Product catalog summary

Specifications and Features:

Fitting space recommendations vary by product line: 19 mm, 25.6 mm, and 13.3 mm per slide.
Recommended screws: Outer profiles use countersunk screws; inner profiles use either panhead or countersunk screws based on the product.
All products are zinc plated (Blue) with a 32 mm hole pattern.

Product Lines:

Stock Item 4608: Available in various lengths with load capacities from 33 kg to 50 kg per pair for 50,000 cycles. Features include a bumper with hold closed, disconnect of inner profile, and adjustable side space tabs.
Condor: Offers lengths from 300 mm to 900 mm with load capacities up to 100 kg per pair for 10,000 cycles. Includes a bumper with hold closed and lock-in mechanism.
SOLAR S: Features a soft-close system with load capacities up to 60 kg per pair for 10,000 cycles. A minimum order of 250 pairs is required for some items.
ULF HD S: Includes a soft-close system with load capacities up to 75 kg per pair for 10,000 cycles.

Contact Information: For special requests, contact Thomas Regout International B.V. at Industrieweg 19, 6287 NR Maastricht, The Netherlands. Email: [email protected], Phone: 0031 (0) 43 351 6666.

Catalog excerpts

Stock Item TELESCOPIC SLIDES STOCK ITEM RANGE

Open the catalog to page 1

Stock Item ADO Article number L / T (mm) L/T (inches) Load capacity 100.000 Cycles kg/pr (lbs/pr) Load capacity 10.000 Cycles kg/pr (lbs/pr) Packaging Pair 105044 300/223,5 11,81/8,80 Vertical Side mounted 70 (154) Horizontal Bottom mounted 45 (99) Vertical Side mounted 91 (200) Horizontal Bottom mounted 58 (127) 13 Features Bumper without hold closed Zinc plated (Blue) Recommended fitting space: 22 mm per slide Recommended screws: Outer profile: Countersunk Inner profile: panhead Please contact our sales department for special requests Contact Thomas Regout International B.V. Industrieweg 19...

Open the catalog to page 6

Stock Item Finn Double Article number L / T (mm) L/T (inches) Load capacity 100.000 Cycles kg/pr (lbs/pr) Load capacity 10.000 Cycles kg/pr (lbs/pr) Packaging Pair 117270 315/395 12,40/15,55 Vertical Side mounted 40 (88) Horizontal Bottom mounted 25 (55) Vertical Side mounted 52 (114) Horizontal Bottom mounted 32 (70) 10 Features Bumper with hold closed Zinc plated (Blue) Recommended fitting space: 27,5 mm per slide Recommended screws: countersunk Please contact our sales department for special requests Contact Thomas Regout International B.V. Industrieweg 19 6287 NR Maastricht (The Netherlands)...

Open the catalog to page 7

Stock Item SOLAR S Article numer L T A B C D F G H 103R92 350* 333* 64 128 32 45 128 234 103R93 400 400 32 32 192 32 45 92 288 103R94 450* 450* 32 32 256 32 45 160 352 103R95 500 504 32 32 288 32 45 192 384 Article number L / T (mm) L/T (inches) Load capacity 100.000 Cycles kg/pr (lbs/pr) Load capacity 10.000 Cycles kg/pr (lbs/pr) Packaging Pair 103R92* 350/333* 13,77/13,07 38 45 14 103R93 400/400 15,75/15,75 45 55 12 103R94* 450/450* 17,72/17,72 60 60 7 103R95 500/504 19,68/19,84 60 60 7 Features Soft-Close system 32 mm hole pattern Zinc plated (Blue) Packed per pair in shrink wrapped foil Recommended...
