SPECIALTY FOLDER GLUERS
16Pages

{{requestButtons}}

Catalog excerpts

SPECIALTY FOLDER GLUERS - 1

Total Solutions Provider of Gluing & Inspection Systems for SPECIALTY FOLDER GLUERS Adhesive Dispensing & Quality Assurance Systems

Open the catalog to page 1
SPECIALTY FOLDER GLUERS - 2

Shelf-ready packaging is the key. Specialty gluers are called on as a solution to make the product stand out. Clever box design, high-quality printing, and precision die-cutting are all key elements. The ability to produce various styles and sizes of boxes further enhance a box maker’s success. Valco Melton gluing systems for specialty gluers are versatile, capable of contact or non-contact gluing, at high or low pressures, ribbons or bead patterns, with cold glue or hot melt adhesives. In many cases a combination of components are used together, successfully producing the most complex...

Open the catalog to page 2
SPECIALTY FOLDER GLUERS - 3

Valco Melton MCP-4J • 4-Valves, 4-Scanners • Auto-configuring voltage 90-240VAC • Internal/External Pressure Control • Job Storage (100) • Inch/Metric • LED display plus push-button overlay • Auto-Glue mode • OEM Communication • Pulse-Purge • Jam Preventer (4 or 8 Channel) • Stitched patterns - jog on restart • Data sharing with CartonChek 7 • USB port for system backups and software updates. • Batch Count • Scanner Lockout • Vertical or Horizontal Mounting MCP-8 • 8-Valves, 8-Scanners • Jam Preventer (4 or 8 Channel) • Auto-configuring voltage 90-240VAC • Internal/External Pressure Control...

Open the catalog to page 3
SPECIALTY FOLDER GLUERS - 4

VCX/DT-12D Up to 16 channels in modules of 4 in any combination of sensors and valves Jam Preventer (up to 16 channels) Auto-configuring voltage 90-240VAC Internal Pressure Control (up to 4) External Pressure Control (up to 4) Easily recognized icon-based access to gluing inspection Job Storage (1000) Batch, supports tracking and all forms of ejection • Inch/Metric • 12” Remote-mount Color touch-screen • Data sharing with CartonChek 7 • OEM Communication • Auto-Glue mode • Pulse-Purge • Stitched patterns - jog on restart • Scanner Lockout • Quality data collection and reporting •...

Open the catalog to page 4
SPECIALTY FOLDER GLUERS - 5

GLUE STATION & VALVES 524 VALVE • Adjustable flow rate for precision high-speed patterns • Integrated purge/test switch • Capable of high pressure operation (up to 500 psi) • Compatible with a range of adhesive viscosities (up to 4000cps) • Ceramic on ceramic ball and seat 524 EXTENDED NOZZLE BODY VALVE • Adjustable flow rate for precision high-speed patterns • Integrated purge/test switch • Capable of high pressure operation (up to 500 psi) • Compatible with a range of adhesive viscosities (up to 4000cps) • Extended nozzle body permits positioning close to machine rails for installation...

Open the catalog to page 5
SPECIALTY FOLDER GLUERS - 6

The Valco Melton 540 Valve for single and multi-orifice nozzles can convert quickly from non-contact to contact. A variety of available contact applicator heads apply pattern widths up to 3 inches, come with a built-in purge switch, and are available in a rear-adjust version. This valve has a high flow rate and dispenses viscosities up to 4,500 mPas. Suitable for high speed patterns, dotting, and dispensing high glue pressures up to 500 psi (35 bar), the Valco® 540 Series Valve is the ideal solution for replacing pneumatic technology on specialty gluers. • High cycle rate offers superior...

Open the catalog to page 6
SPECIALTY FOLDER GLUERS - 7

NOZZLES & APPLICATORS Single orifice, multi-orifice, contact and non-contact design. Valco Melton can provide an applicator/nozzle to meet nearly any carton design and style. Offered in stainless-steel and hardened tool-steel (for contact applications) the nozzles are designed to run clog-free and offer long service life. They are chemical resistant and can easily be cleaned for use with different types of adhesives. Orifice diameter and spacing can be selected according to the pattern required coupled with the viscosity of the adhesive. As standard they are available for pattern...

Open the catalog to page 7
SPECIALTY FOLDER GLUERS - 8

1:1, 3:i, 6:i balancing regulator • Pressure balancing regulator - relieves excessive pressure that occurs during high speed stops • Ultra-precise and fast pressure control • No shaft seals • Easy rebuild • No pattern flooding at restart • Rolling diaphragm design for frictionless movement and no losses dd-1 • Trusted reliability of a 1:1 diaphragm pump • Electronic shifting • High flow rate • Suction from totes, drums, and pails • 1/2 NPT and 1/2 BSPP inlet/outlet fittings • 24VAC source from Valco Melton controls or optional transformer • Wall mount, pail mount, or drum mount EPP-9 • High...

Open the catalog to page 8
SPECIALTY FOLDER GLUERS - 9

MXM SERIES VALVES, SIDE-FEED OR TOP-FEED Valco Melton’s MXM electric hot melt valve is the workhorse for most Valco Melton hot melt dispensing solutions. The MXM electric valve can operate at extremely high speeds reaching 15,000 cycles per minute for short bursts and are capable of more than 2 billion cycles before requiring service. Combine the speed of hot melt with the strength of cold glue. • Cost-effective solution • Maximize production • Clean application • Fast system payback • Side feed or top feed assembly ME VALVE Valco Melton’s ME Double Effect Dispensing Gun Series introduces...

Open the catalog to page 9
SPECIALTY FOLDER GLUERS - 10

GEAR PUMP OR PISTON PUMP MELT UNITS Valco Melton’s D4, D10, and D16 Series Units are ideal for high speed folding carton applications. All D Series units feature an LED display, spur gear pump with fixed or variable speed, “ key-to-line” control, and a D SERIES GEAR PUMP UNITS 4, 10, 16 KG TANKS multi-functional control system. Other options include an integrated glue pattern control, line speed pressure control and integrated auto-feed systems. • Achieve uniform output pressure to match line speed with built-in pressure run-up control • Easy-to-connect HMI communication through the melter...

Open the catalog to page 10
SPECIALTY FOLDER GLUERS - 11

Decrease your material cost by 40% or more Streamline production and improve the quality of your deferred-use packaging products using Valco Melton’s SealTak® System. Compared to double-sided pressure sensitive pressure-sensitive adhesive and a release liner. Get these immediate benefits • Increase production and reduce downtime by eliminating the need for excessive tape roll changes • Reduce material costs–the cost of buying bulk adhesive and bulk silicone paper is far less than transfer tape • Produce a stronger bond by evenly depositing adhesive onto the substrate Deferred-Use Packaging...

Open the catalog to page 11
