Terra Universal Inc.
Hoods & Lab Equipment

Hoods & Lab Equipment

Product catalog summary

Overview: This document is a mini-catalog from Terra Universal, Inc., showcasing a selection of cleanroom and laboratory equipment. It includes detailed specifications, pricing, and ordering information for various products designed to maintain contamination-free environments.

Key Sections:

Product Specifications: The catalog provides detailed specifications for Vertical and Horizontal Laminar Flow Stations, CleanBooth™, CleanCube™, and WhisperFlow™ Benchtop Hoods. These products are designed to provide HEPA-filtered air to meet critical contamination requirements. Features include quiet, low-vibration fan/filter modules, stainless steel or powder-coated steel construction, and optional ionization equipment for static control.
Ordering Information: Instructions are provided for ordering the Vertical Laminar Flow Station and its components, such as Filter/Fan Units (FFUs) and optional accessories. The catalog lists dimensions, materials, and pricing for various configurations.
Accessories and Options: The document details optional accessories like motorized sliding shields, cleanroom drawers, and ionizing equipment. It also includes information on softwall panel kits and fluorescent lighting options for the CleanBooth™.
Pricing and Availability: Prices for each product and accessory are listed, with a note that prices and specifications are subject to change without notice. The catalog also mentions the availability of ULPA filters and other customizations.
Additional Products: The catalog briefly mentions handheld particle counters and environmental monitors, providing specifications and pricing for these devices.

Critical Information: The catalog emphasizes the importance of selecting the correct configuration and accessories to meet specific contamination control needs. It highlights the efficiency of HEPA filters, the benefits of ionization for static control, and the versatility of modular cleanroom solutions.

Materials and Configurations: The document lists several materials used in the construction of hoods, including Static Dissipative PVC, Nondissipative PVC, Polypropylene, 304 Stainless Steel, and Acrylic. Each material has specific pricing and configurations for both vertical and horizontal flow setups.

Filter Fan Units: The document specifies different sizes of filter fan units, their average flow rates, power requirements, and pricing for both HEPA and ULPA filters. It highlights the importance of selecting the appropriate filter for maintaining a clean environment.

Lighting Fixtures: Fluorescent illuminators are available in different sizes and are housed in vapor-sealed static-dissipative PVC. The document provides pricing and replacement bulb options.

High-Performance Plastics Series: Terra offers a range of specialty plastics for bench top hoods, including PVDF, CPVC, PVC, and Polycarbonate, each with unique properties like corrosion resistance and fire resistance.

Universal Hood Features: The Universal Hood can function as a mini-cleanroom or an exhaust venting station. It is modular, allowing for customization based on specific requirements. The document provides dimensions and material options for different hood types.

Filter and Blower Modules: The document outlines the selection process for filter/blower modules, including HEPA and ULPA filters, and provides performance metrics for different hood sizes.

Stands and Additional Options: Various stand options are available, including vibration-isolated and non-isolated designs. Additional options include power strips, air velocity monitors, and flange adapter panels.

Mini-Environment Equipment Enclosures: These enclosures provide a controlled environment for sensitive equipment. They include features like dual front doors, optional spill trays, and customizable access ports.

Laboratory Hoods:

Basic Laboratory Hoods: Feature a by-pass design for stable air velocity, epoxy-coated steel construction, and tempered safety glass. Options include vapor-proof and explosion-proof models.
Fiberglass 30 Laboratory Hoods: Designed for small spaces, these hoods have a fiberglass-reinforced polyester interior, are resistant to chemicals, and include a vapor-proof light.

Work Surfaces and Stands:

Available in various materials such as clean laminate, conductive laminate, polypropylene, and stainless steel. Pricing varies based on material and configuration (isolated or non-isolated stands).

Ventilation Systems:

Protector XVS Ventilation Stations: Suitable for light-duty fume hoods and other applications, featuring tempered glass for visibility and patented air foil designs for optimal containment.
FilterMate Portable Exhausters: Provide HEPA and carbon filtration for safe indoor exhausting, with options for different filter types based on specific needs.

Compliance and Standards:

Products comply with various standards such as SEFA, ANSI, NFPA, UL, ASTM, CAN/CSA, and ASHRAE, ensuring safety and performance.

