Turbo-J Condensers

Turbo-J Condensers

Product catalog summary

Introduction
The Turbo-J series by Thermokey is a line of double coil condensers designed for industrial refrigeration and air conditioning, compatible with eco-friendly refrigerants. They offer capacities from 100 kW to 1915 kW under nominal conditions as per ENV 327 Norm.

Specifications
The series features high-efficiency aluminum fins, 3/8” copper tubes with inner corrugation, and new fans for high airflow with reduced energy consumption and low noise. The modular design includes a galvanized steel housing painted in RAL 7035, accommodating up to sixteen 900 mm fans with eight sound power levels.

Customizations
Customizations include speed controllers, wiring options, and special materials for various applications. An optional adiabatic system, AFS, maintains performance at higher air temperatures.

Order Code
The order code specifies product series, fan diameter, number of fans per row, sound level, capacity level, shock absorbers, fan-motor connection, wiring, speed controller type, and number of separate circuits.

Selection Procedure
Capacities are based on ENV 327 standards with specific conditions: air inlet temperature of 25°C, condensing temperature of 40°C, and refrigerant R404A. For different conditions, the Archimede selection software or a provided formula should be used.

Performance Data
Performance data includes model type, capacity, air flow, noise level, fan-motor specifications, surface area, tube volume, weight, and connection sizes, crucial for selecting the appropriate condenser model.

Overview
The document details specifications and technical data for the Turbo-J Condensers, including model types, capacities, air flow, noise levels, fan motors, surface area, tube volume, weight, and connection sizes.

Technical Drawings
Technical drawings with dimensions for various models indicate the layout and size of the condensers.

Sound Levels
Sound levels are detailed with Lw sound power levels in octave bands, and adjustments for different numbers of fans are provided. Sound pressure levels are calculated according to EN 13487/EN ISO 3744 standards.

Additional Information
Thermokey reserves the right to modify product specifications without prior notice. Contact information for Thermokey is provided, including address, phone number, and website.

Catalog excerpts

TURBO-J > From Thermokeys R&D experience ғTurbo-J, an innovative series of double coil condensers, has come into being. This new series is capable of fully satisfying the needs of industrial refrigeration and air - conditioning operators. The new Turbo-J series has been designed, in order to be used with all environment-friendly refrigerants. The capacities of this series range from 100 kW to 1915 kW measured at nominal conditions (ENV 327 Norm). The extraordinary performance of these condensers is the result of an optimal combination of new high-efficiency aluminium fins, 3/8Ԕ copper tubes with...

Open the catalog to page 2

CONDENSERS > Aus der Erfahrung von THERMOKEY R&D wurde Turbo-JӔ Serie geboren. Es ist eine innovative Serie von V-frmigen Verflssigern, die speziell in den gr漶eren Leistungsbereichen (Industrie- und Klimaanwendungen) die Anforderungen des Markets erf߼llen knnen. Die neue Turbo-J series kann mit allen umweltfreundlichen Kltemittlen verwendet werden. Das Leistungsspektrum der neuen Serie reicht von 100 kW bis zu 1915 kW bei Normenbedingungen (nach ENV 327). Die Sonderleistungsf椤higkeit dieser Verflssiger entsteht aus der optimalen Zusammenstellung von den neuen Hochleistungslamellen aus Aluminium...

Open the catalog to page 3

The capacities indicated in the catalogue are stated in accordance with the ENV 327 standards taking into consideration the following working conditions: Air inlet temperature T > 1 : 25CCondensing temperature T > 1 : 25аCKondensationstemperatur T Δ T > c : 40CRefrigerant R404A Ў T > c : 40԰CKltemittel R404A > 1 (T > c T > 1 ) : 15 KThe capacities indicated in the catalogue are referred to the working with cleaned coil. For other conditions please use Archimede selection software or the following formula:Le potenze indicate a catalogo sono espresse in accordo alle norme ENV 327, considerando...

Open the catalog to page 5

THERMOKEY reserves the right to modify the products contents in this catalogue without previous notice. - THERMOKEY si riserva il diritto di apportare modifiche e migliorie ai prodotti a catalogo in qualsiasi momento e senza preavviso.THERMOKEY behaltet sich das Recht vor, die Produkte dieses Katalogs ohne vorherige Ankndigung zu verndern. - THERMOKEY se reserve le droit de modifier les produits de ce catalogue sans avis pr줩able. THERMOKEY SPA - VIA DELLINDUSTRIA 1 - 33050 RIVAROTTA DI TEOR - UDINE - ITALY - TEL. +39 0432772300 FAX +39 0432 779734 - WWW.THERMOKEY.COM - [email protected] THERMOKEY...

Open the catalog to page 12
