Filter Media

Product catalog summary

Product Range Overview
The document provides an overview of TROX GmbH's filter media products, categorized by filter class according to EN 779 and EN 1822 standards. Products include roll filter media, filter mats, panel filters, bag filter inserts, compact fine dust filters, and minipleat filter inserts.

Filter Specifications
Specifications for each filter type include average arrestance against synthetic dust, average efficiency against atmospheric dust, nominal face velocity, initial pressure differential, and temperature resistance. For instance, G3 filters have an average arrestance of 86% and can resist temperatures up to +100°C.

Filter Types and Applications

Roll Filter Media: Used for coarse and fine dust filtration in ventilation and air conditioning systems, available in various sizes and materials.
Z-Line Filters: Suitable for pre- or main filtration in air conditioning systems, known for high dust holding capacity and long service life.
Bag Filter Inserts: Available in chemical and glass fiber variants, used for fine dust extraction with various efficiency grades.
Compact Fine Dust Filters: Designed for high-efficiency applications such as gas turbines and industrial systems.
Minipleat Filter Inserts: Used in systems requiring high volume flows and extended filter life.

Technical Data and Ordering Information
Includes technical data for each filter type, such as dimensions, pressure differentials, and efficiency ratings, along with ordering information for standard and special sizes.

Key Features and Benefits
Features include high dust holding capacity, low pressure differential increase, long service life, easy maintenance, compatibility with standard and non-standard frames, and environmentally friendly disposal options.

Conclusion
The document serves as a guide for selecting appropriate filter media for various air conditioning and ventilation applications, emphasizing efficiency, durability, and adaptability.

Circular Minipleat Filters
Designed to remove suspended particles, these compact, cylindrical filters are made with high-grade glass fibre paper and are available in two standard sizes, with additional sizes upon request.

Minipleat Filter Cells
These filters serve as pre-filters or high-performance filters for fine dust and suspended particles, available in filter classes F6 to F9 (EN 779) and H11 to H13 (EN 1822).

Minipleat Filter Panels
Used for extracting fine dust and suspended particles, available in filter classes F7 and F9 (EN 779) and H11 and H13 (EN 1822).

Minipleat Filter Panels for Clean Room Technology
These panels meet high standards of air purity and are used in clean rooms, available in filter classes H14 to U16 (EN 1822).

Particulate Filter Cells
High-efficiency filters for separating sub-micron particles, available in filter classes H11 to H14 (EN 1822).

Activated Carbon Filter Cartridges
Remove gaseous air pollution, suitable for retrofitting in air-conditioning systems, available in two lengths.

Activated Carbon Filters
Used in ventilation systems to adsorb odours and toxic substances, with operational limits of 40°C temperature and 70% relative humidity.

Catalog excerpts

Filter MediaF721Trox-o-filF702 Filter mediaTrox-o-fil F702 Filter grade to EN 779 > 1) G3863.180up to +100 G3862.580up to +100 Filter grade to EN 779 > 1) G3862.560up to +100 Average Arrestanceagainst synthetic dustin %Nominal facevelocity in m/sInitial pressuredifferential at nominalflow velocity in PaTemperature resistance in װC Average Arrestanceagainst synthetic dustin %Nominal facevelocityin m/sInitial pressuredifferential at nominalflow velocity in PaTemperature resistance in C > 1) EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. > 1) EN...

Open the catalog to page 3

Filter MediaF703F704F711 Filter MediaF706 > 1) Filter grade to EN 779 > 1) G3G3G4Average Arrestanceagainst synthetic dustin %828690Nominal facevelocityin m/s1.51.51.5Initial pressuredifferential at nominal flow velocityin Pa304050Temperature resistance in Cup to + 100 Filter grade to EN 779 F5Average Arrestanceagainst synthetic dustin %96Average efficiencyagainst atmospheric dust in %47Nominal facevelocityin m/s0.9Initial pressuredifferential at nominal flow velocityin Pa90Temperature resistance in ںCup to +100 > 1) EN 779: particle air filters for general room air-conditioning technology. See...