Accessories and Options:

Includes airflow monitors, electrical receptacles, cupsink and turret kits, gas service fixture kits, and solvent storage cabinets.

Ordering Information:

Each product section includes catalog numbers and pricing for easy ordering. Additional options and accessories are available for customization.

Paramount Filtered Enclosures:

These are self-contained workstations that use carbon and HEPA filters to remove organic solvents, formaldehyde, acid gases, or ammonia.
Duet models include both carbon and HEPA filters for safe removal of vapors and particulates.
Features include a two-position tempered-glass safety sash, fluorescent lighting, and glacier white epoxy-coated aluminum construction.
Models are available in 36" and 72" widths, with options for organic vapor sensors.
Compliance with standards such as SEFA 1-2005, ANSI Z9.5-2003, and CE Conformity Marking for 230V models.

Purifier Delta Series Biological Safety Cabinets:

Designed to meet NSF standards for Class II, Type A2 Biological Safety Cabinets.
Features include a fully closing tempered glass sash with an audible/visual alarm, and a 30% exhausted/70% recirculated air ratio.
Available in various sizes, with options for air/water service fixtures and UV light.

Additional Products:

Heated Processing Chamber: Ideal for biological samples and microelectronics, with a recirculation system for uniform heating up to 140°F.
Temperature Stability Chamber: Provides a particle-free, heated environment with stable temperature conditions for critical operations.
ECM Modular System: Ductless exhaust purifiers with options for horizontal and vertical flow, using activated charcoal and HEPA/ULPA filters.

Ordering Information:

Detailed pricing and catalog numbers are provided for each product and accessory, including base cabinets, work surfaces, and filter types.
Contact information for ordering is included, with phone and fax numbers provided.

ECM™ Modular System Overview: The ECM™ Modular System is designed for permanent installation as a complete turnkey solution for cleanrooms. It offers various materials and designs to meet diverse cleanroom requirements, ensuring precise sizing to eliminate particle-collecting edges.

Cleanroom Benches: These benches are tailored for Terra’s Environmental Control Modules (ECMs), allowing fixed hood installation with minimal exposed edges. Available in dissipative and non-dissipative models, they feature laminated surfaces to prevent particle shedding. Options include laminate, polypropylene, and stainless steel with epoxy-finished steel frames.

Specifications:

Blower: 1200 CFM, 1675 RPM, 115VAC/60Hz, housed in polypropylene for optimized airflow.
Exhaust Purification: Charcoal filters for improved safety and efficiency.
Dimensions: Hood sizes range from 28" to 56" in width.
Air Flow: 600 CFM with standard filters, 525 CFM with HEPA filters.

Exhaust Fume Hoods: These hoods are available in stainless steel or powder-coated steel, with optional exhaust purification systems. They feature transparent PVC panels and sliding shields to control negative pressure and reduce fume escape.

Free-Standing Exhaust Fume Hoods: Designed for flexibility and economy, these hoods include a sturdy steel frame and a 6" discharge for easy connection to exhaust systems. They feature sliding shields and optional purification filters for safe indoor release of fumes.

Exhaust Fume Filtration Systems: These systems are ideal for localized operations, featuring a high-capacity unit with a bonded-charcoal filter for enhanced performance. They include various mounting options and accessories for customized setups.

DownDraft Work Station: This station is designed for operations involving hazardous fumes, featuring a powerful blower and activated charcoal filter for safe fume removal. It includes adjustable safety shields and customizable platform sizes.

Ductless Work Station: A portable system providing effective fume protection with a variable-speed blower and activated charcoal filter. It offers optional HEPA filters for cleanroom applications and is ideal for compact spaces.

Wet Processing and Cleaning Cabinets: Terra Universal offers flexible wet processing and cleaning cabinets that can be customized to fit specific application needs. These cabinets integrate with existing facility systems, including chemical delivery and fire suppression. Options include stainless steel for solvents and flammable chemicals, and polypropylene for acids and caustic chemistries. Fire-retardant polypropylene is also available.

Modular Stations: Terra's modular stations accommodate various processing modules and are available in polypropylene for acid compatibility and stainless steel for solvent applications. Standard configurations include options for vertical laminar flow hoods and control cases.

Vacuum Chambers: Terra offers a range of vacuum chambers suitable for degassing and transporting parts. Options include high-capacity, stainless steel, aluminum, and acrylic chambers, each with specific features like viewing windows and metering valves. Accessories such as vacuum controllers and connection kits are available.

