CLASSIC PRODUCT OVERVIEW Cooling units SWISS THERMAL MANAGEMENT

COOLING SYSTEMS Flexibility and performance for every requirement Our range of cooling units offers a wide selection of models with cooling capacities from 5 to 259 kW – perfectly tailored to a wide variety of industrial applications. Air- or water-cooled versions for maximum adaptability Three different refrigerant options for optimum efficiency and sustainability Heating (only with tank) switchable depending on model/as an option with or without tank depending on model/as an option Whether for precise process cooling or demanding environments – our cooling units deliver reliable performance...

Execution variants Air-cooled Heating system Low installation costs: As no water circuit is required, the costs for pipework and water treatment are eliminated. Easy to maintain: Less complex as no water system to clean or monitor. Flexibility: Can be installed in almost any environment, as no access to water sources is required. Regardless of the ambient temperature: Water-cooled systems deliver maximum efficiency, even at high ambient temperatures. Constant performance: The performance remains stable regardless of the outside temperature. Quiet operation: As no large fans are required for air...

■ Self-optimizing temperature controller with temperature display 1/10 °C - steps ■ Display in °C or °F and l/min or gal/min ■ Digital flow display and monitoring (depending on device) ■ Integrated heating (depending on device) ■ Automatic or manual refill ■ Leakstopper device - operation in pressure and vacuum mode possible (depending on device) ■ Submersible sealless pump made from bronze (depending on device) ■ Proven pump with mechanical seal (depending on device) ■ Long life expectancy due to the electronic control of the compressors operating time ■ All parts in contact with water are made...

■ Compact controller with predefined machine settings (according to appliance type) ■ PID control with 2-point cooling switchable to PID cooling ■ Simple operation via key combinations ■ Clear display of operating mode, setpoint actual temperature and flow rate ■ Physical units selectable ■ Visual error messages ■ Limit value monitoring for excessive temperature deviation between setpoint and actual value ■ Analogue: entrance 0-10 V, (0)4-20 mA exit 0-10 V ■ Languages: numerical parameters ■ Compact controller with predefined machine settings (according to appliance type) ■ PID control with 2-point...

CLASSIC Cool TT-5’500 E with heating CLASSIC product overview cooling unit

— = Theoretical pump characteristic curve Nominal power 5 kW — = Achievable practical values for permanent internal bypass taken into account Refrigerant — R-407c — = R-134a = R-1234yf On request: for refrigerators, there is the option of adjusting the minimum operating temperature. The reference values depend on the installation and the conditions on site.

CLASSIC Cool TT-14’500 H with heating

Level control Visual fault indications Acoustic warning Pressure regulation Profibus interface Profinet interface OPC-UA interface Web interface (LAN cable, WiFi) Leakstopper device Version without tank Flow control Controller Temperature sensor Power consumption heating/cooling model kW Pump capacity Nominal power 14 kW Refrigerant R-407c = Theoretical pump characteristic curve = Achievable practical values for permanent internal bypass taken into Nominal power 14 kW Refrigerant R-407c Nominal power 14 kW Refrigerant R-407c On request: for refrigerators, there is the option of adjusting the...

CLASSIC Cool TT-28’500 with heating

Level control Visual fault indications Acoustic warning Pressure regulation Profibus interface Profinet interface OPC-UA interface Web interface (LAN cable, WiFi) Leakstopper device Version without tank Flow control Controller Temperature sensor Power consumption heating/cooling model kW Pump capacity Nominal power 28 kW Refrigerant R-407c = Theoretical pump characteristic curve = Achievable practical values for permanent internal bypass taken into Nominal power 28 kW Refrigerant R-407c Nominal power 28 kW Refrigerant R-407c On request: for refrigerators, there is the option of adjusting the...

CLASSIC Cool TT-54’500 with heating ■ standard, □ optional, - not possible 1 included in MP-988 From mould Auto. water refill CLASSIC product overview cooling

Leakstopper device Level control Visual fault indications Acoustic warning Pressure regulation Profibus interface Profinet interface OPC-UA interface Web interface (LAN cable, WiFi) Version without tank Flow control Flow monitor Controller Temperature sensor Power consumption heating/cooling model kW Pump capacity = Theoretical pump characteristic curve with permanent internal bypass taken into account Nominal power 54 kW Refrigerant R-407c Nominal power 54 kW Refrigerant R-407c Nominal power 54 kW Refrigerant R-407c On request: for refrigerators, there is the option of adjusting the minimum...

CLASSIC Cool TT-108’000without heating CLASSIC product overvi

— = Theoretical pump characteristic curve with permanent internal bypass Nominal power 108 kW taken into account Refrigerant — R-407c — = R-134a Ambient temperature 10 °C Nominal power 108 kW Refrigerant R-407c — = R-134a Nominal power 108 kW Refrigerant — R-407c — = R-134a On request: for refrigerators, there is the option of adjusting the minimum operating temperature. The reference values depend on the installation and the conditions on site.

CLASSIC Cool TT-216’000without heating CLASSIC product overview cooling

Flow control Version without tank Leakstopper device Level control Visual fault indications Acoustic warning Pressure regulation Profibus interface Profinet interface OPC-UA interface Web interface (LAN cable, WiFi) Controller Temperature sensor Power consumption heating/cooling model kW Pump capacity = Theoretical pump characteristic curve with permanent internal bypass taken into account Nominal power 216 kW Refrigerant R-407c Nominal power 216 kW Refrigerant R-407c Nominal power 216 kW Refrigerant R-407c On request: for refrigerators, there is the option of adjusting the minimum operating...
