Trico offers lubrication management solutions to enhance machine productivity and reliability, including high-performance products and services like consulting, monitoring, training, and auditing. Their focus is on maximizing productivity while maintaining standards.
The Flexible Flinger Disc improves lubrication in bearing housings by creating an oil splash, eliminating slippage and metal wear. Made from corrosion-resistant stainless steel and Viton®, it is adaptable to various shaft diameters.
Constant level oilers maintain a set oil level, automatically replenishing oil. Available in vented and closed systems, they prevent contamination, with closed systems being effective in harsh environments.
These oilers offer an economical solution for maintaining oil levels, featuring adjustable settings, multiple air vent slots, and a large surge chamber to prevent overflow. Stainless steel models are available for corrosive environments.
Specifications include operating temperatures, materials, and dimensions, highlighting corrosion resistance, ease of assembly, and adaptability.
Trico guarantees products against defects, offering free repair or replacement under certain conditions, with the right to change specifications without notice.
Materials include butyrate plastic, zinc die-cast, and stainless steel, with operating temperatures from 165ºF to 350ºF. Opto-Matic oilers prevent overflow with adjustable settings and multiple air vent slots.
Designed for large capacity applications, maintaining constant oil levels in pump bearing housings and gearboxes, featuring a large reservoir and feed tube.
Prevent contamination and spillage with a closed system design, featuring a one-piece glass reservoir and adjustable settings.
Designed for closed systems, preventing contamination without adjustment or level setting, suitable for harsh environments.
Prevent pressure increase in closed systems, extending seal life and preventing leakage, made from corrosion-resistant stainless steel.
Viewports and liquid level gauges for visual inspection of industrial fluids, prolonging equipment life by monitoring fluid levels and conditions.
Emphasizes preventing oil contamination and maintaining lubricant cleanliness to extend equipment life, recommending products like WATCHDOG oilers and Equalizer expansion chambers.
Detailed specifications and ordering instructions for liquid level gauges and oil sampling equipment, focusing on Trico's products.
Liquid level gauges available in various sizes, constructed from brass with glass sights and Viton seals, withstanding temperatures up to 250ºF.
Select gauge mounting type and model number from selection charts, with optional top caps for closed systems.
Emphasizes the importance of oil sampling in maintaining machinery, with Trico offering sampling supplies and accessories.
Trico provides auditing, consulting, training, and monitoring services to improve lubrication management and equipment reliability.
Designed to collect representative samples under typical operating conditions, featuring protective caps and check valves.
Allow easy viewing of fluid levels and oil condition, suitable for non-pressurized systems.
Designed for high-pressure hydraulic applications, allowing sampling between standard flanges.
Specifications for four-bolt flanges, detailing codes, pipe diameters, and materials, with carbon steel and stainless steel as primary materials.
Includes a selection chart for catch pipe sampling ports, specifying thread sizes, dimensions, and materials.
Trico offers compact vacuum pumps for oil sampling, drawing a vacuum of 27 inches of Hg.
Prevent airborne contaminants from entering systems, featuring a two-stage breather system with a filter and desiccant.
Discusses the importance of detecting and removing moisture from lubricating oils, describing methods for detection and removal.
Monitor moisture levels in lubricating oils, providing real-time readings to prevent damage.
Protect industrial equipment by preventing moisture and particulate contamination, featuring a dual filtration system.
Comprehensive information on products and systems designed to maintain the integrity of lubricating oils and prevent contamination.
Designed for extreme humidity environments, incorporating check valves to control airflow and prolong desiccant life.
- Nominal Air Flow Rate: 35 CFM
- Operating Temperature Range: -20ºF to 200ºF
- Material: ABS plastic and impact-modified acrylic
- Particulate Filtration Level: 2 Micron Filter
- Water Vapor Adsorbent: Efficient at humidity levels of 80% and higher.
- Color Indicating: Silica gel changes color to indicate replacement need.
- Durable Construction: Made from rugged materials.
- Easy Connection: Available with 1" slip fit or 2" male NPT connection.
- Reusable Top Cap: Allows economic replacement of the desiccant cartridge.