Safety and Transport Solutions: Products include enclosed safety showers, acid transport carts, flammable materials carts, and mobile desiccators. These solutions are designed for safe handling and transport of hazardous materials, complying with safety regulations.

Gloveboxes: Terra's gloveboxes provide controlled environments for critical processing operations. Available in various materials and configurations, they offer features like humidity control, static protection, and temperature regulation. Options include Series 100, 300, 400, 500, and 600 models, each catering to different operational needs.

Work Benches and Accessories: Terra offers work benches with options for nonconductive laminate, stainless steel, and vibration-free tops. Additional accessories include Class 100 and static control chairs, designed to meet cleanroom standards.

Specifications and Product Listings:
1. Static Control Desks and Benches: Available in black and blue, with various models offering quick shipping options. Prices range from $403 to $452 depending on the model and color.
2. Laboratory Chairs: Ergonomic upholstered chairs and urethane chairs are available, with prices ranging from $208 to $376. Options include different backrest sizes and materials.
3. ErgoHeight™ Workstations: These workstations offer adjustable heights for ergonomic comfort and are compatible with Class 100/ISO 5 cleanliness requirements. Prices vary based on size and material, from $2,415 to $2,907.

Modular Cleanrooms and Laboratories:
1. Turnkey Solutions: Terra offers modular cleanrooms that can be customized for size, cleanliness rating, and material. Options include BioSafe™ steel designs and economical softwall panels.
2. Pass-Throughs and Air Showers: Various models are available for contamination-free transfer, including acrylic and stainless steel options, with prices ranging from $316 to $12,713.

Cleanroom Equipment:
1. Motorized Shoe Cleaner: Available in 110VAC and 220VAC models, priced at $2,719 and $2,973 respectively.
2. CleanTech® Hand/Glove Washing System: A microprocessor-controlled system priced at $6,950.
3. Gowning Room Equipment: Includes stainless steel benches, garment cabinets, and Sticky Mats® for maintaining cleanliness.

Dispensers and Storage Solutions:
1. Garb and Parts Dispensers: Available in acrylic and static-dissipative PVC, these dispensers organize gloves, safety glasses, and other items.
2. Stainless Steel Dispensers: Chemical-resistant and easy to clean, available in various sizes for gloves, wipers, and booties.

Additional Products:
1. Step Stools and Ladders: Made of electropolished stainless steel, with prices ranging from $1,146 to $3,633.
2. Cleanroom Waste Receptacles: Foot-pedal operated, available in various sizes and materials, with prices from $119 to $838.
3. PureDry™ Hand/Glove Dryer: Provides warm, contamination-free air, priced at $1,892.

Environmental Chambers: These chambers offer temperature control from 4°C to 70°C and humidity control from 20% to 98% RH in select models. They feature a 21-step programmable controller, RS485 data output, alarms, and a chart recorder. Available in various sizes, they are suitable for precise environmental condition control.

Refrigerated Incubators and Stability Chambers: These microprocessor-controlled chambers provide temperature control from 5°C to 60°C. Stability Chambers include a humidity system with a solid-state sensor, operating from 20% to 98% RH. They use environmentally friendly refrigerants and offer optional light packages and chart recorders.

UV Sterilization/Filtration Cabinet: This cabinet features a ceiling filter for particle removal and a UV germicidal light with a timer. It is designed for optimal air flow and sterilization efficiency.

Compact Lab-Line Incubators: These incubators are designed for small spaces, offering excellent temperature uniformity with a bimetallic thermostat. They are available with metal or acrylic doors.

Imperial III Incubators: These incubators provide gravity convection and mechanical options with electrical outlets for additional equipment. They are available in multiple chamber capacities.

Water- and Air-Jacketed Incubators: These incubators feature heated doors and stainless steel chambers, offering options for infrared or thermocouple sensors for temperature and humidity control.

Explosion-Proof Hot Plate: Designed for safe heating in explosive environments, this hot plate features a cast-aluminum top and a temperature range up to 220°C.

Cimarec® Digital Hot Plates/Stirrers: These devices offer uniform heat distribution and microprocessor-controlled temperature settings, with StirTrac™ technology for improved stirring.

