Overview: This document provides detailed information on various temperature sensor accessories offered by Tempsens Instruments, including thermowells, flanges, protection tubes, precision pipe fittings, compression fittings, bayonet parts, seal pots, connectors, compensating cables, connection heads, and terminal blocks. It highlights the materials, sizes, types, and specifications of these products.

Thermowells and Flanges: Thermowells are available in materials such as AISI SS304, SS316, and others, with sizes ranging from 1/2'' to 4''. They are rated from 150# to 2500#. Flanges include types like plate flange, lap joint flange, and weld neck flange. The document emphasizes the variety of materials and configurations available.

Protection Tubes: These are offered in materials like stainless steel and ceramic, with various configurations and lengths. The document lists specific dimensions and types, such as open-ended and close-ended tubes.

Precision and Compression Fittings: Made from materials like AISI SS316 and brass, these fittings come in sizes from 1/8” to 1” and include various types like hex nipples and reducing adapters.

Bayonet Caps and Seal Pots: These components are available in materials such as stainless steel and brass, with options for plain and threaded designs. They are used for thermocouple connections and sealing applications.

Compensating Cables: The document details wire gauges, conductor types, and insulation materials like fiberglass and Teflon. It includes a guide for wire insulation identification and application, highlighting temperature ranges and resistance properties.

Connection Heads and Terminal Blocks: These are available in materials like die-cast aluminum and stainless steel, with various types and protection classes. Terminal blocks are offered in configurations from two to eight terminals.

Company Profile: Tempsens Instruments is part of the Pyrotech group, established in 1976. The company specializes in temperature solutions, offering products like thermocouples, RTDs, and calibration equipment. They have a NABL accredited calibration laboratory and provide extensive quality assurance through various tests and inspections.
