TMI Strip Door Catalogue

Product catalog summary

Introduction
Strip and swinging doors are cost-effective solutions for protecting against environmental conditions like noise, heat, cold, humidity, dust, and drafts. The document details various PVC materials and hardware products for industrial and commercial use.

RIP-A-STRIP Replacement Strips
The RIP-A-STRIP line offers "Ready-to-Hang" replacement strips, pre-cut and pre-punched for easy installation, available in sizes from 4'' to 16'' wide and up to 1/4'' thick.

PVC Materials
Standard flexible transparent PVC materials range from 4'' to 60'' in width and .040'' to .250'' in thickness. They are UV stabilized, compliant with the California Fire Marshal Code, and suitable for temperatures from -20°F to 150°F.

Specialty PVC Products
Specialty PVC products include anti-static, colored, and reinforced materials for specific applications like noise reduction and UV protection.

Material Requirements and Design
Guidelines are provided for determining PVC strip material needs based on door height, traffic type, and overlap patterns, with recommendations for strip width, thickness, and overlap percentage.

Physical Properties of PVC Materials
PVC materials are tested for thermal conductivity, noise reduction, and safety compliance, with data on tensile strength, tear resistance, and stiffness.

Conclusion
The document offers comprehensive information on PVC materials and hardware products, highlighting their benefits in enhancing safety, reducing maintenance, and improving environmental control.

Overview
The document details industrial door solutions and accessories by TMI, LLC, including specifications, mounting options, and materials for various doors and hardware.

1. Strip Door Hardware
Two types of Save-T Overhead Door Brackets are available: Heavy Duty for doors up to 24' wide and Standard Duty for doors up to 11' wide, with zinc plating. Mounting bars and hardware come in galvanized steel, stainless steel, and aluminum.

2. Sliding Track System
Accordion Strip Doors are designed for doorways with obstructions, reducing heating or cooling costs, featuring a nylon pull-rope and bi-parting panel options.

3. Mega-Pro™ Swinging Doors
Designed for interior applications with openings up to 10' wide, available in standard or USDA clear polar PVC, with optional impact plates and heavy-duty galvanized steel construction.

4. Polar-Pro™ Swinging Doors
Made of USDA Low Temp PVC for temperature-sensitive areas, featuring stainless steel hardware with a lifetime corrosion warranty, suitable for openings 34'' to 60'' wide and up to 96'' high.

5. Specialty Doors
Available in 6” and 8” wide PVC strip material for freezer applications to –30°F, with aluminum mounting hardware and brackets.

6. Dock Lights & Accessories
Dock lights with extensions from 24'' to 115'' and various light head options, including dock bumpers, parking blocks, speed bumps, and wheel chocks. The Auto Riser trailer stand complies with OSHA regulations with a static load capacity of up to 100,000 lbs.

7. Air Doors
Engineered to create an invisible wall separating environments, stabilizing temperatures, and saving energy costs, available with heating options like electric, steam, hot water, and gas-fired units.

8. Industrial Curtains & Enclosures
Softwall partitions contain environmental issues like dust and noise, with custom-made Weld Screens using PVC and galvanized square tubing frames.

Contact Information
TMI, LLC is located at 5350 Campbells Run Road, Pittsburgh, PA. Contact via phone at 412-787-9750 or email at [email protected].

Catalog excerpts

See OurExclusiveRIP-A-STRIPPVC Material& Save-T LOCHardware >

Open the catalog to page 1

RIP-A-STRIP is available in strip sizes from 4'' to 16'' wide,up to 1/4'' thick, and in lengths from 1 foot to 16 feet. Strips are 85% Pre-Cut withPre-Punched Hanger Holes The items listed below are in stock and readyto ship the same day the order is placed. >

Open the catalog to page 3

Both surfaces of the strip have ribsspaced 2 apart and are off-set by > 1 / > 2 Ԕ. Ribbed strips are ideal for heavytraffic strip doors because they signif- icantly reduce scratching, so the door remains clearer and safer. USDAmaterial is made of compoundsthat meet federal requirements for incidental contact with meat, poultry,and dairy products. This product is rec-ommended for indoorand outdoor appli-cations, in temperaturesranging from40ְFto 140F. Extra Low Temp. isavailable forapplications to Ж75F. Frosted PVC material offers a translu-cent quality that allows light transmis- sion but restricts...

Open the catalog to page 5

Wall Mount TrackConnector-Down Straight Track RT-16-8/10/20 WMTC-D-16 End Stop Wall Mount TrackConnector-Up ES-16 Straight SpliceConnector WMTC-U-16 SSC-16 End Stop ES-16 Double CeilingSupport/Splice Connector DCSSC-16 Sectional Hinged Trolleywith Nylon Wheels HT-16 > Model BP-WMModel OS-WMModel DT-HM > frame Bi-Parting Wall Mount One-Sided ֖ Wall Mount Double TrackHeader Mount > PVCStripRetaining BarStopPlateConnecting BarMounting BarSteel Wheel TrolleyNylon Pull-Rope & Handle Sliding Track >

Open the catalog to page 11

Mega-ProٙSwinging Doors are light industrial impact doors fordoorway openings up to 10' wide. This revolutionary door has aspring return and swings on an even plane. > Panels are available in either standard grade clear or USDAclear, polar PVC, in thicknesses up to > 9 Galvanized Steel Mounting Bracket / > 32 ''. Welded-on Impact Plates are optional. Galvanized SteelSwinging ArmGalvanized SteelAdjusting PlateGalvanized SteelTube Weldment TensionAdjustment Bar > Optional PVC WeldedImpact Platesavailable in5 different sizes Optional BreakawayHinge > All springs are made of chromevanadium andyou...

Open the catalog to page 12

are engineered to create an invisi-ble wall that separates environments. Not only does it stabilize work area temperatures, but it saves on expensive energy costs.Air Doors provide year round comfort forcustomers and employees. Our Industrial Air Doors are used for both interior or exte- rior doorways at plants and warehouses and we have heating options available.All Commercial and Industrial Series Air Doorshave heating options. Although electric heaters are the most popular, steam, hot water and gas-fired units are available. > Softwall partitions are the most inexpensive solution to contain...
