RediSep Rf — Resolution With Speed

0 Absorbance 0.45 Minutes Standard Flash Column 5 10 15 100 %B Solvent 0 100 %B Solvent 0 0 0.45 RediSep Rf Gold Column Isomer 5 10 15 Absorbance Minutes Gold Resolution Ä Rf 0.1 Run Conditions Column size: 40 g Load: 333 mg (on 5 gram) Solvents: Hexane & Ethyl Acetate Flow rate: 40 mL/min Run time: 19.4 min. See Application Note #70 at www.isco.com/products/appnotes.asp for complete information. RediSep Rf Gold™ high performance flash columns deliver superior sample purity through the use of fine spherical silica gel (20 - 40 ìm). RediSep® columns were the first flash columns with Luer end...

Open the catalog to page 2

Gold Speed Ä Rf > 0.1 Save Time & Solvent Take advantage of the sharper peaks provided by spherical media to shorten purification time. Convert your methods to Gold Speed with steeper gradients and higher flow rates. .. Save on average 60% of your purification time with Gold Speed .. Save 30% or greater on solvents .. Separate silica sensitive compounds faster .. Dry compounds faster by collecting in 2/3 fewer fractions Run Conditions Column size: 40 g Load: 0.4 g (1% load) Solvents: Hexane and Acetone Flow rate: 40 mL/min: 80 mL/min See Application Note #72 at...

Open the catalog to page 3

RediSep Rf Gold™ Silica Columns 4 gram, package of 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69-2203-344 12 gram, package of 14 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69-2203-345 24 gram, package of 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69-2203-346 40 gram, package of 10 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .69-2203-347 80 gram, package of 6 . . . . . . . . . . ....

Open the catalog to page 4
