Systemair
Iris Damper

Iris Damper

Product catalog summary

Overview: The Iris Damper SPI by Systemair is designed for efficient airflow adjustment and measurement, offering quick, silent, and effective operation. It ensures air tightness to Class C and is suitable for various ventilation systems.

Installation and Maintenance: The SPI Iris Damper is easy to install and maintain, reducing the time required for balancing airflow during system commissioning. It features linear choking characteristics, allowing for simultaneous adjustment and measurement, which enhances indoor climate comfort.

Design Features: The damper is delivered in a fully open position for easy pressure testing. It includes a graduated scale of 'K' factors for precise adjustment, and each unit comes with comprehensive mounting and adjustment instructions. The extended spigot connections prevent seal damage during installation.

Performance: The SPI offers 100% opening capacity, eliminating the need for an access door for cleaning. Its design minimizes noise generation during volume control, maintaining low noise levels even with increased air velocity.

Construction and Accuracy: The simple construction of the SPI damper provides excellent adjustment properties and is manufactured to air tightness class C. It functions effectively with airflow in either direction, reducing installation errors.

Variants: The SPI-F motorized unit is available for variable ventilation requirements, adjusting air supply based on sensor signals. The SPM variant offers more choking ability and is recommended for complete closing applications, ideally with an RLL access door.

Size Specifications: The document includes a table listing various sizes of the SPI damper, detailing dimensions for each size to accommodate space constraints.

Contact Information: Systemair Ltd is located in Rochester, Kent, with contact details provided for further inquiries.

Catalog excerpts

100% Opening capacity The SPI can be fully opened,eliminating the need for an access door for clea- ning purposes. Low Noise Generation The design of the adjustment function together with the geometry of the SPI, results in low noise generation under volume control.A conventional damper will increase the air velocity along the duct walls resulting in high generated noise under volume control.The 'Iris' aperture is close to ideal from a flow technology aspect.The Iris damper increases the air velocity with low levels of noise generation provided the instructions are followed in relation to the...

Open the catalog to page 2

Systemair Ltd Medway City Estate,Rochester,Kent,ME2 4ER Օ Tel:+44 1634 735 000 Fax:+44 1634 735 010Head Office Systemair AB Օ SE-739 30 Skinnskatteberg,Sweden Tel +46 222 44000 Օ +46 222 44099 Systemair 2003 Inhouse studio Օ Art no 8001 [email protected] www.systemair.com Օ [email protected] >

Open the catalog to page 4
