ADCA HIGH PURITY BALL VALVES M3HP TRUE BORE (6") DESCRIPTION The ADCAPure M3HP three piece body ball valves are isolating valves designed for use with clean steam, condensate and other gases and liquids used in high purity and aseptic processes. The valve is not designed as a control valve and should only be used as an isolating valve, fully open or fully closed. The product is mainly designed for the pharmaceutical, biotech, semiconductor, cosmetics, fine chemical and food & beverage industries. MAIN FEATURES True bore floating ball design. Completely made from solid bar stock material. Can be serviced without removal the from the pipeline. Bidirectional. Antistatic device. Anti blow out proof stem. Tube weld with loose body flanges (360º rotation after installation). ISO 5211 mounting. STANDARD SURFACE FINISH Internal wetted parts: ≤ 0,51 µm Ra – SF1. External : ≤ 0,76 µm Ra – SF3. Other surface conditions see TIS.GIA – General information ADCAPure. Ultrasonic cleaning. OPTIONS: Degreased for oxygen use. Cavity fillers. Gearboxes. For more options and extras, please consult IS M3H.100 – Sanitary Ball Valves Additional Options and Extras. Clean steam, gases and liquids compatible with the construction. AVAILABLE MODELS: M3HP – Complete bar stock construction. ASME BPE clamp ferrules, tube weld (ETO) ends or a combination of both. Others on request. Assembling and packaging in a clean room certified according to ISO 14644-1. The product is end capped and sealed with recyclable thermo-shrinkable plastic film, to avoid contamination. VALSTEAM ADCA CE MARKING – GROUP 2 (PED – European Directive) PN16 We reserve the right to change the design and material of this product without notice

Open the catalog to page 1

ADCA PRESSURE / TEMPERATURE LIMITS 1/2" to 1" DN 10 to 20 Tube weld easy and quick installation Remark: Maximum operating conditions may be limited by the valve end connections due to normative restrictions. Valves with tube weld (ETO) connections are fitted, as standard, with loose body flanges which allow installation with no need to align the end connections. After installation the valve can rotate freely 360º to the desired orientation. BALL PORT VALSTEAM ADCA We reserve the right to change the design and material of this product without notice.

Open the catalog to page 2

Valve body Seal retainer Clamp ferrules end connection Tube weld end connection * Valve ball * Standard seat * Cavity filler seat Body ring * Body seal * Retainer seal * Stem seals * Stem thrust seal Handle body Spring washer Lock washer Body fixing bolts Handle stopper Handle fixing bolt Antistatic device * Available spare parts. Remarks: FDA / USP Class VI seals certificate on request. All valves have a serial number. In case of non-standard valves, this number must be supplied if spare parts are ordered. VALSTEAM ADCA We reserve the right to change the design and material of this product...

Open the catalog to page 3

ADCA ORDERING CODES M3HP Valve model M3HP 3 pieces ball valve - AISI 316L Lever handle Round lever with complete stainless steel construction Bare stem AISI 316L / 1.4404 Seat design Standard seats Cavity fillers Seat material Standard surface finish Mirror mechanical polished external surfaces (SF1) Electropolished internal wetted parts (SF5) Degreased for oxygen Pipe connection TC – Sanitary clamps ASME BPE ETO – Extended tube orbital welding ASME BPE TC / ETO – Combination ASME BPE Ball port True bore Size 6" Special construction / Additional options Full description or additional codes...

Open the catalog to page 4
