CAD-CAM SOLUTION FOR THE SHEET METAL INDUSTRY

TOPSOLID, THE DIGITAL ALLY OF MANUFACTURERS, NOW AND IN THE FUTURE. For over 40 years, TOPSOLID has been developing CAD, CAM, PDM, ERP and VR integrated software solutions to support manufacturers worldwide as they transition to Factory 4.0. Our single platform brings together in the same ecosystem all the solutions to free up creativity, optimize the industrial process, boost productivity, and secure data. Here at TOPSOLID, we strive to take complex, seemingly impossible tasks and make them simple and doable, in 6 functional sectors: precision manufacturing, digital engineering, the wood industry,...

It is aimed at companies looking to manage their cutting operations efficiently, regardless of whether they work with laser, plasma, water jet or oxy-fuel cutting machines. This module is part of a comprehensive digital chain for manufacturers keen to boost automation, reliability and responsiveness while maintaining perfect control over their production. In an industrial environment where responsiveness, precision and optimisation of resources are all essential, TopSolid’Cut rises to the major everyday challenges faced by professionals in the cutting sector: ■ Shorter preparation times for the...

CENTRALISED MANAGEMENT WITH TOPSOLID’WORKMANAGER Designed to be part of a diverse industrial environment, TopSolid’Cut is extremely flexible and able to handle a host of data exchange modes, formats and software interconnections. It adapts easily to your legacy tools to ensure seamless production processes from the design phase to the workshop. TopSolid’WorkManager, which is integrated into the TopSolid ecosystem, lets you centralise, organise and automate the upstream phases of sheet metal production, with a direct link to TopSolid’Cut. COMPATIBLE FORMATS C entralised CAD files, cutting data,...

PARTS MANAGEMENT ■ Material / thickness compatibility ■ Rotation, symmetry, overturn SIGNIFICANT MATERIAL SAVINGS THROUGH OPTIMISED NESTING TopSolid'Cut offers a standard nesting module with a powerful algorithm that results in significant material savings. ■ Material and thickness checks ■ Checks of the gaps between parts and the quantity ■ Grid-based placement, maximum filling ■ Priority large parts ■ Minimum number of different nestings ■ Maximum number of part references per support 8 ■ TopSolid'Cut ■ The integrated cutting cad-cam solution for the sheet metal industry.

TOPSOLID’CUT The TopSolid’Cut solution, which has been on the market for more than 40 years, is built on renowned expertise to guarantee 100% satisfaction. Knowledge of the machines and integration of their technical developments have made TopSolid’Cut the benchmark solution in the sector. ■ Optimised cycle times ■ Cuts allocated by part or placement ■ "FlyCut" cutting for hole templates ■ Smooth joints between cuts ■ Checks of dangerous lead-ins ■ Checks of dangerous joints ■ Realistic 3D simulation of cuts, toolpaths and machine head movements ■ Management of cutting speed ■ Speed levels for...

To complete your cutting processes, TopSolid'Punch is the natural ally of TopSolid'Cut. Specially designed for programming NC punching machines, TopSolid'Punch lets you centralise cutting and punching operations in a single, consistent environment. This add-on enables you to automate repetitive tasks, reduce the risk of errors, and significantly boost your productivity. ■ Native programming of NC punching machines (turret punch presses, multi-tool machines, etc.) ■ Automated management of standard and special tools ■ Smart optimisation of punching cycles ■ Supports engraving, tapping, notching...

OUR SUPPORT: MUCH MORE THAN SOFTWARE A team on hand to guarantee your tools perform brilliantly day after day CERTIFIED TRAINING COURSES Here at TOPSOLID, our pledge extends beyond the software itself. We support you at every step to make your project a long-term success. Whether you’re just getting started or fully engaged in upskilling, our service offer is designed to boost your performance and autonomy. Initial, advanced and specialist training tailored to different profiles (operators, programmers, process planning managers, etc.) In-person, digital or on-site training: total flexibility...

RCS : 329109227 R.C.S Evry • Crédit photo : Stéphane Couchet • Direction artistique et création graphique : creation-k.com READY TO BOOST YOUR PRODUCTION WITH TOPSOLID? Our sales and technical teams are on hand to advise you, arrange for a customized demo, or put together an offer tailored to your industrial challenges. MADE IN FRANCE topsolid.com BUILDING TRUST, SHAPING THE FUT
