smartCHEM Series Advanced Benchtop Models

Product catalog summary

Overview of smartCHEM Series:
The smartCHEM series consists of advanced analytical instruments for laboratory use, featuring data logging, calibration, and security functionalities. Manufactured in Australia, these instruments comply with the AS/NZS ISO 9001 standard.

Key Features:

Calibration and Data Logging: Stores calibration data with timestamps and alerts for failed calibrations. Includes a Calibration Alarm and date-stamped readings.
Notepad and Automatic Datalogging: Stores up to 2730 readings with user-set intervals for data logging, supporting serial port data transfer.
Automatic Stability Function (ASF): Identifies unstable parameters and stabilizes readings for accurate data.
P.I.N. Code Security Access: Restricts unauthorized menu access to prevent changes to settings.
Multiple Outputs: RS232 Serial port for data transfer and optional analogue recorder output.
Waterproof Construction: Designed for harsh environments with waterproof enclosures.
Display and Interface: Features a graphic display and tactile keypad for easy navigation.

Specifications:

Measurement Capabilities: Measures pH, millivolts, temperature, conductivity, TDS, and specific ion concentrations.
Memory and Logging: Varying memory capacities with manual and automatic logging options.
Power and Environment: Operates on 12V DC power, suitable for 0 to 45°C and up to 95% R.H.

Models and Options:

Various models for specific measurements like pH and ion concentration.
Optional sensors and accessories enhance functionality.

Specifications for Sensors:

Dissolved Oxygen Sensors: ED1 and YSI models with ranges from 0.00 to 40.00 ppm and 0.0 to 450% saturation.
Conductivity and TDS Sensors: Configurations k=0.1, k=1.0, and k=10, measuring 0 to 2000 mS/cm and 0 to 1000 ppK.
pH and ORP Sensors: Glass and Teflon models with auto-recognition of buffers.
Temperature Sensors: Operate from -10.0 to 120.0°C with automatic compensation.

Procedures:

Calibration: Automatic and manual options for pH, millivolts, and ions, supporting reference thermometer calibration.
Temperature Compensation: Automatic for membrane permeability and oxygen solubility.

Standards and Recommendations:

Use specific calibration standards and buffers for accuracy.
Automatic salinity correction using conductivity/TDS readings.

Ordering Information:

Product codes for sensors, cables, and software. Some items need additional components.
Ion Selective Electrodes available in a separate brochure.

Additional Features:

smartCHEM-Lab software for enhanced data management.
Full function tactile keypad for easy operation.

Contact Information: TPS Pty Ltd, Brisbane, Australia. Phone and email details provided for support.

Catalog excerpts

smartCHEM Series Advanced Benchtop Models-2

To comply with GLP guidelines, the date, time and results of the last calibration are stored in memory, along with the instruments serial number. This data can be displayed or sent to the serial port. All readings stored in memory are stamped with the date, time and a log number. Warning of failed calibration is provided.New for the smart CHEM series is the Calibration Alarm. This can be activated for any one or more parameters the user chooses, and can be set to Daily, 1 Weekly, 2 Weekly or 4 Weekly. When calibration is due, the instrument displays a message at turn-on, indicating which parameters...

Open the catalog to page 2

smartCHEM Series Advanced Benchtop Models-3

The 240 x 64 dot graphic display features a user-friendly menu system. Full text prompting and error messages are provided. The graphic capabilities of the display allow for 11.1 mm or 7.4 mm digit size, depending on model. The snapshots below are 1:1 scale illustrations of the smart CHEM displays. Note that all readings plus date and time are displayed simultaneously for all models.A full function keypad with raised, tactile buttons is provided. The Menu and Function keys are used to navigate the menu system. Several One-Touch keys are provided for instant access to often-used functions. The...

Open the catalog to page 3
