Product catalog summary

Overview: This document provides comprehensive specifications and guidelines for steel pipe adapters, focusing on SAE standards, working pressures, assembly instructions, and material specifications. It includes detailed information on various fittings such as elbows, tees, crosses, and adapters, along with their materials, pressure ratings, and assembly instructions.

Specifications: The document lists different types of pipe adapters, including street elbows, pipe elbows, pipe tees, branch tees, and pipe crosses, available in various sizes and materials like carbon steel, stainless steel, and brass. It provides thread sizes and configurations for each adapter type, as well as O-ring sizes and NPTF thread sizes with corresponding burst pressures.

Materials and Styles: Adapters are made from carbon steel, stainless steel (Type 316), and brass, with specific plating and chamfering details. Styles include barstock, forging, and chamfered ends. Ordering instructions specify prefixes for different materials and styles.

Pressure Ratings: Recommended working pressures for steel NPSM pipe swivel union hydraulic fittings are provided, following SAE standard J514. The document emphasizes testing for safety and performance, especially under elevated pressures or severe conditions.

Assembly Instructions: Detailed steps are provided for assembling NPTF dry seal pipes and NPSM swivel unions, including inspection, lubrication, and torque application. The document cautions against backing off installed fittings to avoid seal corruption and provides alternate assembly methods if torque application is not feasible.

Torque Values: Tables of torque values for different thread sizes ensure leak-free connections. The importance of using the correct torque to prevent thread deformation and maintain clamping force is stressed.

Standards and Recommendations: The document adheres to SAE J514 and J1453 standards for various fittings and recommends sufficient testing for performance assurance. It advises consulting technical support for guidance on part selection.

Additional Components: Information on JIC to flange connectors, elbows, split flange plugs, and quick disconnect couplings is included. Materials and sizes are specified for each component type.

Conclusion: This technical document serves as a comprehensive guide for selecting, assembling, and testing steel pipe adapters in accordance with SAE standards, ensuring safe and effective hydraulic system operations.

Catalog excerpts

37 Degree JIC Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1-32SAE O-Ring Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .33-38 Pipe Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .39-56 Pipe Swivel Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .57-66 O-Ring Face Seal Adapters . . . . . . . . . . . . . . . . . . . . . . . . . . . .67-82 Beaded Hose Fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .83-86 Flange Components . . . . . . . . . . . . . . . . . . . . . ....
