EOLIA Industrial air cooled heat exchangers
EOLIA Industrial air cooled heat exchangers
Thermofin's EOLIA series of industrial air-cooled heat exchangers are designed for durability and efficiency, utilizing heavy gauge materials and advanced fin tube technology to ensure long-lasting performance in various industrial applications.
The exchangers are constructed with painted steel, galvanized steel, or stainless steel casings. They feature aluminum extruded fin tubes that prevent fouling and allow for easy cleaning, maintaining efficient heat transfer over time.
EOLIA exchangers are suitable for diverse industrial processes, including energy, petrochemical, environmental, metal mills, pulp and paper, plastics, and agrobusiness sectors. Custom designs are available to meet specific application needs.
Thermofin's exchangers incorporate high-efficiency electric motors and low-noise axial fans. Options for variable speed motors are available to modulate cooling capacities and reduce energy consumption. The electrical components meet or exceed standards such as C.S.A. or U.L.
Thermofin offers various options to facilitate maintenance, including access doors, middle access between tube rows, and pollen filters. Customization options include different coatings and materials, as well as a variety of connection types.
Thermofin provides services such as temperature and flowrate measurements, testing and repairs, capacity uprating, and unit replacement. They also offer cleaning services and reverse engineering for unit replacement.
Since 1993, Thermofin has been a leading name in thermal exchange in North America, known for designing and manufacturing high-quality exchangers for industrial processes.
Catalog excerpts
The excellence of our technology For sustainable exchanges ... >
Open the catalog to page 1
The range of Thermofin EOLIA exchangers is meant to address the particular needs of applications featuring necessary atmospheric discharges. It is perfectly adapted to cooling industrial processes as varied as those of the energy sector, petrochemical plants, the environment industry, metal mills, pulp and paper industry, plastics plants, the agrobusiness and others. Its custom design is optimized to respond to the particular needs of your application. Finned tubes Th e ran g e of T he rm of in E OL IA exc ha n g ers is meant to ad d d d d d d d dr ess th e p art ic ul ar nee ds o f a p pl ic...
Open the catalog to page 2
Thermofins study of the latest development in air handling has also yielded highly efficient custom designs of the fan motor arrangement, insuring optimum performance at the electrical, acoustic and flow distribution levels. Custom designs also means that EOLIA exchangers meet or exceed your requirements notably by the use of high efficiency electric motors and axial type low noise fans.All motors are of industrial quality and at least TEFC, explosion proof motors are available for even more rugged environment or to meet other security requirements. Fan propeller material is also selected with...
Open the catalog to page 3
Thermofin is keenly aware that the equipment maintenance and proper operation play a key role in the perfomance and longer life expectancy of the exchanger unit. Consequently, Thermofin has developped various options to facilitate and to shorten the time associated to these activities : > Addition of access doors to facilitate electrical motor maintenance. Middle access between tube rows to permit efficient and fast cleaning of finned surfaces otherwise out of reach. Easy access to electrical junction box. Addition of pollen filters to prevent seasonal or envi ronmental clogging of fins. Addition...
Open the catalog to page 4
Thermofins team can also intervene on your units:Temperature and flowrate measurements on existing units for thermal analysis and diagnosticTesting and repairs onsite or in ThermofinҒs shop Uprating capacity or allowable pressures and temperatures Unit replacement via reverse engineering Cleaning (passivation) Te a n Te U p U n Cl >
Open the catalog to page 5
Since 1993, Thermofin has designed, manufactured and marketed a large range of high quality exchangers for industrial processes. Over the years, Thermofin has become one of North Americas leading name in thermal exchange. Through its expertise and its dedicated workforce, Thermofin will always offer you the right exchanger: the one for sustainable exchanges ... Si nc e 19 93 Th er mo fi n ha s de si gn ed > Gasketed plate heat exchangers Unit heater Unitheate r @ thermofin.netwww.thermofin.net Industrial heat exchanger Extruded aluminum finned tubes 47, Marie-Victorin Blvd. Candiac Quebec, Canada...
Open the catalog to page 6All Thermofin catalogs and technical brochures
