OG7 500L/Min Oval Gear Meter
1 / 2Pages

TECHNICAL PRODUCT DATA SHEET Ilian OG7 500L/Min Oval Gear Meter FLOW, The rugged OG7 oval gear flowmeter is designed to give high performance with a low cost of ownership. It has a standard flow range from 5.0 to 500 L/min on 30 cSt oil and 20 to 500 L/min on water-like liquids. The standard inlet and outlet are 2” female threads. For OEMs, alternatives are available, including manifold mountings. The standard model is 316 St St with Viton™ ‘O’ ring seals. At the heart of the meter are a pair of toothed oval gears one of which contains chemically resistant magnets. Rotation is detected through the chamber wall by a Hall effect detector or a reed switch giving approximately 15 pulses per litre passed. The output is an NPN pulse or a voltage free contact closure either of which is readily interfaced with most electronic display or recording devices. This combination of materials and technology ensures a long life product with reliable, accurate operation throughout. • Engine test • High viscosity liquids • Hazardous areas Titan Enterprises Oval Gear Pressure Drop Information • Excellent chemical resistance • Rugged construction • Individual calibration • No flow conditioning required • Hall, reed switch or Namur sensor • Accuracy 1.0% reading water % Max Flow of Oval Gear Meter

OG7 500L/Min Oval Gear Meter TECHNICAL SPECIFICATIONS Sample product codes Stainless standard OG7-SS5-VHD-B Flow range – Water 20 - 500 L/min – 30 cSt Oil 5.0 - 500 L/min Wetted materials – Body 316 St St – Gears Carbon filled PEEK – Seal Viton™ – Magnet PTFE - Spindles St St Ordering Codes – Water ±1.0% Reading – 30 cSt oil ± 0.5% Reading Model OG7 Body Material S = 316 St St 50 bar std Temp Rating S = 80°C / 158°F T = 100°C / 212°F U = 150°C / 300°F Pressure Rating 5 = 50 bar 750 PSI (St St) Seal Material V = Viton™ N = Nitrile E = EPDM K = Kalrez® Detector Type H = Hall effect R = Reed...
