WP Series Premium Waterproof Portables

Product catalog summary

Overview: The WP Series is a range of portable, waterproof instruments designed for diverse environments such as laboratories, fields, and industrial settings. The enclosures are rated IP67 for waterproofing, ensuring they float if dropped in water, while connectors are rated IP65. The series is designed for durability and ease of use, featuring a user-friendly menu system and a 32-character alphanumeric display.

Power and Battery: The WP Series includes a rechargeable NiMH battery and a charger suitable for the destination country. Options for extended use include a solar panel or car cigarette lighter charger.

Data Logging and Memory: The instruments have a 150-reading memory capacity (100 for WP-89), with automatic data logging capabilities. Users can set logging intervals from 1 second to 24 hours, except hourly logging is not available for WP-89. All readings are time-stamped, and the RS232 interface option allows data transfer to a printer or PC.

Specifications: The WP Series includes various models with specific features:

WP-80 and WP-80D: Dual-channel pH-mV-Temperature meters with automatic buffer recognition and temperature compensation.
WP-87 and WP-87T: Multi-channel logging thermometers with differential readout and automatic calibration.
WP-90: Specific Ion-pH-mV-Temperature meter with auto-ranging capabilities.
WP-89: Features include turbidity measurement with a range of 0.1 to 30,000 NTU and optional RS232 port for data transfer.

Environmental and Physical Specifications: The instruments operate in temperatures from 0 to 45°C and humidity levels up to 95% R.H. They are constructed from tough, anti-static Luran-S plastic, ensuring durability in harsh conditions.

Additional Features: The WP Series supports GLP compliance by storing calibration data, including date, time, and results. Optional accessories include various sensors, RS232 interfaces, and software for data management.

Conclusion: The WP Series is designed and manufactured in Australia, adhering to the AS/NZS ISO 9001 standard, and is known for its quality and reliable service. It offers a comprehensive solution for portable measurement needs across different applications.

Additional Overview: This document also provides technical specifications and ordering information for various water quality measurement devices, including temperature, conductivity, salinity, pH, and dissolved oxygen meters.

Additional Specifications:

WP-82 and WP-82Y Dissolved Oxygen-Temperature Meters: Compatible with YSI dissolved oxygen sensors. Measurement ranges include 0 to 20.00 ppm for dissolved oxygen, 0 to 240.0% saturation, and 0 to 45.0% gaseous. Temperature range is -10.0 to 120.0°C with a sensor limit of 50°C. Features dual automatic temperature compensation.
WP-91 Dissolved Oxygen-pH-mV-Temp Meter: Similar specifications to WP-82Y with additional pH and mV measurement capabilities. pH range is 0 to 14.00 with a resolution of 0.01 pH. mV range is 0 to +/-1500 mV with auto-ranging.

Ordering Information:

Various models and kits are available, including WP-81, WP-84, WP-89, WP-82, WP-82Y, and WP-91.
Accessories include battery chargers, pH buffers, and various cable lengths (3m, 5m, and extended cables up to 60m for specific sensors).

Additional Notes:

Extended cables are available for specific sensors with a maximum submersion depth of 60 meters.
TPS reserves the right to change specifications without notice.

Catalog excerpts

WP Series Premium Waterproof Portables-2

The WP Series enclosure is fully waterproof to an IP67 rating, and will float if dropped into water. The connectors are rated to IP65. The case, keypad and connectors are designed for maximum durability in the harshest conditions. A sturdy carry case is available for field use. The case holds the instrument, sensors and standard solutions. The WP Series is equally at home in laboratory, field or industrial environments. The WP Series are supplied with a rechargeable NiMH battery and charger to suit country of destination as standard. For extended field trips, a solar panel or a charger lead for...

Open the catalog to page 2