Explosion-Proof Refrigerator/Freezer: This unit provides explosion protection for storing flammable materials, with separate compartments for refrigeration and freezing, meeting various safety standards.

Lab Refrigerator/Freezers: Available in different configurations, these units offer hydraulic thermostatic control and separate cold air flow control for efficient temperature management.

Tenney Junior Test Chambers: These chambers provide a wide temperature range from -75°C to +200°C, suitable for quality assurance and reliability testing in various industries.

Lunaire Stability/Shelf Life Test Chambers: Designed to meet ICH guidelines, these chambers offer stable temperature and humidity levels for various testing applications.

ESP-400 Processing Ovens: These ovens are designed for general baking and quality control, featuring a one-pass horizontal airflow system for efficient heating.

High-Capacity, HEPA-Filtered Cleanroom Oven: This oven provides stable elevated temperatures with HEPA filtration for a Class 100 process environment.

Hi-Temp “Squaroid” Oven: Featuring hydraulic thermostat controls, these ovens provide uniform temperatures up to 300°C with radiant warm-wall heating.

Large-Capacity Forced-Air Ovens: These ovens offer stable heating to 220°C with a turbo blower system for optimal uniformity and fast recovery time.

Tube Furnaces: Ideal for microelectronics applications, these furnaces offer a temperature range from 100°C to 1200°C, accommodating various tube sizes.

Sterilizers and Autoclaves: Terra Universal offers a range of sterilizers including the SterileMax Steam Sterilizer with a large chamber and safety features, MC8 and MC10 Steam Sterilizers with optional data logging, and the Chemiclave Chemical Vapor Sterilizer which is faster than conventional steam units. The DI+ Water Pretreatment System is also available to provide pure water for sterilizers.

Cryogenics: The document details cryogenic storage solutions such as the Bio-Cane Canister and Cane system, Locator Rack and Box system, and the Locator 7 Autofill Cryogenic Vessel. These systems are designed for both short- and long-term storage of biological samples.

Shakers: Various shakers are described, including the MaxQ series for different laboratory applications, Dual-Action Orbital and Reciprocating Shakers, and specialized shakers like the Labquake Tube Shaker/Rotator and Titer Plate Shakers. Each model is designed for specific laboratory needs, offering features like variable speeds and different holding configurations.

Water Systems: Terra Universal provides a comprehensive range of water purification systems from Barnstead, including the DIamond RO system, Mega-Pure Glass Stills, and various ultrapure water systems like the NANOpure DIamond and EASYpure models. The W.A.T.E.R. testing program is available to assess water needs and recommend appropriate systems.

Additional Products: The document also mentions polymer utility carts with adjustable shelves, made from chemical-resistant materials, suitable for laboratory environments.

For more detailed specifications and ordering information, visit Terra Universal's website.

Product Specifications and Pricing:
1. Polymer Carts: Available in 2-shelf and 3-shelf models with dimensions ranging from 18 x 28 inches to 27 x 39.5 inches. Prices range from $139 to $215 depending on the model and configuration.
2. Deep Ledge Carts: Feature 2.75-inch deep shelf ledges for spill containment. Available in 2-shelf and 3-shelf configurations with prices from $157 to $225.
3. MetroMax Utility Carts: Made from high-strength reinforced polymer with a weight capacity of 600 lbs. Prices start at $378.
4. Series 100 to 600 Carts: Various configurations with stainless steel and wire shelves. Prices range from $285 to $721.

Vacuum Cleaners:
1. Cleanroom Vacuum Cleaner: Features a four-stage filtration system with ULPA filter, priced at $914 for 120VAC and $957 for 220VAC.
2. Minuteman Explosion-Proof Vacuum: Suitable for hazardous materials, priced at $7,045 for 115VAC and $7,113 for 220VAC.
3. Portable Cleanroom Vacuum Cleaner: Includes HEPA filtration, priced at $354.
4. MicroVac: Functions as a vacuum or air blower with ULPA filter, priced at $955.

Ordering and Contact Information:
Orders can be placed via phone, fax, or online at TerraUniversal.com. Contact details include phone: 714-578-6000 and fax: 714-578-6020.

Additional Information:
Terra Universal offers a wide range of products for critical environment solutions, including particle filtration, static neutralization, and ultra-clean materials. Comprehensive guides and catalogs are available upon request.
