THCD-400 Multi-Channel Display

THCD-400 Multi-Channel Display
5Pages

Catalog excerpts

www.teledyne-hi.com THCD400 Self contained four channel power supply and display for How meters/controllers and pressure transducers FEATURES 5 Digit Resolution 0-5 VDC, 0-10 VDC, or 4-20 mA Accuracy (A/D) < 0.01% of Full Scale Eight Alarms (High & Low for Each Channel) Ratio Control Totalizer RS232 / RS485 Convenient Valve Override Buttons Many Selectable Units & Gas Names Bench Top or Panel Mount CE & RoHS Compliance APPLICATIONS • Operate & Monitor Flow Meter or Flow Controller • Gas Blending • Pressure Transducer Readout BENEFITS • Easy to Configure & Operate • Reduces Wiring/Integration Challenges • Highly Visible Display • Flexible Interface with Setpoint & Digital Command

Open the catalog to page 1

The THCD-400 is a microprocessor-based four channel power supply and controller that can operate mass flow meters, mass flow controllers, and pressure transducers as well as vacuum gauges. It provides stable output voltage levels to power these devices. The instrument accurately measures and displays output from analog transducers. In addition, it can generate analog command signals to mass flow controllers. The bright, blue OLED allows the display to be easily viewed. With a quick glance, the user can see each channel's status. Easy to Use The THCD-400 features an intuitive front panel. On...

Open the catalog to page 2

Specifications Signal Input Number of Channels Signal Type Accuracy Input Resistance Voltage Current Four 0-5 VDC, 0-10 VDC, 4-20 mA (User Selectable) < ± (0.1% of reading + 1 digit) > 1 MQ 120Q Set Point Output (Control Signal) Signal Type Accuracy (typ) Source Resistance 0-5 VDC, 0-10 VDC, 4-20 mA (User Selectable) ± 0.1% FS (Voltage); ± 0.2% FS (Current) 100 n Totalizer (Each Channel) Accuracy Output Voltage Total Supplied Current Single Channel Max Current Mains Input Voltage Frequency Fuse Fuse 110/115/230 vac Environmental Operating Temperature Regulatory Safety Emissions/lmmunity/ESD...

Open the catalog to page 3

Outline Drawing

Open the catalog to page 4

THCD-400 Four Channel Power Supply Meter 300 “B” Series & 24 VDC 200 Series Cable 8' Cable (15-Pin “D” Male to 9-Pin “D” Female ) HPM-760S Vacuum Sensor Cable: Connects Teledyne Hastings Power Supplies to Teledyne Hastings 760s Series .TELEDYNE HASTINGS INSTRUMENTS Everywhereyoulook' PB-190_03/17 © Teledyne 2017 All Rights Reserved.
