Overview: This document provides comprehensive information on fittings used in pneumatic circuits, focusing on push-in fittings made from technopolymer and nickel-plated brass. It includes technical specifications, assembly instructions, and a detailed index of fitting types and sizes.

Technical Specifications:

Body Material: Technopolymer
Fixing Element: Nickel-plated brass with NBR O-ring or Teflon coating
Clamping Collet: Stainless steel
Release Ring: Technopolymer
Applications: Pneumatic circuits
Recommended Hoses: Rilsan/Elastollan
Max Pressure: 15 bar
Working Pressure: -0.99 to 10 bar
Temperature Range: -20°C to 60°C

Assembly Instructions:

Cut the tube square with no burrs or ovalization.
Insert the tube fully into the fitting.
To release, press the release ring and pull the tube out.

Fitting Types and Sizes: The document lists various fittings such as straight, elbow, tee, and Y connectors, each identified by unique codes and available in multiple sizes.

Key Fitting Types:

Straight Fittings: Available in taper and parallel male versions.
Swivel Elbows: Offered in extended, male, and female versions.
Tee and Y Connectors: Available in central and lateral configurations.
Specialty Fittings: Includes reducing stems, plugs, and multi-branch tees.

Additional Technical Specifications: The document also covers fittings made from nickel-plated brass and aluminum, suitable for pneumatic, oleodynamic, and low-pressure hydraulic circuits, with a maximum pressure of 50 bar.

Product Listings: Includes reducing bushes, nipples, sockets, and plugs with specifications like thread sizes and product codes.

Materials and Applications: Fittings are made from nickel-plated brass and aluminum, with polyamide PA12 and polyurethane C98 tubes available for various applications.

Additional Components: Information on tee connectors, elbow connectors, cross adaptors, and Y connectors is provided.

Technical Notes: Includes bending radius specifications for calibrated tubes.

Specifications: Details on spiral tubes made from polyamide PA11 and polyurethane 1190, available in various colors and diameters.

Product Variants: Polyamide PA11 and polyurethane 1190 tubes are available in different colors and sizes.

Technical Data: Tables list product codes, diameters, useful lengths, and tube end lengths.

Distributor Information: Contact details for UNIVER distributors and service centers in various countries are provided.

Notes: LU refers to the useful length of the tube, and LT refers to the length of the tube ends.

Disclaimer: UNIVER reserves the right to modify technical characteristics without prior notice.
