Overview

This document details the technical specifications, features, and compliance of firefighting electrical control panels manufactured by Tecnoelettra srl. The panels are designed according to UNI12845 standards to control and monitor motorpumps and electropumps used in fire suppression systems.

1. General Specifications

• Panels are housed in robust metal cabinets with IP54 or IP65 protection and painted RAL3000.
• Equipped with door interlock switch disconnectors with fuses for safety.
• Use of AC3 rated contactors and three-phase thermal relays with manual reset.
• Incorporation of safety transformers for low voltage auxiliary circuits.
• Warning lights indicate power status, engine operation, and thermal relay activation.
• Terminal boards facilitate weekly testing and remote signaling for automatic/manual modes and pump status.
• Selector switches allow manual, off, and automatic operation modes.

2. Jockey Pump Panels (198P Series)

• Power range from 4 to 7.5 kW.
• Compact dimensions: 400x300x200 mm.
• Designed specifically for jockey pump control with standard safety and monitoring features.

3. Motorpump Panels (F808MP Series)

• Fully compliant with UNI12845 norms.
• Incorporate the TE808 electronic controller featuring a large 320x240 pixel backlit display.
• Capabilities include ambient temperature monitoring, scheduled periodic testing, and fuel level/endurance visualization.
• Robust design with IP65 protection, certified vibration resistance (30G), and operational temperature range from -30°C to +70°C.
• User-friendly interface with intuitive keyboard, alarm help key, USB and RS-232 ports for PC connectivity.
• Data storage supports up to 128 event logs; optional Data Recorder System (SDR) enables data transmission.
• Standard components include battery chargers, acoustic alarms with silencer, starter buttons, and remote alarm terminals.
• Comprehensive alarm coverage includes start failures, battery faults, temperature alarms, fuel and oil pressure warnings, RPM limits, and scheduled test statuses.
• Optional GSM and GPS communication modules enhance remote supervision.
• TE808 controller uniquely passed HALT accelerated reliability testing (-60°C to +120°C, 30 g RMS vibration).

4. Electropump Panels (F808D and F808ST Series)

• Designed for electric pump control using direct-on-line (D.O.L.) or star/delta starters.
• Power range from 10 kW up to 180 kW depending on model.
• Cabinet sizes vary from 500x400x200 mm to 800x600x300 mm.
• Features mirror motorpump panels including TE808 controller, environmental monitoring, scheduled testing, and fuel endurance visualization.
• Standard components include IP54 metal cabinet, TE808VVF electronic board, interlock switches with fuses, acoustic alarms with silencer, test lamps, contactors, current transformers, auxiliary battery supply with 3-hour endurance, and remote alarm terminals.
• Alarm list covers start faults, overloads, battery charger faults, phase failures, environmental temperature, and automatic stop signals.
• Optional GSM and GPS modules available.
• TE808 controller certified for extreme environmental conditions and vibration resistance.

5. Remote Alarms Report Box (F808RA)

• Compact IP55 rated PVC cabinet (118x158x75 mm) designed for acoustic and visual alarm monitoring.
• Complies with UNI EN12845 Appendix I for remote alarm signaling.
• Features a 75 dB acoustic buzzer, silencer button, alarm lamp test button, and 5 signaling lamps with customizable multilingual strips.
• Supply voltage options: 12/24 Vdc.

6. Additional Product Series and Controllers

• F210VVFD-F210VVFST-UNI12845 series panels designed for motor pump control, housed in IP54 RAL3000 metal boxes.
• Incorporate TE2010-VVF controller with a 128x64 pixel backlit display supporting multilanguage interface.
• Measures 23 electrical parameters with high accuracy <1% error.
• Supports 16 alarms and 4 motor starting methods (D.O.L., star/delta, impedance, autotransformer).
• Programmable automatic weekly tests and periodic service indications.
• Communication ports: RS232 for GSM modem (SMS), RS485 for remote data reporting up to 1 km.
• Analog input for pressure sensor and 4 outputs for remote alarm reporting.
• Event log and warranty tracking features included.

7. Alarm Report Box RE12845

• Connects to TE2010-VVF controller to remotely display main alarms per UNI12845 requirements: start request, start failure, pump ON, and no supply alarms.
• Self-powered with rechargeable battery to ensure alarm signaling during power failure.
• Includes LED indicators for supply, charging, and alarms, plus buttons for LED testing and siren silencing.
• Available in DIN rail mount (RE12845) or wall-mounted IP65 box (F2010RA).

8. Technical Specifications and Product Codes

• Detailed tables specify power ratings (HP, kW), voltage (400 Vac), DC voltage (12 Vdc), dimensions, and product codes for D.O.L. and star/delta starters.
• Cabinet dimensions range from 500x400x200 mm to 800x600x300 mm depending on power rating.

9. General Sales Conditions

• Offers valid for 30 days; prices exclude VAT, packing, carriage, customs duties unless specified.
• Seller reserves right to modify products without prior notice for improvements.
• Delivery is ex works San Rocco di Guastalla, Italy; delivery times are estimates and may be extended due to buyer delays or uncontrollable events.
• Packing methods depend on goods; special packing requires prior agreement.
• Warranty covers defects in materials and workmanship for 12 months from dispatch; excludes normal wear, misuse, improper assembly, negligence, or uncontrollable events.
• Payment terms specified in contract; late payments incur bank interest; returns accepted only if pre-authorized and in original condition.
• Disputes governed by Italian law, jurisdiction of Reggio Emilia courts.

Critical Information and Best Practices

• All panels meet or exceed UNI12845 fire-fighting system standards ensuring safety and compliance.
• Controllers provide comprehensive monitoring, diagnostics, and scheduled testing to maintain system readiness.
• Robust construction supports operation under severe environmental conditions including wide temperature ranges and high vibration.
• Remote monitoring and data logging facilitate maintenance and compliance verification.
• Optional GSM and GPS modules enhance remote supervision capabilities.
• Warranty coverage of 24 months starts automatically upon full system operation for certain products.

Summary

Tecnoelettra’s firefighting electrical control panels offer advanced, reliable solutions for motorpump and electropump control in fire suppression systems. Their compliance with UNI12845 standards, robust design, user-friendly interfaces, extensive alarm and diagnostic features, and optional remote communication modules ensure high safety, operational efficiency, and ease of maintenance.