Open the catalog to page 4

Z-line filterF718F719 Filter class to EN 779 > 1) G4F5Average efficiencyagainst synthetic dustapprox. in %91> 98Average efficiencyagainst atmospheric dustapprox. in %3045Initial pressure differentialat nominal volume flowin Pa7090Temperature resistancein ֺCup to + 80up to + 80Maximum relative humidityin %100100 > 1) EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. >

Open the catalog to page 5

Bag Filter InsertF742 F743 F745 F726 F728 F729 Filter grade to EN 779 > 1) G49036035/50 F59665070/100 F6>9860045/60 F7>9860055/75 F8>9860090/115 Average Arrestanceagainst synthetic dustapprox. in %Bag filter length in mm Initial pressure differentialat nominal volume flow > 2) in PaTemperature resistance in ְC G38236025/35up to + 90up to + 70 > 1) EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. > 2) For nominal volume flow for filter size concerned, see leaflet F7/2.1/EN/. >

Open the catalog to page 6

Bag Filter InsertF744 F746 F748 F749 Filter grade to EN 779 > 1) F6>9865 F7>9885 F8 F9>9895 Average Arrestanceagainst syntheticdustapprox. in %Average efficiencyagainst atmosphericdust approx. in %Bag filter length in mm Initial pressure differentialat nominal volume flow 60050/7070050/70 60080/11070080/110 600100/13070080/110 600140/190700120/160up to +90 > 2) in PaTemperature resistance in ְC F598 55 > 1) EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. > 2) For nominal volume flow for filter size concerned, see leaflet F7/2/EN/. >

Open the catalog to page 7

Compact Fine Dust FiltersF736 > 1) F739 > 1) F736 F737 F739 for gas turbinesfor ventilation and AC systems Filter class to EN 779 > 2) F995180/220 F66585 F785110 F995130up to + 120100up to + 120100 Average efficiencyagainst atmosphericdust in %Initial pressure differenceat nominal volume flow > 3) in PaTemperature resistance in CMax. relative humidityin %F665130/170 > 1) 2) Fine dust compact filter with double-layer micro-glass fibre paper. EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. > 3) Nominal volume flows for each filter size are given...

Open the catalog to page 8

Minipleat Filter CellsF756 F757 F759F780F781 Filter class to EN 779 > 1) F6F7F9֖Filter class to EN 1822 > 2) ֖֖H11H13Average efficiencyagainst atmospheric dust in %658595֖Extraction efficiencyto EN 1822in %֖>95>99.95Initial pressure differentialat nominal volume flow > 3) in Pa120140180125250Temperature resistance in ְCup to +80 > 1) EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. > 2) 3) EN 1822: Particulate Filter (HEPA and ULPA)Ӕ. For nominal volume flow for filter size concerned, see leaflet F7/4.3/EN/. >

Open the catalog to page 11

Minipleat filter panelsF757 F759 F780 F781 Filter class to EN 779 > 1) F7F9֖Filter class to EN 1822 > 2) ֖H11H13Average efficiencyagainst atmospheric dustin %8595֖Extraction efficiency to EN 1822in %֖> 95> 99.95Initial pressure differentialat nominla volume flow > 3) in Pa140180125250Temperature resistance in ְCup to +80 > 1) EN 779: particle air filters for general room air-conditioning technology. See leaflet F0/2/EN/. > 2) 3) EN 1822: Particulate Filter (HEPA and ULPA)Ӕ. For nominal volume flow for filter size concerned, see leaflet F7/4.4/EN/. >

Open the catalog to page 12

Particulate Filter Cells F770F771F772 Filter class to EN 1822 > 1) H11H13H14Extraction efficiency to EN 1822in %>95>99.95>99.995Initial pressure differenceat nominal volume flow > 2) in Pa125250125Temperature resistancein ֺCup to +100 > 1) 2) EN 1822: Particulate Filter (HEPA and ULPA)Ӕ. For nominal volume flow for filter size concerned, see leaflet F7/3.3/EN/. >

Open the catalog to page 14

Filter type F760 Rated volume flowin l/s2855in m > 3 /h100200Pressure differentialat rated volume flowin Pa100175Activated carbon volumein l2.24,0 Coating thicknessin mm2626Contact timein s0.080.07B.E.T. surfacein m > 2 /g10001000External diameterin mm145145 Lengthin mm250450 Rec. operating temperaturein C< 50 Rec. relative humidityin %70 >
