Bearing Roller Conveyor Chain Features ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ 03 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ Application Examples ・・・・・・・・・・・・・・・・・・・・・・・・ 05 ・・・・・・・・・・・・・・・・・・・・・・・・ Sample Customizations ・・・・・・・・・・・・・・・・・・・・・・・ 06 ・・・・・・・・・・・・・・・・・・・・・・・・ Standard Series ・・・・・・・・・・・・・・・・・・・・・・・・・・ 07 ・・・・・・・・・・・・・・・・・・・・・・・・・・・ Anti-Dust Series ・・・・・・・・・・・・・・・・・・・・・・・・・・ 09 ・・・・・・・・・・・・・・・・・・・・・・・・・・・ Lube-Free Series (Standard Specs) ・・・・・・・・・・・・・・

Chain running resistance reduced by Cylindrical bearings Reduces Chain Running Resistance Minimizes poor roller rotation and decreases rail wear Cylindrical bearings ensure smooth roller rotation and reduce rail wear. Roller wear life is also dramatically increased. Reduces motor capacity Smaller motor means 2.5 30% Less power consumed means cost savings Reduces chain replacement labor by When Replacing Existing Chain Standard RF Conveyor Chain Bearing Roller Conveyor Chain Standard RF Conveyor Chain Chain load Chain load RF26250F Same size RF26250BF (When lubed) of fricton chain load Can...

Bearing Roller Conveyor Chain has a line-up of s to suit your needs.Longer Wear LifeOver 3X the wear life Note: Water resistant series has twice the wear life of RF Series Chain load and required drive are only 1/3 of standard conveyor chains. This allows users to choose a smaller size chain, as well as reduce the size of their conveyor and necessary drive power, for greater cost savings. Stable Conveyance Better productivity Prevents stick-slip phenomenon at low speeds Preventing stick-slip and providing smooth movement ensures stable conveyance and eliminates motion sickness on assembly lines for...

Application Examples Standard Series Completed vehicle conveyance Lube-Free Series Web roll conveyance Anti-Dust Series Casting conveyance (in contact with molding sand) Coating line pallet conveyance Anti-Dust Series Water Resistant Lube-Free Specs Waste conveyance (scrap iron, rocks, etc.) Lube-Free Series Shower tester

Bearing Roller Conveyor Chain Sample Customizations Bearing Outboard Rollers Easy roller replacement With Grease Nipples Easy lubrication Grease nipples Same size as S Rollers on Standard Series Heat Resistant Special spacer Deep Link With Ribbed Attachments Attachments with Nuts Reduces load during accumulation Higher attachment allowable load Allows direct conveyance, even with BR rollers Easy attachment

Standard Series Standard Series Bearing Roller Conveyor Chain features a unique construction of cylindrical bearings between rollers and bushes. (Patented) These rollers have the same dimensions as R and F Rollers on standard RF Conveyor Chain. Construction Roller Cross Sectional View Roller Cylindical bearing Bush Features In-house test comparison, no additional lubrication 5 Bush–Roller Wear Life Standard Series Bearing Roller Conveyor Chain 5x the wear life of DT Series and 3x the wear life of AT Series, without additional lubrication. Running Time Chain Numbering Example RF03075 BR - DT -...

Chain Size Note: 1. Contact a Tsubaki representative for imperial sizes. 2. The above dimensions are nominal dimensions and may differ from actual dimensions. Note: 1. Contact a Tsubaki representative for imperial sizes. 2. The above dimensions are nominal dimensions and may differ from actual dimensions.

Anti-Dust Series Anti-Dust Series Bearing Roller Conveyor Chain uses a labyrinth construction and seal to make it harder for dust and debris to infiltrate compared to our Standard Series. (Patented) These rollers have the same dimensions as R and F Rollers on standard RF Conveyor Chain. Construction Roller Cross Sectional View Seal board Spacer Steel Side board Roller Cylindical bearing Bush Features In-house test comparison, no additional lubrication 3 Bush–Roller Wear Life Bearing Roller Conveyor Chain (Standard Spcs.) Anti-dust series Bearing Roller Conveyor Chain 3x the wear life of bearing...

Chain Size Note: 1. Chain cannot be used for conveyance in environments where it will be fully covered in dust. 2. Periodically lubricate the base chain using the grease nipple on the pin head. 3. Base chain is compatible with General Use Conveyor Chains and can use current sprockets. 4. Do not use in corrosive environments. (Exposed to or submersed in water, etc.) 5. The above dimensions are nominal dimensions and may differ from actual dimensions. Note: 1. Chain cannot be used for conveyance in environments where it will be fully covered in dust. 2. Periodically lubricate the base chain using...

Lube-Free Series (Standard Specs) Lube-Free Series Bearing Roller Conveyor Chain uses special cylindrical bearings with self-lubricating functions between the bushes and rollers. The rollers can be used without additional lubrication. (Patented) These rollers have the same dimensions as R and F Rollers on standard RF Conveyor Chain. Construction Roller Cross Sectional View Plastic bearing Spacer A Roller Steel bearing Bush Features In-house test comparison, no additional lubrication Bush–Roller Wear Life 5 AT Series Conveyor Chain Standard Series Bearing Roller Conveyor Chain Lube-Free Bearing...

Chain Size Note: 1. Contact a Tsubaki representative for imperial sizes. 2. The above dimensions are nominal dimensions and may differ from actual dimensions.

Lube-Free Series (Completely Lube-Free Specs) Completely Lube-Free Bearing Roller Conveyor Chain uses special cylindrical bearings with self-lubricating functions between the bushes and rollers, and further includes a solid lubricant to eliminate the need for additional lubrication. Construction Roller Cross Sectional View Outer plate Plastic bearing Seal Inner plate Spacer A Roller Steel bearing Bush Solid lubricant Features In-house test comparison, no additional lubrication Lube-Free Bearing Roller Conveyor Chain (std.) Lube-Free Bearing Roller Conveyor Chain (completely lube-free specs) Running...

Note: 1. This chain is interchangeable with standard large size conveyor chain and can use the existing sprocket. However, the L1 + L2 dimension is different. 2. The above dimensions are nominal dimensions and may differ from actual dimensions.