Various adapters available for different applications, including flange, threaded, bayonet, and spin-on adapters.
Addresses issues with oil mist by using a coalescing breather to prevent environmental and safety issues.
Designed to remove water vapor from air, ideal for bearing housings.
Systems for high-viscosity oils, capable of filtering oils up to 7500 SUS @ 100ºF.
Proper fluid handling is crucial to prevent contamination, with features like ruggedness and ease of handling.
Detailed specifications and applications for various oil lubrication systems, including Oil Safe® products and gravity feed oilers.
Include a range of lids and drums for easy identification and contamination prevention, made from high-density polyethylene.
Provide a reliable and continuous supply of oil using gravity, cost-effective and consistent.
- O-ring Material: Buna-N
- Temperature Range: -40°F to 176°F
- Reservoir Materials: Heavy wall heat-resistant glass and acrylic plastic
- Max Operating Temp: 250°F for glass, 165°F for acrylic
- Finish: Bright nickel or zinc plated for corrosion resistance
Used in various industrial applications, featuring adjustable oil feed rates and durable construction.
Includes selection charts for different models, specifying capacities, dimensions, and connection types.
Comprehensive guide for selecting and using oil lubrication systems in industrial settings.
Detailed specifications for various lubrication products, including chain oilers and full flow dispensers.
To order solenoid versions, use the solenoid voltage chart and add a designator to the model number.
Toggle shut-off for manual control, solenoid versions for automatic control, and mounting studs for easy installation.
Used for lubricating chains, bearings, and other machinery parts, suitable for remote or multiple point lubrication.
Applicators, valves, and manifolds ordered separately.
Used when oil cannot stay in place or when sealing out contaminants is necessary.
Devices used to dispense grease over time to bearings, preventing contamination and providing consistent lubrication.
- Mechanical: Spring-loaded to drive a plunger for grease feeding.
- Electro-Chemical: Uses a battery-operated timer to activate an electrochemical cell.
- Electro-Mechanical: A motor-driven cam activates a piston pump for grease ejection.
- Prevents contamination.
- Alternative to manual lubrication.
- Provides constant lubricant flow at low cost.
- Easy operation and suitable for frequent re-lubrication.
- Ideal when staff is insufficient for manual lubrication.
- Cost-effective compared to automatic systems.
- Useful in hard-to-access or hazardous areas.
Offer precise grease flow to critical machine parts, suitable for environments with moisture, high temperatures, and contamination.
- GL-P Series: Mechanical, spring-loaded with anodized aluminum base.
- GL-M Series: Double spring design for uniform pressure.
- M Series: Electro-mechanical with variable feed rate.
- V Series: Electro-chemical with pre-filled grease.
Trico offers Single Line Resistance Systems for reliable oil lubrication, using pumps to deliver oil and control units to apportion oil delivery.
- Continuous Pumps: For large lubrication needs with constant oil output.
- Automatic Cyclic Pumps: For intermittent lubrication with adjustable intervals and outputs.
- Manual Pumps: For infrequent lubrication with manual operation.
Provide oil lubrication using a piston principle, with various output sizes available.
Trico offers pumps with different reservoir capacities and control options for PDI systems.
Detailed specifications and features of Trico's lubrication pumps and accessories.
Pumps operate within a temperature range of 32-120°F and use Buna-N seals.
Designed for automatic cyclic systems with fewer than 50 points, featuring adjustable interval times.
Versatile pumps with digital control over dispensing time and cycle intervals.
Designed for continuous lubrication, featuring a standard float switch and pressure gauge.
Provide precise control of lubricant flow to each point.
Various fittings, hoses, and other accessories compatible with the pumps.
Trico pumps are designed to dispense mineral-based lubricants with viscosities ranging from 30-250 centistokes.
Consider factors such as load, friction, ambient temperature, and equipment speed when selecting lubricating oils.
A chart illustrates the relationship between operating temperature and oil viscosity.
Guides users through designing a cyclic lubrication system.
Formulas for calculating lubrication needs for various components.
Key considerations include pump location and interconnecting plumbing.
MQL minimizes lubricant use, reducing airborne mist and associated hazards.
Features pressure delivery, various nozzle options, and solenoid voltages.
