THERMOKEY
Light Cubic Unit Coolers

Light Cubic Unit Coolers

Product catalog summary

Overview
Thermokey introduces a new series of direct expansion unit coolers, designed for small and medium cold rooms for storing fresh or frozen goods. The series includes PH and PM models, differentiated by fin spacing and temperature range suitability.

Specifications

PH Series: Fin spacing of 4.0 mm, suitable for temperatures between 15°C and 2°C.
PM Series: Fin spacing of 6.0 mm, suitable for temperatures between 2°C and -20°C.
Heat exchanger coils feature high-efficiency corrugated 'TK' aluminum fins and ½” diameter internally grooved copper tubes.
Casing made from RAL 9010 painted galvanized steel with ABS thermoplastic resin parts.
Single-phase 230V-50/60Hz fan motors with IP54 protection and internal thermal contact.
Available fan diameters: Ø300, Ø350, Ø400, and Ø450 mm, with 1 to 4 fans per diameter.
Optional features include electrical defrosting systems and three-phase 400V-50/60Hz fan motors.

Order Code Explanation
The order code for the unit coolers includes information on model type, fin spacing, fan diameter, number of fans, fan motor type, defrosting system, operation system, refrigerant connections, and number of rows.

Selection Procedure
Standard conditions are defined according to ENV 328, with nominal capacities related to specific air inlet and evaporating temperatures. Two selection methods are provided: a mathematical approach using a table (TAB. 1) and a software-based approach using Archimede selection software.

Example Calculation
For a required capacity of 12 kW at a cold room temperature of -20°C and a temperature difference of 7 K using R404A refrigerant and electrical defrosting, the nominal capacity is calculated to be 15.2 kW, corresponding to model PM 340.66 D6 E M.

Technical Data
Detailed tables provide information on model capacities, air flow, surface area, air throw, fan motor specifications, defrosting options, noise levels, connections, tube volume, and net weight for both PH and PM series.

Dimensions
Technical drawings and dimensions are provided for various models, detailing measurements such as length (A), width (B), height (H), and other critical dimensions.

Note
Thermokey reserves the right to modify product specifications without prior notice.

Catalog excerpts

LIGHT CUBIC UNIT COOLERS >

Open the catalog to page 1

Thermokey presents a new direct expansion unit coolers series designed for small and medium cold rooms for storage of fresh or frozen goods. PH series fin spacing 4,0 mm for temperatures 15 2C PM series fin spacing 6,0 mm for temperatures 2 簷 -20CThe heat exchanger coil is produced using a new geometry designed specifically for refrigeration, with high efficiency corrugated surface ГTK aluminium fins and Խ diameter copper tubes internally grooved. The casing is made in RAL 9010 painted galvanized steel with some parts in ABS thermoplastic resin. All models use single-phase 230V-50/60Hz fan motors...

Open the catalog to page 2

Rows numberNumero ranghi > Operation system - Sistema di funzionamento: D = > Direct expansion - Espansione diretta Refrigerant connections - Attacchi frigoriferi:6 = Left - Sinistro Defrosting system - Sistema di sbrinamento:A = > Air - Ad aria E = Electric - Elettrico Fin-spacing (mm)Passo alette (mm)Fans diameter (cm)Diametro ventilatori (cm) Number of fansNumero di ventilatoriModel - ModelloPH Fan motor type - Tipo motore:M = > Single-phase - Monofase T = Three-phase - Trifase >

Open the catalog to page 3

For different operating conditions two selection methods are supplied: one is mathematical by using the table ( TAB. 1 places the inlet air temperature T TAB. 1 ), the other one is by using Archimede selection software. - > 1 (corresponding to the temperature of the cold room) in relation to the Δ T > 1 at which the unit cooler is required to work.- The selection software Archimede enables to select the right unit to be used.Per condizioni di funzionamento differenti vengono forniti due metodi di selezione alternativi: uno matematico con luso della tabella ( TAB. 1 ) e uno informatico, utilizzando...

Open the catalog to page 5

LIGHT CUBIC PH PM SERIES >

Open the catalog to page 6

UNIT COOLERS SERIE PH PM >

Open the catalog to page 7

ModelModelloA (mm)B (mm)H (mm)P (mm)C (mm)D (mm) P_130._ _ 932588429531416300 P_135._ _ 932588479559416350 P_140._ _ 1132788531646502400 P_145._ _ 1132788681646502450 > ModelModelloA (mm)B (mm)H (mm)P (mm)C (mm)D (mm) P_230._ _ 14821138429531416300 P_235._ _ 14821138479559416350 P_240._ _ 18821538531646502400 P_245._ _ 18821538681646502450 > ModelModelloA (mm)B (mm)H (mm)P (mm)C (mm)D (mm) P_330._ _ 20321688429531416300 P_335._ _ 20321688479559416350 P_340._ _ 26322288531646502400 P_345._ _ 26322288681646502450 > ModelModelloA (mm)B (mm)H (mm)P (mm)C (mm)D (mm) P_430._ _ 25822238429531416300...

Open the catalog to page 11

THERMOKEY reserves the right to modify the products contents in this catalogue without previous notice. - THERMOKEY si riserva il diritto di apportare modifiche e migliorie ai prodotti a catalogo in qualsiasi momento e senza preavviso. THERMOKEY S.P.A. - VIA DELLINDUSTRIA 1 - 33050 RIVAROTTA DI TEOR - UDINE - ITALY - TEL. +39 0432 772300 FAX +39 0432 779734 - WWW.THERMOKEY.COM - [email protected] THERMOKEY AUTHORIZED DEALER > LIGHT CUBIC UNIT COOLERS - RELEASE 01 - 05/2008 size="-2">

Open the catalog to page 12
