TA2
10Pages

Catalog excerpts

Product Segments • Industrial Motion TiMOTION’s TA2 series linear actuator is compact, robust and capable of performing well in certain outdoor environments. This linear actuator is perfect for use in small spaces where force or capability cannot be sacrificed. Options include feedback sensors, signal sending limit switches and 90 degree clevis mounting. Industry certifications for the TA2 linear actuator include IEC606011, ES60601-1, and EMC. General Features Max. load Retracted length ≥ Stroke + 105mm (without output signals) POT, Reed, Hall sensors Color Silver Operational temperature range Operational temperature range at full performance Compact size for lim

Open the catalog to page 1

Dimensions without Output Signals (mm) Dimensions with Output Signals

Open the catalog to page 2

Load and Speed CODE Self Locking Force (N) Motor Speed (4200RPM, duty cycle 25%) A Motor Speed (6000RPM, duty cycle 25%) F Note 1 lease refer to the approved drawing for the final authentic value. P 2 This self-locking force level is reached only when a short circuit is applied on the terminals of the motor. All the TiMOTION control boxes have this feature built-in. 3 The current & speed in table are tested with 24V DC motor. With a 12V DC motor, the current is approximately twice the current measured in 24V DC. With a 36V DC motor, the current is approximately two-thirds the current...

Open the catalog to page 3

Motor Speed (4200RPM, duty cycle 25%) Speed vs. Load 80.0 70.0 60.0

Open the catalog to page 4

Motor Speed ((6000RPM, duty cycle 25%) Speed vs. Load 80.0 70.0 60.0 F

Open the catalog to page 5

Rear Attachment (mm) See page 8 1 = luminum casting, without slot, hole 6.4, one piece 4 = luminum casting, U clevis, slot 6.0, depth 10.5, hole A A casting with gear box 6.4, one piece casting with gear box 2 = luminum casting, without slot, hole 8.0, one piece 5 = luminum casting, U clevis, slot 6.0, depth 10.5, hole A A casting with gear box 8.0, one piece casting with gear box 3 = luminum casting, without slot, hole 10.0, one piece 6 = luminum casting, U clevis, slot 6.0, depth 10.5, hole A A casting with gear box 10.0, one piece casting with gear box Front Attachment (mm) See page 9 1...

Open the catalog to page 6

TA2 Ordering Key Appendix Retracted Length (mm) 1. Calculate A+B+C = Y 2. Retracted length needs to ≥ Stroke + Y A. Rear / Front Attachment Front Attachment

Open the catalog to page 7

TA2 Ordering Key Appendix Voltage 5 = 24V DC, PTC 4 = luminum casting, U clevis, slot A 6.0, width 10.5, hole 6.4, one piece casting with gear box 3 = luminum casting, without slot, A hole 10.0, one piece casting with gear box 2 = luminum casting, without slot, A hole 8.0, one piece casting with gear box 1 = luminum casting, without slot, A hole 6.4, one piece casting with gear box 5 = luminum casting, U clevis, slot A 6.0, width 10.5, hole 8.0, one piece casting with gear box 6 = luminum casting, U clevis, slot A 6.0, width 10.5, hole 10.0, one piece casting with gear box

Open the catalog to page 8

TA2 Ordering Key Appendix Front Attachment (mm) 1 = luminum casting, without slot, A hole 6.4 2 = luminum casting, without slot, A hole 8.0 6 = Aluminum casting, without slot, 3 = luminum CNC, U clevis, slot 6.0, A depth 16.0, hole 10.0 ø10 4 = luminum CNC, U clevis, slot 6.0, A depth 16.0, hole 6.4 5 = luminum CNC, U clevis, slot 6.0, A depth 16.0, hole 8.0 Direction of Rear Attachment (Counterclockwise) 1 = 90° Functions for Limit Switches Wire Definitions CODE extend (VDC+) retract (VDC+) extend (VDC+) retract (VDC+) extend (VDC+) upper limit switch retract (VDC+) lower limit switch...

Open the catalog to page 9

TA2 Ordering Key Appendix Connector 1 = DIN 6P, 90° plug Terms of Use The user is responsible for determining the suitability of TiMOTION products for a specific application. TiMOTION products are subject to change without prior notice.
