperature, water absorption, and impact resistance, measured using ASTM test methods.
Lists patents and trademarks associated with Value Plastics, emphasizing the importance of using genuine products to maintain integrity and quality.
Outlines contractual agreement covering acceptance, product ordering, pricing, payment terms, force majeure, delivery terms, inspection and acceptance, title, and limited warranty. Key points include:
- Products sold under specific terms, any variance rejected.
- Orders via phone, mail, fax, or email, shipped in bulk.
- Prices subject to change, exclude taxes.
- Payment terms net 30 days, various methods accepted.
- Not liable for delivery delays beyond control.
- Risk of loss transfers to buyer upon delivery to carrier.
- Products inspected upon delivery, claims for damages within ten days.
- Title remains with Value Plastics until full payment.
- Limited warranty covers defects in materials and workmanship, with specific claims procedures.
Catalog excerpts
Thank you for your interest in our products. If youre a current customer, we thank you for your past support and look forward to exceeding your expectations in the future. If youҒre seeing us for the first time, we welcome the opportunity to earn your trust. At Value Plastics, quality is designed in from the outset; its not an add-on at the end of the process. Our Quality Management System is registered under the auspices of ISO 9001:2000 and passes the most stringent evaluations possible Җ our customers audits. We anticipate your needs and modify our systems to ex- ceed your expectations. Our...
Open the catalog to page 2
The CLASSIC SERIES is characterized by a longer barb that extends the sealing surface of the fitting. Tubing is expanded from 42% to 69% above its nominal ID. > The 200 SERIES offers outstanding performance characteristics when used with flexible tubing. Tubing is expanded by 50% above its nominal ID, permitting high-pressure capabilities. The 300 SERIES offers outstanding performance character-istics when used with flexible tubing. Tubing is expanded by 35% above its nominal ID, permitting high-pressure capabili-ties in the larger tube sizes. SINGLE BARB > MOLD PART LINE: Placed where it cant...
Open the catalog to page 5
DAPTERSPG-14 PUBLISHED ISO DESIGN STANDARD - Well understood worldwide - Often assures interconnections without need to retrofit ROTATING LOCK PERMITS TUBE POSITIONING PRIOR TO TIGHTENING > OUPLERSPG-14 - Minimizes twisting and kinking of tubing TAPERED CONE SEAL - Reliable - Inexpensive - Uncomplicated > EESPG-15 AVAILABLE IN MANY MATERIALS - Facilitates optimal material selection for your application > LBOWSPG-16 INEXPENSIVE - Facilitates single-use EASY TO UNDERSTAND > LUGSPG-16 - Ease of use in field MANY CONFIGURATION OPTIONS - Adaptable to wide range of applications > HREADPG-17 SECURITY...
Open the catalog to page 6
NUMBERMATERIAL Male Luer Integral Lock Ring to 500 Series Barb, 1/16 (1.6 mm) ID Tubing MTLL004-1White NylonMTLL004-2Black NylonMTLL004-3Red NylonMTLL004-4Green NylonMTLL004-5Blue NylonMTLL004-06Orange NylonMTLL004-07Yellow NylonMTLL004-6Natural PolypropyleneMTLL004-9Clear PolycarbonateMTLL004-9002Rad. Stable Polycarbonate Male Luer Integral Lock Ring to 200 Series Barb, 3/32Ԕ (2.4 mm) ID Tubing MTLL220-1White Nylon > LUER MTLL220-2Black Nylon MTLL220-3Red NylonMTLL220-4Green NylonMTLL220-5Blue NylonMTLL220-06Orange NylonMTLL220-07Yellow NylonMTLL220-6Natural PolypropyleneMTLL220-9Clear PolycarbonateMTLL220-9002Rad....
Open the catalog to page 7
NUMBERMATERIAL Male Luer Integral Lock Ring to 400 Series Barb, 1/8 (3.2 mm) ID Tubing MTLL430-1White Nylon MTLL250-1White NylonMTLL250-6Natural Polypropylene > LUER Male Luer Integral Lock Ring to 200 Series Barb, 3/16Ԕ (4.8 mm) ID Tubing MTLL430-3Red Nylon MTLL430-6Natural PolypropyleneMTLL430-9Clear PolycarbonateMTLL430-9002Rad. Stable PolycarbonateMTLL430-J1ANatural Kynar PVDF MTLL250-8003Natural ABS MTLL250-9Clear PolycarbonateMTLL250-9002Rad. Stable PolycarbonateMTLL250-J1ANatural Kynar PVDF > NUMBERMATERIAL Male Luer Integral Lock Ring to 500 Series Barb, 5/32 (4.0 mm) ID Tubing MTLL025-1White...
