PD Series

Product catalog summary

Overview: This document provides detailed specifications and features of the EPA Tier-4 Diesel Engine-Powered Forklifts with capacities ranging from 4,000 to 7,000 lbs. It includes information on standard warranties, dimensions, performance, weight, chassis, wheels, and drive line specifications.

Specifications:

Model Designation: PFD40M, PFD50M, PFD60M, PFD70M
Rated Load Capacity: 4,000 lbs (1,800 kg) to 7,000 lbs (3,175 kg)
Power Type: Diesel
Operator Orientation: Sit Down

Dimensions:

Tire Type: Pneumatic
Maximum Fork Height: 131.5 inches (3340 mm)
Overall Length: 98.0 inches (2490 mm) to 107.0 inches (2720 mm)
Width: 45.3 inches (1150 mm) to 67.5 inches (1715 mm)

Performance:

Maximum Travel Speed: 11.2 mph (18 km/h)
Lift Speed: 120 fpm (609 mm/sec) to 126 fpm (640 mm/sec)
Gradeability: Up to 42% full load

Weight:

Standard Truck Weight: 7,610 lbs (3,450 kg) to 9,640 lbs (4,373 kg)

Chassis & Wheels:

Tire Size: Front 7.00-12-12PR, Rear 6.00-9-12PR
Wheelbase: 63 inches (1600 mm) to 66.9 inches (1700 mm)

Drive Line:

Engine Model: 4EG
Rated Output: 48.0 hp (36.0 kW) @ 2250 rpm
Transmission Type: Powershift

Brand Reliability: UniCarriers emphasizes the reliability and strong performance of their forklifts, highlighting their long-standing history and commitment to quality.

Catalog excerpts

Engine-Powered Forklifts EPA Tier-4 Diesel 4,000 / 5,000 / 6,000 / 7,000 Capacities

Open the catalog to page 1

MAIN TRUCK SPECIFICATIONS Foot Operated, Hydraulic Hand, Mechanical Full Hydraulic

Open the catalog to page 2

It’s the defining trait of our brand and our forklifts. UniCarriers’ roots extend back over 100 years, and over that time, strong, reliable performance has always been the hallmark of our people and our equipment. Today, our unrivaled reliability continues to provide UniCarriers’ customers with a competitive edge. And together, we move the merchandise that moves world commerce with greater efficiency, economy and reliability. Which brand do you trust? The one you never have to think about. © 2026 Logisnext Americas Inc. UniCarriers· is a registered trademark of Logisnext Co., ltd. Logisnext Americas,...

Open the catalog to page 3
