CLASSIC AND MATIC PRODUCT OVERVIEW Temperature control units SWISS THERMAL MANAGEMENT

Our product overview Customised to your industry Plastics & injection moulding Pharmaceutical & chemical temperature control units Heat transfer medium water and oil up to 90°C/150°C The universal temperature control units impress with their ease of use and high performance. Designed for use with water or oil, they provide a versatile range of applications with a heating capacity ranging from 3 to 18 kW. temperature control units Heat transfer medium water up to 90°C The water temperature control units are distinguished by their high reliability and user-friendly operation. With a heating capacity...

Rubber & silicone Lamination, printing & textiles water temperature control units Heat transfer medium water up to 160°C By utilizing pressurized water, these temperature control units allow for high maximum temperatures. With a heating capacity ranging from 6 to 48 kW, they offer a versatile solution for various applications. temperature control units Heat transfer medium oil up to 360°C The oil temperature control units impress with maximum temperatures reaching up to 360 °C and heating capacities from 8 to 144 kW, even under extreme conditions. Their design meets all safety requirements for...

Our CLASSIC temperature control and cooling units are perfect as stand-alone solutions. They are both robust and easy to maintain. The use of proven technologies guarantees the durability of this product group. Our CLASSIC range of temperature control units comes with digital networking capabilities. Units from our CLASSIC range are ideal solutions for applications in which your temperature control unit’s main function is to control the temperature of the circulation medium. 1 Universal temperature control units CLASSIC Duo, Heat transfer medium water and oil up to 90°C/150°C 2 Water temperature...

■ Compact controller with predefined machine settings (according to appliance type) ■ PID control with 2-point cooling switchable to PID cooling ■ Simple operation via key combinations ■ Clear display of operating mode, setpoint actual temperature and flow rate ■ Physical units selectable ■ Visual error messages ■ Limit value monitoring for excessive temperature deviation between setpoint and actual value ■ Analogue: entrance 0-10 V, (0)4-20 mA exit 0-10 V ■ Languages: numerical parameters ■ Compact controller with predefined machine settings (according to appliance type) ■ PID control with 2-point...

The MATIC range of temperature control units covers all the needs of production environments leveraging industrial networks. The entire MATIC product range is equipped with the new and in-house developed IRIS controller, offering a broad range of connectivity features. It covers the time-tested serial and digital/analogue interfaces, classical fieldbus protocols, as well as current state-of-the-art industrial ethernet (Profinet, EtherNet/IP). The MATIC temperature control units put your economic goals into practice. The energy-saving eco mode leverages the latest-generation variable-frequency...

■ Interfaces and options are flexibly expandable ■ The controller automatically recognises new components ■ One-click software updates via USB stick ■ 7-inch touchscreen with interactive user guidance ■ Foldable display for ergonomic working ■ Predefined actions for all common processes such as mold emptying, end of shift, emergency cooling ■ Languages: EN, DE, FR, IT, ES, NL, CS, PT, HU, PL, SV, HBS, JA, TR, ZH, RO (others through future software updates) ■ User concept with three user levels and password protection ■ Error messages with recommended actions ■ Limit value monitoring ■ Automatic...

■ standard, □ optional, - not possible I/O Modul 1, Manufacturer protocols (RS-232, RS-485, CAN, Current-Loop) I/O Modul 2, Profinet, EtherNet/IP, Profibus I/O Modul 3, 3 x Digital output (changeover switch), 2 x Digital input (on/off), 2 x Analog output, 2 x Analog input, 1 x ext. Temperature sensor 1 included in I/O module 1, 2 included in I/O module 2, 3 included in I/O module 3 * Former TT-168 12 kW CLASSIC and MATIC product overview temperature control units

© Heater (10 Cooler © Float (12 Solenoid valve (13 Solenoid valve @ Flow meter @ Temperature sensor flow @ Return temperature sensor © Pump © Water-filter © Tank © Safety temperature limiter 10/24 CLASSIC and MATIC product overview temperature control units

WATER temperature control units Heat transfer medium water up to 90°C 1 Flow meter Main switch Non-return flap Solenoid valve Temperature sensor flow Return temperature sensor Plate heat exchanger Heat exchanger Subject to technical changes.

2 Water temperature control unitsCLASSIC Water, MATIC Water, Heat transfer medium water up to 90°C a) indirect, b) air cooled, c) direct, ■ standard, □ optional, - not possible I/O Modul 1, Manufacturer protocols (RS-232, RS-485, CAN, Current-Loop) I/O Modul 2, Profinet, EtherNet/IP, Profibus I/O Modul 3, 3 x Digital output (changeover switch), 2 x Digital input (on/off), 2 x Analog output, 2 x Analog input, 1 x ext. Temperature sensor 1 included in I/O module 1, 2 included in I/O module 2, 3 included in I/O module 3, 4 included in MP-988 CLASSIC and MATIC product overview temperature control...

3 Pressurised water temperature control units CLASSIC Water, MATIC Water, Heat transfer medium water up to 160°C a) indirect, b) air cooled, c) direct, ■ standard, □ optional, - not possible I/O Modul 1, Manufacturer protocols (RS-232, RS-485, CAN, Current-Loop) I/O Modul 2, Profinet, EtherNet/IP, Profibus I/O Modul 3, 3 x Digital output (changeover switch), 2 x Digital input (on/off), 2 x Analog output, 2 x Analog input, 1 x ext. Temperature sensor 1 included in I/O module 1, 2 included in I/O module 2, 3 included in I/O module 3, 4 included in MP-988 * former TT-142 N, ** former TT-137 N

@ Solenoid valve ® Pneumatic valve @ Water filter ® Safety valve @ Expansion tank Thermostat @ Probe level control @ Flow control @ Pump @ Pressure increasing pump @ Heating 16/24 CLASSIC and MATIC product overview temperature control units