Open the catalog to page 8
NUMBERMATERIAL Male Luer to 500 Series Barb, 1/16 (1.6 mm) ID Tubing (May be used with separate rotating lock ring; FSLLR) MLRL004-1White NylonMLRL004-6Natural PolypropyleneMLRL004-9Clear Polycarbonate Finger Snap Luer Lock Ring FSLLR-1White Nylon > LUER FSLLR-2Black NylonFSLLR-3Red NylonFSLLR-4Green NylonFSLLR-5Blue Nylon FSLLR-06Orange Nylon FSLLR-07Yellow Nylon FSLLR-6Natural Polypropylene FSLLR-9Clear PolycarbonateFSLLR-9002Rad. Stable Polycarbonate > NUMBERMATERIAL Male Luer to 500 Series Barb, 3/32Ԕ (2.4 mm) ID Tubing MLRL007-1 White Nylon (May be used with separate rotating lock ring;...
Open the catalog to page 9
NUMBERMATERIAL Male Luer to 500 Series Barb, 1/16 (1.6 mm) ID Tubing MLSL004-1White NylonMLSL004-6Natural PolypropyleneMLSL004-9Clear Polycarbonate MTLS210-1White NylonMTLS210-6Natural PolypropyleneMTLS210-9Clear PolycarbonateMTLS210-J1ANatural Kynar PVDF > LUER Male Luer Slip to 200 Series Barb, 1/16Ԕ (1.6 mm) ID Tubing (May be used with separate stationary lock ring; FSLLR) > NUMBERMATERIAL Male Luer Slip to 500 Series Barb, 1/16 (1.6 mm) ID Tubing MSL004-1White NylonMSL004-6Natural PolypropyleneMSL004-9Clear Polycarbonate Male Luer to 500 Series Barb, 3/32Ԕ (2.4 mm) ID Tubing MLSL007-1White...
Open the catalog to page 10
NUMBERMATERIAL Male Luer Slip to 200 Series Barb, 5/32 (4.0 mm) ID Tubing MTLS240-1White NylonMTLS240-6Natural PolypropyleneMTLS240-81Lace White ABSMTLS240-9Clear PolycarbonateMTLS240-J1ANatural Kynar PVDF Female Luer Thread Style to 500 Series Barb, 1/16Ԕ (1.6 mm) ID Tubing FTLL004-1White NylonFTLL004-2Black NylonFTLL004-3Red NylonFTLL004-4Green NylonFTLL004-5Blue NylonFTLL004-06Orange NylonFTLL004-07Yellow NylonFTLL004-6Natural PolypropyleneFTLL004-9Clear PolycarbonateFTLL004-9002 > LUER NUMBERMATERIAL Male Luer Slip to 500 Series Barb, 5/32 (4.0 mm) ID Tubing MSL025-1White NylonMSL025-6Natural...
Open the catalog to page 11
NUMBERMATERIAL FTLL220-1White NylonFTLL220-3Red NylonFTLL220-5Blue NylonFTLL220-6Natural PolypropyleneFTLL220-9Clear PolycarbonateFTLL220-9002Rad. Stable PolycarbonateFTLL220-J1ANatural Kynar PVDF FTLL025-1White NylonFTLL025-2Black NylonFTLL025-3Red Nylon > LUER Female Luer Thread Style to 200 Series Barb, 3/32 (2.4 mm) ID Tubing Female Luer Thread Style to 500 Series Barb, 5/32Ԕ (4.0 mm) ID Tubing FTLL025-4Green Nylon FTLL025-5Blue NylonFTLL025-06Orange Nylon FTLL025-07Yellow Nylon FTLL025-6Natural PolypropyleneFTLL025-9Clear PolycarbonateFTLL025-9002Rad. Stable PolycarbonateFTLL025-F1AMed....
Open the catalog to page 12
NUMBERMATERIAL Female Luer Thread Style to 200 Series Barb, 3/16 (4.8 mm) ID Tubing FTLL250-1White Nylon Female Luer Thread Style Smooth Bore to 500 Series Barb, 1/16Ԕ (1.6 mm) ID Tubing FTLLSB004-1White NylonFTLLSB004-6Natural PolypropyleneFTLLSB004-9Clear Polycarbonate > LUER FTLL250-3Red NylonFTLL250-5Blue Nylon FTLL250-6Natural PolypropyleneFTLL250-9Clear PolycarbonateFTLL250-9002Rad. Stable Polycarbonate FTLL250-J1ANatural Kynar PVDF > NUMBERMATERIAL Female Luer Thread Style Smooth Bore to 500 Series Barb, 3/32 (2.4 mm) ID Tubing FTLLSB007-1White NylonFTLLSB007-6 Female Luer Thread Style...
