MA2
7Pages

Catalog excerpts

Product Segments • Industrial Motion TiMOTION’s MA2 series electric linear actuator was specifically designed for applications that face harsh working environments and require heavy-duty and durability. Its IP69K protection ensures it will withstand high-pressure water jets and the ingress of dust and other solid contaminants. The MA2 electric cylinder actuator also has optional Reed switches along the outer tube which allow users to adjust the stroke length. For improved control and accuracy of motion, the MA2 can be customized with many different feedback options depending on your application requirements. Example applications suitable for the MA2: Agricultural equipment such as spreaders, harvesters, grain handlers, combines, and tractors. Commercial and industrial applications such as commercial lawn mowers, scrubbers and sweepers, material handling equipment and livestock ventilation systems. General Features Max. load 8,000N (push); 6,000N (pull) Max. speed at max. load 5.5mm/s Max. speed at no load 52.5mm/s Retracted length ≥ Stroke + 131mm IP rating IP69K Certificate UL73, EMC Stroke 25~1000mm Output Signals Hall sensors, POT, Reed sensor on the outer tube Voltage 12 / 24 / 36 / 48V DC; 12 / 24 / 36 / 48V DC (thermal control) Operational temperature range -30˚C~+65˚C Operational temperature range +5˚C~+45˚C at full performance Manual

Open the catalog to page 1

Standard Dimensions Load and Speed CODE Self Lock (N) Duty Cycle Motor brake Note 1 Please refer to the approved drawing for the final authentic value. 2 This self-locking force level is reached only when a short circuit is applied on the terminals of the motor. All the TiMOTION control boxes have this feature built-in. 3 The current & speed in table are tested with 24V DC motor. With a 12V DC motor, the current is approximately twice the current measured in 24V DC. With a 36V DC motor, the current is approximately two-thirds the current measured in 24V DC. Speed will be similar for all...

Open the catalog to page 2

Motor Speed (5200RPM) Speed vs. Load 60.0 Performance Data (24V DC Motor)

Open the catalog to page 3

Rear Attachment (mm) See page 6 1 = luminum casting, clevis U, slot 8.2, depth 12.5, hole 10.2 A 2 = luminum casting, clevis U, slot 8.2, depth 15.0, hole 10.2 A 3 = luminum casting, clevis U, slot 8.2, depth 15.0, hole 12.8 A 4 = luminum casting, clevis U, slot 8.2, depth 15.0, hole 12.2 A Front Attachment (mm) See page 6 1 = ron inner tube with punched hole, without slot, hole 10.2 I 2 = ron inner tube with punched hole, without slot, hole 12.2 I 3 = ron inner tube with punched hole, without slot, hole 12.8 I 4 = luminum casting, clevis U, slot 8.2, depth 15.0, hole 10.2 A 5 = luminum...

Open the catalog to page 4

MA2 Ordering Key Appendix Retracted Length (mm) 1. Calculate A+B+C = Y 2. Retracted length needs to ≥ Stroke + Y A. Rear/ Front Attachment Front Attachment Rear Attachment

Open the catalog to page 5

MA2 Ordering Key Appendix Rear Attachment (mm) 2 = luminum casting, clevis U, slot A 8.2, depth 15.0, hole 10.2 4 = luminum casting, clevis U, slot A 8.2, depth 15.0, hole 12.2 3 = luminum casting, clevis U, slot A 8.2, depth 15.0, hole 12.8 1 = luminum casting, clevis U, slot A 8.2, depth 12.5, hole 10.2 4 = luminum casting, clevis U, slot A 8.2, depth 15.0, hole 10.2 ø28 3 = ron inner tube with punched I hole, without slot, hole 12.8 2 = ron inner tube with punched I hole, without slot, hole 12.2 1 = inner tube with punched Iron hole, without slot, hole 10.2 6 = luminum casting, clevis U,...

Open the catalog to page 6

MA2 Ordering Key Appendix Direction of Rear Attachment (Counterclockwise) 1 = 90° Connector 2 = Tinned leads Terms of Use The user is responsible for determining the suitability of TiMOTION products for a specific application. TiMOTION products are subject to change without prior notice.
