A SSttaaiinnlleessss SStteeeell Aiirr CCuurrttaaiinn ffoorr EEvveerryy Buuddggeett Managing Environments™ Revolutionary Air Curtain with AERODYNAMIC Compression Chamb e r Generating “COANDA EFF ECT ” Air Movement

Page 1 . . . . . . . . . . . . Cover 2 . . . . . . . . . . . . Table of Contents 3 . . . . . . . . . . . . Making a Save-T Air Curtain 3 . . . . . . . . . . . . How a Save-T Air Curtain Works 4 . . . . . . . . . . . . When to Use a Save-T Air Curtain 4 . . . . . . . . . . . . Application Selection Guide 4 . . . . . . . . . . . . Choosing Your Model 5 . . . . . . . . . . . . Matching Your Doorway Opening with a Save-T Air Curtain 6 . . . . . . . . . . . . A Guide to Energy Saving – Return on Investment 6 . . . . . . . . . . . . Activation Devices 7 . . . . . . . . . . . . Mounting Options 8...

3 The Save-T Air Curtain is mounted above a doorway opening, just above the header. Ambient air is drawn through the front intake grill (A) and into the fan baskets (B). The blower wheel (C), forces the air into an air chamber (D) and the air is forced downward through the discharge nozzle (E). An invisible “wall of air” is created that serves as the barrier preventing conditioned air from leaving the building and blocking outside air from entering, even when there is no primary door in place. Heaters (see Optional Equipment & Accessories, pgs. 26 & 27) can be added to the units so that a...

If your application is . . . . . . . . . . . . . . . . then you should use these Save-T Air Curtain models Climate and Environment Control Insect and Wind Control Drive-Thru Windows and Concession Stands Office and Employee Entrances Interoffice and Commercial Separation Hospital Entrances and Hallways Retail and Customer Entrances Restaurant and Food Service Entrances Restaurant and Food Service Back Doors Hotel, Resort, and Casino Entrances Hotel, Resort, and Casino Back Doors Loading Docks Internal Warehouse Openings Shipping and Receiving Doors Auto Body and Open Bays Paint Booths...

TMI, LLC offers the largest selection of Save-T Air Curtains in the industry. Air Curtains can satisfy nearly every application requirement. The chart below shows maximum doorway heights and widths for each of our units. 5 Recommended Maximum Height for Flying Insect Control Recommended Maximum Height for Flying Insect Control Recommended Maximum Height for Flying Insect Control Reeccoommeennddeedd ffoorr FFllyyiinngg IInnsseecctt CCoonnttrrooll Recommended Maximum Height for Flying Insect Control S-AP See Pages 10-11 S-XHD See Pages 24-25 EXTRA HEAVY DUTY SERIES HEAVY DUTY SERIES AIR-PRO...

6 AIR CURTAIN JUSTIFICATION ANALYSIS Please allow TMI’s engineering department to provide state-of-the-art, computer-generated energy saving calculations. Cost savings will be stated in years of payback and can be calculated for both heated buildings or air conditioned applications. The following information is required: Heating Example Door height Feet 10 Door width Feet 10 Avg. outside temp. °F 32 Avg. inside temp. °F 65 Avg. wind speed @ door MPH 10 Open time/day HRS/Day 5 Days of operation/week Days 5 Length of season Weeks 26 Cost of heat $/MMBTU 4.25 Cost of electricity $/KW HR .07...

How the Air Curtain is mounted depends on your doorway opening and what equipment or obstructions are in the way. If none of the methods shown below suit your application, please call us at 1-800-888-9750. Our engineers will provide solutions to your mounting problems. Standard Wall Mount Mounting Plate (Optional) Note: A Mounting Plate is standard equipment with the Air-Pro Unit and is the only method of mounting. Wall Mounting Brackets * Threaded Rods provided by others. Ceiling Mount with Threaded Rods* Extension Plates with Threaded Rods* on Standard Overhead Door Extension Bars...

8 SIZES 72'' 84'' 60'' 36'' 96'' 108'' 120'' 48'' 42'' FEATURES • 1/2 horsepower, 2-speed motors • One-piece construction • Unit is concealed in the ceiling, flush with ceiling panels • Hinged service panel for cleaning and service • Aesthetically pleasing white or stainless steel finish blends with traditional drop ceilings (optional custom colors available) • Includes filters for improved air quality • Exceptionally low noise levels (51 dBA low speed) • No additional duct work or nozzle extension required • Electric, hot water, or steam heat optional • Single-phase or three-phase power •...

AIR-PRO SERIES – S-AP For interior mounting only with door heights up to 7' SIZES 72'' 60'' 36'' 42'' 48'' FEATURES AIR-PRO SERIES – S-AP MODEL AP-2-36-1-SS AP-2-42-1-SS AP-2-48-1-SS AP-2-60-1-SS AP-4-72-2-SS Nozzle Width (in.) 34.50 38.50 46.25 58.00 69.50 Diameter of Wheel (in.) 5.5 5.5 5.5 5.5 5.5 Voltage 110-120 110-120 110-120 110-120 110-120 Frequency (Hz) 60 60 60 60 60 Net Weight. (lbs.) 43 47 62 75 86 No. of Motor(s) 1 1 1 1 2 Motor Speeds High Low High Low High Low High Low High Low Capacity (kw) .500 .495 .650 .645 .650 .645 .800 .795 1.00 0.99 Maximum Air Speed (fpm) 3150 2560...

A I H B J C B D E G F S-AP DIMENSIONS CHART Model A B C D E F G H I J AP-2-36-1-SS 35.5'' 1.0'' 11.5 '' 22 '' — 2'' 5.75'' 10'' 8.5'' 5'' AP-2-42-1-SS 39.5'' 1.0'' 11.5'' 22 '' — 2'' 5.75'' 10'' 8.5'' 5'' AP-2-48-1-SS 47.25'' 1.0'' 17.0 '' 28'' 17.5'' 2'' 5.75'' 10'' 8.5'' 5'' AP-2-60-1-SS 59'' 1.0'' 22.5'' 33.5'' 22.5'' 2'' 5.75'' 10'' 8.5'' 5'' AP-2-72-2-SS 69.5'' 1.5'' 22.0'' 46.0'' 22.0'' 2'' 5.75'' 10'' 8.5'' 5'' Stainless Steel Intake Grill Aluminum Blower Wheels Stainless Steel Mounting Plate Stainless Steel Housing • • • • STANDARD EQUIPMENT Easy Adjustments An Automatic Door...

12 FEATURES • 1/2 horsepower, 2-speed motors • Aluminized steel, one-piece construction • Unmatched air flow uniformity • Optional filters for improved air quality • Exceptionally low noise levels (53/51 dBA) • Electric, hot water, or steam heat optional • Single-phase or three-phase power • Two-year parts warranty for unheated units (18 months for heated units) For environmental control up to 10’ high COMMERCIAL FRONT DOOR SERIES – S-CFD APPLICATIONS • Climate and Environmental Control • Office and Employee Entrances • Interoffice and Commercial Separation • Hospital Entrances and Hallways...
