BC series EMBEDDED BATTERY BOX Operating temperature: -10°C ~ +60°C ■ Suitable to be installed into enclosures with material thickness of 1.0mm to 3.5mm. ■ Cover can be opened/closed without any tool for easy battery replacement. ■ 5 different battery layouts are available as AA x 2, AA x 3, AA x 4, AAA x 2 and AAA x4. Each layout comes in 2 models: with lead-wire, and without lead-wire. ■ ©©markings prevents incorrect placement of battery. ■ The dimensions of alkaline or manganese batteries may vary depending on country and brand. Use optional battery cushion sponge to preventing rattling.

Suitable to be installed into enclosures with material thickness of 1.0mm to 3.5mm. *Alkaline or manganese batteries

How to mount on the enclosures ■ Insert battery box into the milled hole first, and fit the frame on the back side. Once mounted, secure the frame with screws. ■ For BC3-4□ models, ▷ markings are shown on the frame. Install by matching the markings. Parallel circuit conversion on BC series battery box ■ BC-3□ models can be converted from a series to a parallel circuit. See below illustration for further details. ■ IT series (IT-3 models) optional battery contacts can be used for parallel circuit conversion. (See website for more information) ■ Use caution when installing or replacing the terminals...

Mount Example ■ BC series battery boxes can also be mounted on aluminium enclosures.

■ DXF/DWG/PDF drawings available on our website. ■ Battery snap comes with holder. Battery snap Technical Data Holder material Holder color Lead wire Contact material Battery snap cover Contact surface finish Product no. Battery Battery snap (included) Weight (g) Pack of SCM SERIES BATTERY CUSHION SPONGE ■ Flame resistant moltoprene sponge with adhesive on the back side. ■ Use to prevent battery from rattling inside the holder. Suitable battery holder Product no. Suitable battery holder

IT SERIES BATTERY CONTACT Components Plate material Product no. / Feature Product no. Spring diameter Spring material Matching battery / Details D : Left + (Positive) • Right - (Negative) D : Left - (Negative) • Right - (Positive) C : Left + (Positive) • Right - (Negative) C : Left - (Negative) • Right - (Positive) AA : Left + (Positive) • Right - (Negative) AA : Left - (Negative) • Right - (Positive) AAA : + (Positive) AAA : Left + (Positive) • Right - (Negative) AAA : Left - (Negative) • Right - (Positive) IT dimensions ■ DXF/DWG/PDF drawings available on our website. IT-1SP IT-1WP 16.3

■ DXF/DWG/PDF drawings available on our website.
