CMOS X-ray Dynamic Detectors for Dental Applications
12Pages

IMAGE SENSORS | X-RAY DETECTORS | IMAGE PROCESSING | CUSTOM SOLUTIONS LOW DOSE X-RAY DETECTORS for Dental Applications COMMITTED TO PEOPLE. DRIVEN BY INNOVATION.

IMAGE SENSORS | X-RAY DETECTORS | IMAGE PROCESSING | CUSTOM SOLUTIONS Solutions for Demanding Applications Teledyne DALSA offers a complete portfolio of innovative X-Ray detectors tailored specifically for dental imaging applications, like General Dentistry; Orthodontic Procedures; Oral Surgery; Ear, Nose and Throat (ENT) and Veterinary Dentistry. Our innovative and reliable products offer solutions for all types of imaging modalities - 3D/CBCT, ExtraOral Scanning and Intra Oral imaging in cutting edge CMOS technology and CCD-TDI technology. Xineos Family of CMOS X-Ray detectors spans the...

XINEOS - Family for 3D/CBCT CMOS X-Ray detectors • LOW DOSE AND HIGH IMAGE QUALITY The Xineos Family of detectors features high Image Quality (IQ) in terms of Modulation Transfer Function (MTF) and Detective Quantum Efficiency (DQE) at very low dose levels leaving behind the until-now unbeatable IQ performance of the IICCDs. The very low noise of the CMOS material and the proprietary active pixel architecture of the Teledyne DALSA’s CMOS detectors assure factors higher signal-to-noise ratio (SNR) with respect to the a-Si-based and even other CMOS-based competing products. HIGH RESOLUTION...

IMAGE SENSORS | X-RAY DETECTORS | IMAGE PROCESSING | CUSTOM SOLUTIONS Utilizing the sixth- generation proprietary radiation-hard pixel design with switchable pixel capacitors which provide switchable saturation dose levels, the Xineos detectors family is extremely versatile and suitable for all types of dental applications with just a single detector. The integrated on-chip analog-to-digital converter (ADC) assures additionally extremely low read out noise levels. INSTANT START-UP TIME AND STABLE OPERATION The extremely low dark current of the Xineos family detectors is responsible for a...

Vera - Family of Intraoral Dental CMOS Sensors The high resolution VERA CMOS sensors family are designed specifically for patient comfort with ergonomic shape in two image sizes that correspond to #1 and #2 size dental films. The pixel size of the sensor is 20um, corresponding to a theoretical resolution of 25lp/mm. The sensors are placed in a rugged thermoplastic enclosure for protection. Key features include integrated USB 2.0 interface and a thin 3 meters long flexible cable. Scanning Extraoral Dental X-Ray Detectors • Full portfolio of detectors – one stop shop • Added value to the...

IMAGE SENSORS | X-RAY DETECTORS | IMAGE PROCESSING | CUSTOM SOLUTIONS GENERAL TECHNOLOGY CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel PIXEL PITCH CMOS Active Pixel RESOLUTION [pxl] 1316x1312 1302x1312 1548x1548 1488X1148 2064x2236 1416x1420 2996x2996 1952x1952 IMAGE QUALITY SATURATION DOSE, RQA5 (per mode) [uGy] MTF @ 1LP/MM DYNAMIC RANGE (HFW) [dB] IMAGE LAG, FIRST FRAME @ 30fps BANDWIDTH DATA INTERFACE GigE / CameraLink GigE GigE / CameraLink GigE GigE / CameraLink GigE / CameraLink GigE / CameraLink GigE /...

XINEOS - FAMILY FOR 3D/CBCT CMOS X-RAY DETECTORS SWITCHABLE PIXEL SENSITIVITY Low Dose X-Ray Detectors for Dental Applications | 7

IMAGE SENSORS | X-RAY DETECTORS | IMAGE PROCESSING | CUSTOM SOLUTIONS INTRA-ORAL DENTAL FAMILY GENERAL TECHNOLOGY - CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel CMOS Active Pixel PIXEL PITCH ACTIVE AREA RESOLUTION [pxl] 1500x1006 1650x1246 1500x1006 1650x1246 IMAGE QUALITY SCINTILLATOR - Kodak Min-R 2190 Kodak Min-R 2190 CsI CsI MTF @ 5LP/MM BANDWIDTH DATA INTERFACE FRAME RATE POWER CONSUMPTION POWER SUPPLY POWER CONSUMPTION [W] 0.35 0.35 0.35 0.35 INTERGRATION DIMENSIONS (WxHxD) CABLE LENGTH OPTIONS DRIVER SUPPORT ENVIRONMENTAL OPERATING TEMPERATURE STORAGE TEMPERATURE

VERA - INTRAORAL DENTAL SENSORS INTRAORAL DENTAL INTRAORAL DENTAL INTRAORAL DENTAL Low Dose X-Ray Detectors for Dental Applications | 9

IMAGE SENSORS | X-RAY DETECTORS | IMAGE PROCESSING | CUSTOM SOLUTIONS PANORAMIC-CEPHALOMETRIC FAMILY GENERAL TECHNOLOGY CMOS Active Pixel CMOS Active Pixel CCD-TDI PIXEL PITCH PIXEL CAPACITY MODES ACTIVE AREA RESOLUTION [pxl] 1536x68 2305x68 5580x256 8160x256 IMAGE QUALITY SATURATION DOSE, RQA5 (per mode) [uGy] DYNAMIC RANGE (HFW) [dB] IMAGE LAG, FIRST FRAME @ 30fps BANDWIDTH DATA INTERFACE GigE GigE FRAME RATE - 1x1 (GigE) FRAME RATE - 2x2 (GigE) POWER SUPPLY POWER CONSUMPTION ACTIVE COOLING POWER CONSUMPTION EXTERNAL INTERFACE MODULE OPERATING TEMPERATURE STORAGE TEMPERATURE HUMIDITY...

ARGUS PAN / XINEOS - FAMILY OF SCANNING X-RAY DETECTORS ARGUS CEPH CMOS DIGITAL TDI (DTDI) ACQUISITION MODE CCD (ANALOG) TIME DELAYED INTEGRATION MODE (TDI) Various line-scan technologies: single-line, dual-line and time delay integration (TDI). To achieve high responsivity, TDI uses multiple stages to capture multiple exposures. In these stages, photogenerated signal charges are transferred in sync with object motion. Dual-line scans are considered two-stage TDI’s. Low Dose X-Ray Detectors for Dental Applications | 11

World-Class Capability... Design, Engineering and Manufacture LEADING PROVIDER AND PREFERRED PARTNER A QUALITY CERTIFIED COMPANY Design, Development and Manufacturing Image Sensor Product Solutions in Professional and Mid-Range segments • CCD- & CMOS Image Sensors • Human Vision • X-Ray Detectors • Medical/Dental X-Ray • Chipset & Application Reference Designs • Non-Destructive Testing • Customer Applications Support • Industrial & Scientific X-Ray • IEC 60601-1 third edition • RoHS compliancy Sales & Customer Support Eindhoven, NL Santa Clara, US www.teledynedalsa.com For more detailed...
