Top Line Biopharm Fittings

Product catalog summary

Overview
Top Line specializes in precision-crafted automatic weld fittings designed for high-speed automatic welding equipment, adhering to pharmaceutical process specifications and ASME BPE dimensional standards.

Specifications

Size Range: 1/2” OD to 6” OD
Materials: 316L for Weld and Clamp Connections
Finish Options:
- No. 3 - 20 RA Mechanical ID only (ASME BPE SFF1)
- No. 3 EP - 15 RA Mechanical and Electropolish ID only (ASME BPE SFF4)
- No. 7 - 20 RA Mechanical ID 150 Grit Mechanical OD (ASME BPE SFF1)
- No. 7 EP - 15 RA Mechanical and Electropolish ID 150 Grit Mechanical OD (ASME BPE SFF4)
- No. 1 - unpolished
- 10 RA ID available

Ordering Specifications
Specify quantity, size, product description, stock number, and polish requirements when ordering. Example: 3 Each 2” TL2S-90° #40720-3 Type 316L No. 3.

Product Range
Includes detailed tables of fittings such as elbows, tees, caps, crosses, and reducers, with size, stock numbers, and finish options.

Key Product Types

Elbows: Available in 45° and 90° configurations with various dimensions and finishes.
Tees: Includes standard, reducing, and short outlet tees with detailed size and finish options.
Caps and Crosses: Offered in multiple sizes with mechanical and electropolish finishes.
Reducers: Both concentric and eccentric types are available, with some not meeting BPE OAL dimensions.

Conclusion
Top Line's BPE fittings are engineered for high purity industries, offering a range of sizes, materials, and finishes to meet specific sanitary and pharmaceutical requirements.

Additional Sections

Reducers: Lists both concentric and eccentric reducers with specific sizes and stock numbers, noting some do not meet BPE OAL dimensions.
Elbows and Tees: Specifications for 45° and 90° elbows, straight tees, cross fittings, and reducing tees, with size, stock number, and dimensions.
Clamps: Details on clamp fittings, including tube outer diameter, size, and stock numbers, with some not meeting BPE standards.
Instrument Tees: Specifications for instrument tees with size, stock numbers, and dimensions, noting some do not meet ASME BPE standards.
U-Bends: Lists 180° u-bends with size, stock numbers, and dimensions, noting some do not meet ASME BPE standards.
Additional Products: Mentions valves, fittings, tubing, gauges, sight glasses, braided hoses, pumps, and strainers available from the supplier.

Key Information

Stock numbers are provided for easy ordering and reference.
Some components are marked with asterisks indicating they do not meet specific BPE or ASME standards.
Supplier contact information is available for further assistance and inquiries.
