APLINK HRX - Direct Printing

Product catalog summary

Overview: The APLINK HRX Series by United Barcode Systems represents a new generation of high-resolution GrayScale inkjet printers designed for enhanced coding performance on both porous and non-porous surfaces. Key features include multichannel vertical resolution management, high horizontal resolution up to 1440dpi, and innovative design for flexible printhead positioning.

Specifications:

Printing Height: Up to 72 mm (2.83 inches)
Printing Speed: Up to 250 m/min
Resolution: GS10: 90dpi to 360dpi (vertical), up to 1440dpi (horizontal); GS05: 90dpi to 180dpi (vertical), up to 1440dpi (horizontal)
Message Length: Maximum 8 meters
Barcodes Supported: GS1 (GTIN13, GTIN14, GS1-128, GS1 Datamatrix, etc.)
Data Types: Texts, variables, formulas, logos, images, dates, etc.
Printhead Position: Side, top, or tilt from 0º to 90º (Flex Integration System)

Features:

Display Options: 7” color touchscreen or optional 10” color touchscreen
Printhead Control: HMI 7” for 1 printhead, HMI 10” for up to 4 printheads (2+2)
Communication: USB 2.0, Ethernet, I/O (12)
Message Design Software: UBS Designer Lite, UBS Designer Pro, NiceLabel, Codesoft, Windows Driver

Innovative Design: The printer head can rotate on its three axes to print in side, top, or tilt positions, enhancing flexibility and ease of use. The controller can be detached and placed anywhere on the production line for convenience.

Advanced Features: The HR Link Communication Protocol allows for comprehensive control of printer parameters. The system supports peripheral connections such as encoders, beacons, and UV LED curing lamps. The printer self-configures based on the ink inserted to prevent errors and ensure optimal print quality.

Additional Options: UV LED Curing System, external beacon, encoder.

Certifications: Equipment and ink certifications for labeling, coding, and marking.

Catalog excerpts

APLINK HRX SERIES HIGH RESOLUTION INKJET

Open the catalog to page 1

GRAYSCALE PRINTING HMI DISPLAY 7” or 10” For a greater comfort, it is possible to remove the controller from the printer’s body and place it anywhere on the production line. Take coding to the next level with GrayScale printing. Up to 3 levels HR LINK COMMUNICATION Control any parameter of the printer thanks to HR Link Communication Protocol, manageable through the user interface. RESOLUTION Multichannel vertical resolution management and up to 1440dpi of horizontal resolution for a higher contrast. PERIPHERAL CONNEXIONS Connect encoders, beacons or UV LED curing lamps; link printers or communicate...

Open the catalog to page 2

CODING TAKEN TO THE NEXT LEVEL APLINK HRX Series is United Barcode Systems’ new generation of high-resolution GrayScale inkjet printers designed to improve coding performance on porous and non-porous surfaces. PRINTER FEATURES PRINTING HIGHT PRINTING SPEED RESOLUTION (VERTICAL / HORIZONTAL) GS10: from 90dpi to 360 dpi (vertical), up to 1440dpi (horizontal) GS05: from 90dpi to 180dpi (vertical), up to 1440dpi (horizontal) MESSAGE LENGTH Texts, variables, formulas, logos, images, dates, etc. PRINTHEAD POSITION Side, top or tilt from 0º to 90º (Flex Integration System) UV LED Curing System, external...

Open the catalog to page 3
