TL13
5Pages

Catalog excerpts

Product Segments TiMOTION’s TL13 series lifting columns are specifically designed for use in • Ergo Motion with compatible TC series Control Boxes and TH/TDH series controls, work ergonomic desks and work tables. Using multiple TL series lifting columns surfaces can be controlled quietly and smoothly with synchronous movement. All Ergo Motion TC series control boxes have a less than 0.1W standby power option that reduces power consumption. Our wide range of columns offer customers the solutions they require to satisfy their working environment project requirements. The TL13 has a two stage telescopic outer tube that is designed for a narrow-top, wide-bottom square appearance. General Features Max. load Retracted length Dimension of outer tube

Open the catalog to page 1

Standard Dimensions 36 70 183 Stroke + Retracted Length Retracted Length Load and Speed CODE Self Locking Force (N) Typical Current (A) With Load 24V DC Note 1 Above self lock performance needs working with Timotion control system. 2 Parameters above are from tested average, please refer to approval drawing for final value.

Open the catalog to page 2

Motor Speed (5200RPM) Speed vs. Load 55 Performance Data (24V DC Motor) Note 1 The performance data in the curve charts shows theoretical value.

Open the catalog to page 3

C = Without wiper fixing holes at sides Stroke & Retracted Length (mm) 1 = Black, RAL 9005, black wiper 2 = Grey, RAL 9006, black wiper 3 = White, RAL 9016, black wiper 4 = Special grey, RAL 9022, black wiper 6 = Grey, RAL 9006, grey wiper Motor Housing Step Output Signals 1 = DIN 6P, 90° plug E = Molex 8P, 180° plug, standard 7 = White, RAL 9016, white wiper 8 = Special grey, RAL 9022, grey wiper B = Matte black, RAL 7021, Black wiper C = Graphite grey, RAL7024, Black wiper D = Matte black, RAL 7021, Matte Black wiper F = Molex 8P, 90° plug, without anti-clip, for TC22/TC23 Note 1 The TL...

Open the catalog to page 4

TL13 Ordering Key Appendix Stroke & Retracted Length (mm) Foot Assembly Stroke & Retracted Length Foot Assembly Standard, with foot Note 1 Only specific TEK could be with the shoes, please refer to TEK speccode Retracted length Extended Outer Tube for Shoe (Excluding Shoe) Retracted length Standard, with Foot Extended outer tube for shoe (excluding shoe) E = Molex 8P, 180° plug, standard F = olex 8P, 90° plug, without antiM clip, for TC22/TC23 Terms of Use The user is responsible for determining the suitability of TiMOTION products for a specific application. TiMOTION products are subject...
