Model TLS-S II Series Full-automatic Dual Digital Display Spring Tension & Compression Testing Machine ISO9001 International Quality CertificateApplication It is suitable for the test of all precision extension & compression springs and testing fragile materials. > oooo TLS-S II Series Automatic Dual Digital Display Ten-sion & Compression Testing Machine is a new spring test-ing instrument, which uses several advanced technolo- gies so as to further improve the test accuracy and ensure the testing efficiency. The test load is divided into 3 grades so that the measuring range is expanded. The...

50kN, 100kN, 150 kN 1% (within 4-100% of max test load) 1% (within 4-100% of max test load)0.05% of each full range0.01mm1000mm300mm (50 0.15L)um40 ~ 400mm/min380V 10% TYD-50/100/150 Item Names CapacityRelative error of test load indicationsRelative error of repeatability of test loadMin. reading of test loadMin. reading of displacement Effective testing spaceDiameter of compression plateError of displacement indicationsLoading speedPower supply (must be connected to the earth) >

Model TYE-W Series Micro-computer Display Hydraulic Spring Compression Testing MachineISO9001 International Quality Certificate Main Applications: > TYE-W300/500 The tester is PLC controlled and hydraulic loaded, and uses high precision transducer to measure the load anddisplacement. The test space is adjustable as per demand. The operation platform is automatic and therefore the workpiece is convenient to be mounted. Computer displays the test load, deformation and characteristics curve of springs and the auto-processing software is adopted to collect data and process the data automatically....

Model TYQ Series Pneumatic Spring Compression Testing MachineISO9001 International Quality Certificate Application and features: > Model TYQ-10IModel TYQ-10 Application and features: Model TYQ-10I testing machines use pneumatic load-ing mode and have quick loading speed. There are pre- load position and test position: At pre-load position, there is no load value indication, and it is only for the pre-com- pression of spring. Pre-compress once to the max load condition; At the test position, Red and Green light are used to show the qualification of spring. Both cylinders work synchronously. The...

Model TYW series Micro-computer Controlled Spring Compression Testing Machine ISO9001 International Quality Certificate Main applications: > TYW-50TYW-100/150 This kind of machine is mainly suitable for testing intensity & other properties of big precision coil springs and leafsprings. It is widely used at railway industry, chemical industry, mineral enterprises and scientific research institutes, and so on. Main Features: The software consists of function modules such as dynamic communication, speed control, parameter input, dataprocessor, result observation, record retrieval, chart display...

Model TPG Series Spring High-frequency Fatigue Testing MachineISO9001 International Quality Certificate Main Applications: > TPG-1000/2000/3000 This kind of machine adopts the theory of electromagnetic excitation and specimen (spring) resonance.The system is kept in the best resonance condition automatically, and without any adjustment. The machine starts quickly with stable and reliable performances. It is very easy to operate and operators need not to be trained. The tester also has functions of digital display of vibration times and frequency, pre-set times, auto stop at break and auto store...

Model QTW Series Micro-processor Controlled Testing Machine for Gas SpringsISO9001 International Quality Certificate Main Applications: > QTW-5000/10000/20000 The machine uses Panasonic Digital AC Servo Motor and precision ball screw counter drive With highmeasuring accuracy, it is equably, stable and non-impact when loading. It is mainly used for testing prosperities of various gas springs. Features: Function: Window Operation Interface, screen display of testing load, compressibility of gas spring, loadingspeed, load-displacement curve, and so on. Data processing: Computer will process all...

Model TFY Series Spring Load Sorting MachineISO9001 International Quality Certificate Main Applications: > TFY-1000/2000 This kind of machine is a spring measuring instrument synchronously used in spring production lines. It oooo o sapplicable for the final test of heat-treated springs. It is mainly used to sort as per the heights after pre-loadingand compression and also to sort as per the test load of springs. It is an essential equipment for quick testing ofsprings. Applicable Spring Specifications: Outer Diameter of Spring: 50mmFree length of spring: 80mmSpring load: 100N-1000N / 200N-2000N...

XLN-200 Testing Machine for RivetingIntensity of Washer Geared Clutch YSJ-10 Digital Display Corner Intensity Testing Machine for plastic materials and plastic doors & windows HYS-S Series Dual Digital DisplayPiston Ring Compression Testing Machine LNS-Through Flow Wind-wheelTension & Torsion Testing Machine Model HTS-200Piston Ring Elasticity Testing Machine XLW-100 Micro-computer Controlled Locknut Torsion Testing Machine ZYS Series - Digital Display Paper TubeTension Testing Machine Model PQC - Car CurtainFatigue Testing Machine XLL-20 Testing Machine for Brake Torqueof Washer Geared Clutch...
