Shuttle Charging System

Product catalog summary

Overview
The document describes the SLS Shuttle Charging System by Paul Vahle GmbH & Co. KG, highlighting its compact, safe, and efficient design tailored for shuttle systems.

Specifications

Compact dimensions: 15 mm x 34 mm.
Designed for integration into shuttle-system profiles.
Modular assembly allows for adjustments in conductor length.
Supports high impact speeds for enhanced system efficiency.
Constructed from special materials to ensure low wear.
Reversible for charging in aisle positions.
Power rating up to 104 A, suitable for 24/48 V systems.
Customizable connections with multiple attachment options.

System Features

Scalable system lengths to accommodate various shuttle operations.
Highly dynamic and flexible to handle numerous load operations swiftly.
Compact design allows integration into shuttle tracks, with the charging contact being very small.
Durable ramp elements for high durability and high impact velocity from both sides.
Can be installed anywhere on the rack or staging area.
Contact area extendable with conductor systems up to 4 meters for charging while moving.

Installation and Durability

Features fully integrated feed-in technology.
Equipped with a compact, durable carbon brush with plug-in or screw connection.
Designed for easy and quick installation.

Catalog excerpts

SHUTTLE CHARGING SYSTEM QUICK | SAFE | COMPACT • Compact design (15 mm x 34 mm) • Ideal for installation in shuttle-system profile • Modular assembly in case of change in length of the conductors • High impact speed for optimized system efficiency • Special material characteristics to guarantee low wear • Reversable for charging positions also in aisles • Power rating up to 104 A available • Perfect for 24/48 V charging system applications • Customized connection possibilities by multiple attachment positions Paul Vahle GmbH & Co. KG | Westicker Str. 52 | 59174 Kamen | Deutschland Tel.: +49 2307 704-0 | Fax: +49 2307 704-444 | [email protected] | www.vahle.de

Open the catalog to page 1

SLS fully integrated feed-in technology easy and quick installation compact, duable carbon brush with plug-in or screw connection Shuttle systems are extremely dynamic and flexible. They can easily handle and cope with a very high number of different load operations in a very short time. The unique nature of shuttle systems requires a charging solution that is extremely dynamic and flexible. VAHLE offers the SLS shuttle charging system to cope with the high demands of today’s hi-tech battery powered shuttle systems. Due to its very compact design, it can be space s aving integrated into the track...

Open the catalog to page 2