Designed for precise coolant delivery in machining applications.
Includes copper nozzles for fixed positions and a nozzle manifold for band saws.
Spray cooling is essential in metal removal operations, providing benefits similar to flood cooling.
Metal removal generates heat through external and internal friction.
- DL & DL Magnum Systems: Designed for light-duty machining.
- Li’l Mister Systems: Compact systems ideal for tool room applications.
- SST Systems: Designed for production applications.
- Spraymaster Systems: Provide convenient spray cooling.
- Spraymaster II: Offers solenoid control for instant on-off operation.
SprayMaster II units are designed for use with water-soluble coolants.
Provide spray coolant delivery to up to six locations.
Offers variable coolant delivery, suitable for a range of machining requirements.
Models 30034 and 30095 cover applications from single to multiple points.
Cutting fluids are essential in machining for temperature control and lubrication.
Formulated for superior performance in metal cutting operations.
Suggested dilution ratios for different operations to optimize the use of Tri-Cool fluids.
Catalog excerpts
PRODUCT CATALOGPRODUCT CATALOG >
Open the catalog to page 1
Opto-MaticConstant Level Oilers. . . . . . . . . . . . . . . C2-C3Breather Tubes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C4 LCL Oilers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C5 Opto-MaticήClosed System Oilers. . . . . . . . . . . . . . . . . C6 WatchdogOilers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . C7 > StreamlinerΙ Grease Dispensers. . . . . . . . . . . . . . . K2-K4 > Basic Types of Systems. . . . . . . . . . . . . . . . . . . . . . . . . L2 Positive Displacement Injectors. . . . . . . . . . . . . . . . . . . L3 Pumps for PDI...
Open the catalog to page 2
Max. Operating Temp.350 պ Continuous Hub MaterialStainless SteelFlinger MaterialViton > Shaft Connection(2) 10-32 Set Screws Outside Diameter3.50 - 7.005.00 - 9.50Inside Diameter1.50 - 2.502.50 - 4.00 > Model No.Inside DiameterOutside Diameter 369501.50 to 2.50/Machined by Customer3.50 to 7.00369511.50 to 2.50/Customer Specified3.50 to 7.00369522.50 to 4.00/Machined by Customer5.00 to 9.50369532.50 to 4.00/Customer Specified5.00 to 9.50 >
Open the catalog to page 4
VENTED CONSTANT LEVEL OILER WITH SIDE CONNECTION VENTED CONSTANT LEVEL OILER WITH BOTTOM CONNECTION CLOSED SYSTEM OILER WITH PRESSURE BALANCING LINE > Direction of shaft rotation Direction of shaft rotation Direction of shaft rotation Direction of shaft rotation CLOSED SYSTEM OILER MOUNTED ONCENTER LINE OF DESIRED OIL LEVEL >
Open the catalog to page 6
Standard 304 Stainless Steel 30003 ZincZinc/Chromate Plate 304 StainlessPassivated Wire guards are ordered separately and are customer installed. DescriptionModel No.StandardModel No.Stainless Steel Max. Operating Temp.Reservoir Casting Finish Internal Parts O-Ring 250F ContinuousOne-Piece Glass BottleZinc Plated SteelViton 3001230013 30016 30020-30223 30225 30230 2-1/2 oz. Guard4 oz. Guard 8 oz. Guard16 oz. Guard ڮ A A A A Capacity(NPT)* Connection Dimensions (in.) > * B Min.B Max.C Min.C Max.Model No.A > C* 3/4 / 43 30002 30003 30005 30010 2-1/2 oz.4 oz.8 oz.16 oz. > C* C* 1/41/4 1/4 1/4 2-1/22-11/163-3/164-1/8...
Open the catalog to page 7
Breather tubes are available for customer installed vent ports in bearing housing or piping lines. >
Open the catalog to page 9
Frequent operation start-ups and environmental temperature swings in mechanical equipment can cause the air pressureinside oil sumps to increase and decrease, causing it to breatheђ. This ԓbreathing air, in most cases, comes from the external atmosphere through vents, fill ports, seals, and anywhere the oil sump is open to atmosphere. This can cause debris, dirt, and moisture to enter the equipment attacking and breaking down the equipments vital lubricant and ultimately reducing the life of bearings and gears. The EQUALIZER > Ԯ Expansion Chamber reduces or eliminates thisbreathingӔ action by...
