Technical Data Recommended torque: ■ Small-sized frontal screw fastening type waterproof box. ■ Available in 39 different sizes. ■ Applicable for various uses as wiring pull box, terminal junction box, switch box and so on. METEOROLOGICAL MONITOR TRANSMITTER

■ Drawings below are reference examples only. DXF/DWG/PDF drawings available on our website. BCAS dimensions ◎ : Guide markings for installation of optional latch/hinge parts. Product no. / Dimensions Product no. Dimensions (External) Dimensions (Internal) Accessories (Optional parts) Mounting plate BMP series Latch • Hinge BCL55 • BCH55 Spare cover screw CB series Mounting bracket CK series See page BCAS-3 ~ BCAS-4 See page BCAS • BCAL-ACC-1 See page BCAS • BCAL-ACC-3 See page BCAS • BCAL-ACC-2 Cable gland See cabl

Accessories (Optional parts) ■ Strong but easily customizable. ■ Drawings below are reference examples only. DXF/DWG/PDF drawings available on our website. Mounting plate Steel t=1.6 Zinc coated

Accessories (Optional parts) BMP-P SERIES PLASTIC MOUNTING PLATE ■ Lightweight ABS plastic mounting plate. ■ Drawings below are reference examples only. DXF/DWG/PDF drawings available on our website. Components Part name Material Color / Finish Mounting plate ABS White gray Product no. / Dimensions Product no.

■ Refer to ◎ guide markings on BCAS • BCAL box when installing. BCH55Components Part name Pcs Material Color / Finish Hinge 1 Stainless steel SUS304 Unfinished Bracket 2 Stainless steel SUS304 Unfinished Gasket 2 EPDM Black Product no. / Suitable box Product no. Suitable box Included screw BCAS series BCH65 BCAL series Truss head M4-10 ■ Refer to ◎ guide markings on BCAS • BCAL box when installing. BCL55 BCL65 Components Part name Color / Finish Product no. / Suitable box Product no Included screw BCAS series BCAL series

Accessories (Optional parts)BCM series BLIND PLUG for BCAS • BCAL ■ Blind plug for BCAS • BCAL when installing hinges and latches. Not usable when using cover screws. Part name Material Color Blind plug ABS White gray Product no. Suitable box Pack of BCM-1 BCAS series (Not available for BCAS050604, 050605 models) 1 CK series STAINLESS STEEL MOUNT BRACKET CK-34Z dimensions ■ CK-34Z model requires the use of MT4-10 screw. Product no. Material Finish Pack of MT4-10 (Pan head M4-10) Stainless steel Unfinished 4

■ Mounting screw for the bosses without insert-nut. Product no. / Feature Product no. Material Finish Pack of MT4-8T (Binding head tapping M4-8) Steel Trivalent chromate MT5-8T (Binding head tapping M5-8) Steel Trivalent chromate CB SERIES SPARE COVER SCREW for BCAS Product no. / Feature / Suitable boxProduct no. Material Color Pack of White gray White gray White gray Product no. / Feature / Suitable box CB28M Product no. Material Color Suitable box Pack of CB28P Fiblerglass • Nylon White gray BCAL series 1 White gray BCAL series 1

Accessories (Optional parts) POLE MOUNTING BRACKET Ŷ Stainless steel pole mounting bracNet Ior SPCM SPCP and BCAL BCAS series. Ŷ Easy pole mount with the use oI SSK-B mounting screw and PKB mounting belt. Ŷ D;)DW*PD) drawings available on our website. Ŷ SSK-P models includes plastic mounting bracNets.

Part name Color / Finish Barrel finish Plastic bracket (SSK-P models only) White gray Screws included with SSK brackets are for BCAP • BCAR • BCPK • BCPR series use only. For other series, please utilize SSK-B screw set. Suitable mounting belt SSK-B SERIES MOUNTING SCREW SET for SSK■ Mounting screw set for use with SSK pole mounting bracket.■ See chart on page SSK-3 for appropriate bracket/screw/box combination.■ Material / Finish : Stainless steel / Unfinished.Product no. / Dimensions Product no. Included screws Suitable box Pcs SSK-B4-25N M4-25 Pan head with nut SPCP • SPCM series 4 SSK-B5-10...

Accessories (Optional parts) BCAS series SPCM • SPCP series mUse screws included with SSK bracket for vertical mount ■ For installation of SR series outdoor roof on SPCM • SPCP series SR series (For SPCM • SPCP - see page SPCP • SPCM-ACC-2) ■ Select SSK bracket depending on mounting type (Vertical or Horizontal). (Longer vertical side) (Longer horizontal side)

POLE MOUNTING BRACKET Accessories (Optional parts) • White gra^lH • I Dark gray ■ Pole mount bracket made from weather resistant ASA material. ■ Suitable for both for vertical and horizontal mounting. ■ Hole milling is required for bracket installation. ■ IPX7 protection can be maintained through the use of sealing washers. ■ Pole mount is possible with the use of PKB series mounting belt. Material Tightening Tensile thickness torque strength ■ Listed tightening torque values are for reference only. Actual required torque may differ. DXF/DWG/PDF drawings available on our website. PKB SERIES POLE...

Accessories (Optional parts) WGMB-2SW POLE MOUNTING BRACKET WGMB-2SW dimensions ■ Pole mount bracket made from robust diecast aluminium. ■ Bracket can be mounted on both vertically, and horizontally. ■ Sealing washers enables the installation to have a protection class equivalent to IPX7, X5. ■ Hole milling on enclosures is required when installing mounting bracket. ■ Pole mount is possible with the use of SNB or PKB series mounting belt. ■ Installation can be done on a variety of enclosures made from plastic, diecast aluminium or stainless steel. ■ DXF/DWG/PDF drawings available on our website....

Accessories (Optional parts) STAINLESS STEEL POLE MOUNTING STRAP ■ Corrosion resistant stainless steel (SUS304) belt clamp. ■ It can be installed securely by tightening the screw. ■ 8 mm nut driver (box driver) is recommended for tightening. Flat-bladed screwdrivers can also be used. Part name Product no. / Details Product no. Strap width Strap thickness ■ Recommended torque listed is for reference only; actual may differ. Assemble after testing torque. SNB Strap required Suitable series SSK series WGMB series Suitable models

Accessories (Optional parts) series POLE MOUNTING BELT PKB-10PM, 10P PKB-10S, 20S ■ Pole mounting belt for attachment of enclosures with suitable pole mount brackets or construction onto poles. ■ Designed for one time use only (not reusable). ■ Strong stainless steel clamping type and easy installation plastic type are available. ■ DXF/DWG/PDF drawings available on our website. Plastic stopper Stainless steel stopper Stainless steel belt Components Part name Product no. / Details Product no.
