Overview
Trido triplex pumps are injection pumps with three simple effect pistons, known for their compactness, robustness, and ease of maintenance. They are available in various models, including standalone units without a frame or motor (N model), versions with a hydraulic motor for drilling rigs (HYD model), electric models with remote control, and diesel engine models equipped with a gearbox.

Specifications
The pumps are equipped with safety features such as a safety valve to prevent overpressure, a manometer, and treated steel ball valves. They are lubricated by an oil bath. The Trido range includes models like Trido 250 x 30, 250 x 40, and 250 x 50, with specific models such as TRIDO 130x40 N, EL, TH, and HYD.

Usage and Versatility
Designed for transferring or injecting water, drilling mud, or light slurries, these pumps can be mounted on drilling rigs or frames with diesel or electric motors. The frame-mounted pumps come with a handling hook for ease of transport.

Performance and Safety
The pumps feature treated steel cylinder liners and ball valves, which are easily replaceable. All pumps include a safety valve to protect against blocked exhaust pipes and are equipped with an emergency stop and safety cages for moving parts.

Technical Data
The 130 x 40 pump has a cylinder capacity of 808 cc, a maximum rotation speed of 660 rpm, and a flow rate of 34.3 gal/min at a pressure of 580 psi. The diesel engine version has a power of 11 hp and a rotation speed of 2300 rpm, while the electric motor version offers 14.75 hp at 1500 rpm. Dimensions and weights vary between the pump-only, electric, and diesel models.

Note
TEC reserves the right to change design, materials, and specifications without notice.
