HYR series - HEAT-SINK RACK MOUNTING ENCLOSURE

Product catalog summary

Product Overview:
The document details the HYR and HYRH series heat-sink rack mounting enclosures, available in 8 different sizes and two color options (Silver and Black). These enclosures are designed with a stylish hairline finish and offer excellent cooling performance due to the heat-sink side plates. They are constructed from robust aluminium extrusion parts, ensuring durability and ease of assembly.

Components:

Heat-sink side plate: 2 pcs, Extruded aluminium A6063S-T5, Silver/Black, Anodized
Front and Rear panels: 1 pc each, Extruded aluminium A6063S-T5, Silver/Black, Hairline brushed & Anodized
Top and Bottom cover: 2 pcs, Aluminium A1050P, Silver/Black, Hairline brushed & Anodized
Corner support: 4 pcs, Steel SPCC, Trivalent chromate
Rubber feet: 4 pcs, Polyurethane, Black
Handle (HYRH series only): 2 pcs, Extruded aluminium A6063S-T5, Silver/Black, Anodized
Screws: Steel, Nickel plated/Black trivalent chromate

Technical Data:

Protection class: IP40
Heat resistant

Product Specifications:
The document provides detailed dimensions and weights for various models within the HYR and HYRH series, specifying the width (W), height (H), depth (D), and standard weight in kilograms for each model.

Included Screws:

BB Color type: M3-6 countersunk screw, black trivalent chromate x 16 pcs; M3-5 Slotted raised countersunk screw, black trivalent chromate x 12 pcs
SS Color type: M3-6 countersunk screw, nickel plated x 16 pcs; M3-5 Slotted raised countersunk screw, nickel plated x 12 pcs

Optional Accessories:

Mounting plate HYC series
L-bracket HYCL series
TORX screw MR3-5Z series

Drawings are available in DXF/DWG/PDF/STP formats on the website.

Additional Components:

Mounting plate: Aluminium A1050P, Unfinished
L-bracket: Steel SPCC, Trivalent chromate
Screws: Steel M3, Trivalent chromate

Customization and Services:
Clinching stud customization service is available.

Catalog excerpts

HYR series - HEAT-SINK RACK MOUNTING ENCLOSURE-1

Technical Data ■ 8 different sizes, each with 2 color types available for selection. ■ Stylish and elegantly designed with a hairline finish. ■ Excellent cooling performance with the heat-sink side plates. ■ Tough and robust enclosure from using aluminium extrusion parts. ■ Simple and easy to assemble construction.

Open the catalog to page 1

HYR series - HEAT-SINK RACK MOUNTING ENCLOSURE-2

Accessories (Optional parts) Mounting plate HYC series See page 331 TORX screw MR3-5Z series See page 398 HYR dimensions (outside view) ■ Drawings below are reference examples only. DXF/DWG/PDF/STP drawings available on our website. Product no. / Details Product no.

Open the catalog to page 2

HYR series - HEAT-SINK RACK MOUNTING ENCLOSURE-3

Technical Data ■ Equipped with handy rack mount / pull out handles. ■ Available in 8 sizes, and 2 different colors. ■ Excellent cooling performance with the heat-sink side plates. ■ Tough and robust enclosure from using aluminium extrusion parts. ■ Simple and easy to assemble construction.

Open the catalog to page 3

HYR series - HEAT-SINK RACK MOUNTING ENCLOSURE-4

Mounting plate HYC series See page 331 TORX screw MR3-5Z series See page 398 HYRH dimensions (outside view) ■ Drawings below are reference examples only. DXF/DWG/PDF/STP drawings available on our website. Product no. / Details Product no.

Open the catalog to page 4

HYR series - HEAT-SINK RACK MOUNTING ENCLOSURE-5

Accessories (Optional parts) HYC dimensions ■ DXF/DWG/PDF/STP drawings available on our website. Mounting plate Mounting plate ■ Mounting plate and L-bracket set. Product no. / Details Product no. W Clinching stud customization service available. HYCL series L-bracket for HY • HYR • HYRH HYCL dimensions ■ DXF/DWG/PDF/STP drawings available on our website. ■ Simple L-bracket and screw set. ■ Use with your original mounting plate or PCB. Product no. / Details Product no. Lab Pack of
