Brazed Plates

Product catalog summary

Technical Specifications:

Maximum Allowable Pressure: Varies by temperature and circuit. For example, at 50°C, F1-F2 and G1-G2 are 40 bar, while W1-W2 is 36 bar.
Working Pressure: At 120°C, F1-F2 and G1-G2 are 31 bar, W1-W2 is 28 bar; at 300°C, F1-F2 and G1-G2 are 23 bar, W1-W2 is 21 bar.
Design Temperature: Ranges from a minimum of -100°C to a maximum of +300°C.
Number of Plates: Between 14 and 210.
Volume per Chamber: 0.227 liters.
Total Weight: Calculated as P=Np x 0.406 + 9.2 kg.

Connection Details:

Standard Connections: F1: ODS 28, F2: ODS 42.
Optional Connections: Various ODS and flexible joint options available upon order.

Heat Exchanger Models:

TP09: 12 kW
TP22: 28 kW
TP12: 30 kW
TP82: 85 kW
TP202: 220 kW
TP222: 220 kW dual circuit
TP404: 440 kW
TP606: 660 kW

Materials:

Plate Material: 1.4401 - EN10028/7 “AISI 316L”.
Connections Material: 1.4401 - EN10028/7 “AISI 316L”.
Brazing Material: Pure Copper.

Insulation:

Material: Expanded Reticular Polyethylene Foam.
Thickness: 8 mm (16 mm on request).
Temperature Range: -50°C to +105°C.

Additional Notes:

Various configurations and connection types are available, including single and double circuit options.
Support kits and optional accessories are available upon request.

Catalog excerpts

S C A M B I AT O R I A P I A S T R E TP09 12 kW TP22 28 kW TP12 30 kW TP82 85 kW Ready for TP202 220 kW TP222 220 kW dual circuit R410A

Open the catalog to page 10

PLATE HEAT EXCHANGERS VERSIONE NORMALE STANDARD/STANDARD NORMAL VERSION □A SPECIFICARE IN FASE D'ORDINE/TO B£SPECIFIED ON ORDER FRONT FIXING REAR FIXING NB:POSSIBILE ANCHE KIT Dl SUPPORTO/ SUPPORT KIT AVAILABLE

Open the catalog to page 12

design model Multi pass

Open the catalog to page 15

CONNESSIONI DISPONIBILI AVAILABLE CONNECTIONS 3/4" Gas Cil. Femm. lungo/Female Lone Flexible Joint 1"1/4 lungo/long Flexible Joint 1 "1/2 lungo/long

Open the catalog to page 16

2" Gas cil. Maschio Lungo /Male Long

Open the catalog to page 17

COIBENTAZIONE - ISOLAMENTO MATERIALE: POLIETILENE RETICOLATO ESPANSO SPESS0RE:8 miTl (a richiesta anche 16 mm) MATERIAL: EXPANDED RETICULAR POLYETHILENE FOAM MIN. MAX WORKING TEMPERATURE: from -50°C to +105%

Open the catalog to page 18

THERMOKEY reserves the right to modify the products contents in this catalogue without previous notice. - Thermokey si riserva il diritto di apportare modifiche e migliorie ai prodotti a catalogo in qualsiasi momento e senza preavviso. THERMOKEY behaltet sich das Recht vor, die Produkte dieses Kataogs ohne vorherige Ankündigung zu verändern. - THERMOKEY se reserve le droit de modifier les produits de ce catalogue sans avis préable. l THERMOKEY AUTHORIZED DEALER BRAZED PLATE HEAT EXCHANGERS - RELEASE 00 - 03/2009 THERMOKEY SPA - VIA DELL’INDUSTRIA 1 - 33050 RIVAROTTA DI TEOR - UDINE - ITALY -...

Open the catalog to page 20
