ISCO Water Monitoring Product Guide 2009 - 1

Automated Water Sampling and Open Channel Flow Measurement Sewer Systems Municipal/Industrial Wastewater Stormwater Runoff Rivers and Streams E n v i r o n m e n t a l Product Guide 2009 Edition

Open the catalog to page 1

ISCO Water Monitoring Product Guide 2009 - 2

Worldwide Sales and Service Friendly, knowledgeable help is available from Teledyne Isco in the U.S. and 40 other countries. Phone, Fax, or E-mail us today to arrange for a consultation or demonstration. Leasing Contact Isco leasing for competitive rates and fast delivery when instruments are needed for short-term projects. Special Applications We can provide creative solutions for almost any need, from consultation to unique hardware adaptations. Isco Environmental Products

Open the catalog to page 2

ISCO Water Monitoring Product Guide 2009 - 4

Intelligent sampling with integrated flow and parameter measurement capabilities. ¡ SDI-12 interface and 512 KB memory for versatile parameter monitoring and logging ¡ Accurate, repeatable samples ¡ High-performance peristaltic pump ¡ Accepts Isco 700 Series Modules Flow and Parameter modules add versatility. These environmentally sealed modules for your 6712 and Avalanche samplers are interchangeable in the field. The sampler’s memory retains data for convenient retrieval. 6712 Sequential/Composite 6712 full-size 700 Series Slide-in Modules 2 Automated Water Sampling Area Velocity...

Open the catalog to page 4

ISCO Water Monitoring Product Guide 2009 - 5

3 Durable, economical portables for general purpose and priority pollutant applications. ¡ Accurate, repeatable sample volumes ¡ Basic programming mode for simple setup ¡ Extended programming mode with additional features – Non-uniform time intervals – Multiple samples per bottle – Multiple bottles per sample Especially designed for general purpose and priority pollutant applications where a full-size sampler is too large. ¡ Small and lightweight ¡ Simplified programming for quick, easy setup ¡ Two keystroke program recall and one-button program start 3700 Sequential/Composite 3710...

Open the catalog to page 5

ISCO Water Monitoring Product Guide 2009 - 6

4 True refrigeration in a portable composite sampler. 12 VDC or 110/220 VAC power. ¡ Microprocessor controlled refrigeration system ¡ Two-keystroke program recall ¡ Download exact sample temperature in a simple, summarized report ¡ Optional mobility cart with battery carrier and pneumatic tires Multi-bottle sampling combined with portable refrigeration. 12 VDC or 110/120 VAC power. ¡ Intelligent sampling with SDI-12 interface and 700 Module input for parameter monitoring and triggering ¡ High performance peristaltic pump ¡ Data and sample compartment logging for convenient retrieval ¡...

Open the catalog to page 6

ISCO Water Monitoring Product Guide 2009 - 7

5 Intelligent sampling, advanced controls and communication, with a rugged fiberglass exterior. ¡ Sequential, composite, or flow-proportioned sampling in any environment ¡ SDI-12 interface and 512 KB memory for versatile parameter monitoring and logging ¡ Accurate, repeatable samples ¡ High performance peristaltic pump ¡ Accepts Isco 700 Special Function Modules Innovative ideas and materials combined with extreme weather and corrosion resistance. ¡ For outdoor use at wastewater treatment plants ¡ Sample temperature logging ¡ Slide-out bottle rack ¡ High output system cools samples fast...

Open the catalog to page 7

ISCO Water Monitoring Product Guide 2009 - 8

6 Open Channel Flow Measurement Accurate, non-contact liquid level measurement with built-in flow conversion software. ¡ Microprocessor-based digital sensor ¡ Self-tuned power control ¡ Unique sensor design minimizes “deadband” ¡ Vertical sensor face avoids condensation problems ¡ Variable rate data storage Advanced area velocity technology in modular form. ¡ Microprocessor-based low profile sensor ¡ Span calibration not required ¡ No temperature drift ¡ Automatic gain control ¡ No “draw down” effect ¡ Variable rate data storage 2150 Area Velocity System 2100 Series Modular Flow Systems...

Open the catalog to page 8

ISCO Water Monitoring Product Guide 2009 - 9

7 CSA approved for Class I, Div. 1, Groups C&D environments. Intrinsically Safe Area Velocity Flow Systems Baseefa and CSA approved for use in potentially explosive atmospheres. 2100 Series Communication Options 2151 Area Velocity System 2150 EX Area Velocity System 2101 Field Wizard 2102 Wireless Module 2108 Analog Output 2103c Cellular Modem Module 2103 Land-line Modem Module Modbus Protocol Internet Flowlink Software 2103G GSM Cellular Modem Module A weatherproof module for on-site data retrieval. Rugged NEMA 4X, 6P (IP 68) enclosure. Stores more than 2 weeks’ data from up to 20 modules!...

Open the catalog to page 9

ISCO Water Monitoring Product Guide 2009 - 10

8 For open channels and pipes from 12 to 180 inches (0.3 to 4.5 meters). ¡ Pulse-Doppler velocity profiling ¡ Upward-looking quad-redundant velocity sensors and integrated depth sensor in a single probe ¡ Real-time data output ¡ In-situ calibration never required For shallow water and small pipes/channels from 8.0 to 48 inches (0.2 to 1.2 meters). Ideal for high-accuracy applications. ¡ Upward-looking tri-redundant velocity sensors and integral depth sensor ¡ NEMA 6P (IP 68) housing ¡ Optional pressure or ultrasonic depth sensor ADFM® Pro 20 accQmin™ Flow Meter Velocity Profiling Flow...

Open the catalog to page 10

ISCO Water Monitoring Product Guide 2009 - 11

Velocity Profiling Flow Meters 9 Velocity profiling measurement for channel widths of 10 feet (3.0 meters) or more. ¡ Accurate in low velocities and complex flows ¡ Horizontally-looking redundant velocity sensors ¡ Upward-looking depth sensor For velocity profiling in full pipes 18 inches (0.4 m) to 9 feet (2.7 m) diameter. Can be installed while a pipe is still fully pressurized and in service – avoiding operation interruptions. ¡ Accurate measurement in difficult sites ¡ Industry-standard two-inch (50 mm) tap Horizontal ADFM® Flow Meter (H-ADFM) ADFM® Hot Tap Insertion Flow Meter FLOW...

Open the catalog to page 11

ISCO Water Monitoring Product Guide 2009 - 12

10 The first choice for flow logging when basic features satisfy your needs. Monitor rainfall, as well as sampler pacing and activation. ¡ Large, versatile memory ¡ Rugged, submersible enclosure ¡ Rain gauge input ¡ Sampler interface 4100 Series Flow Loggers Open Channel Flow Transmitters & Loggers Dependable flow measurement and data transmission. Proven accurate under the toughest conditions. ¡ Built-in level-to-flow-rate conversions ¡ Backlit LCD ¡ Sampler interface ¡ Analog, digital, and relay outputs 3010 Flow Transmitter Ultrasonic Level Sensor Area Velocity Probe Submerged Pressure...