Open the catalog to page 14
Closed system liquid level gauge with pressurebalancing line connected to a gear box housing. >
Open the catalog to page 18
Contamination of machinery lubricants is a major problem for many manufacturers. In fact, it has been stated that six to seven percentof the gross national product ($240 Billion) is required just to repair the damage caused by mechanical wear, which is caused bycontamination. However, when contamination is controlled, the life span of a machines vital components can be extended by as muchas 50 times. ItҒs for these reasons and many more that routine sampling is done.The process of sampling is not only a vital and necessary function in identifying contaminants andcontamination levels, but also...
Open the catalog to page 22
Maximum Working Pressure9000 PSI (630 bar)Connect Under Pressure5800 PSI (400 bar) Check Valve BallStainless Steel O-RingViton > 36133 36109 ծ Maximum Operating Temperature-4F to 392ںF > Gauge adapter can be usedto attach pressure gaugesfor troubleshootingpurposes when barbfitting is removed.Sample port adapter is used with any pitottube, liquid level gauge, or sample portsthat have a black cap. PartPort ConnectionDim DMaterialNumber(Dim C) > 36100 36104Barb for 1/4" OD TubeM16x2Carbon Steel36105Barb for 5/16" OD TubeM16x2Carbon Steel36106Barb for 1/2" OD TubeM16x2Carbon Steel36109 Carbon Steel...
Open the catalog to page 23
Maximum Pressure500 PSI (34.5 bar)MaterialCarbon Steel or Stainless Steel Check Valve BallStainless Steel SealViton Maximum Operating Temperature-4պF to 392F > Fixed AdapterSwivel AdapterTube LengthFitting 362003621312"1/4" NPT Male362013621418"1/4" NPT Male362023621524"1/4" NPT Male362033621672"1/4" NPT Male Fixed AdapterSwivel AdapterTube LengthFitting 362043621712"1/4" NPT Male362073622018"1/4" NPT Male362103622324"1/4" NPT Male Fixed AdapterSwivel AdapterTube LengthFitting 362053621812"1/4" NPT Male362083622118"1/4" NPT Male362113622424"1/4" NPT Male > Fixed AdapterSwivel AdapterTube LengthFitting...
Open the catalog to page 25
Max Pressure3000 PSI (274 bar) Code 616000 PSI (548 bar) ֖ Code 62Connect Under Pressure5800 PSI (400 bar) Code 62 MaterialCarbon Steel or Stainless Steel Check Valve BallStainless Steel SealsViton Maximum Operating Temperature-4ֺF to 392F >
Open the catalog to page 27
Part NumberDescription 36800Vacuum Pump, Standard36801Vacuum Pump, Heavy-Duty with Release Valve > 3680136800 36813 Note: Bottles sold separately Part NumberDescription 36813Clean, 4 oz Sample Bottle, Single36814Clean, 4 oz Sample Bottle, Case of 57636816Clean, 8 oz Sample Bottle, Regular Wall, Single36817Clean, 8 oz Sample Bottle, Regular Wall, Case of 2703681916 oz Oil Sample Purge Bottle36821Black Plastic Mailer for 4 oz Bottles > 368061/4" OD Poly Tubing, 100 ft Roll368075/16" OD Poly Tubing, 100 ft Roll368081/2" OD Poly Tubing, 100 ft Roll368091/4" OD Poly Tubing, 500 ft Roll368105/16" OD...
Open the catalog to page 29
Moisture in lubricating oils is the root cause of prematurely damaging oiland accelerating wear of machine components. As water invades your fluids it will not only attack the additives in the oils, destroying their beneficial properties; but it will also cause damage to the machine surfaces through corrosion, and rapidly degrade the oil through increased oxidation. By understanding the effects of water contamination, it is easy to see the importance of moisture detection and removal.Once water has entered the lubricant, it can exist in one or more of thefollowing forms; dissolved, emulsified,...
