SUMMER 2011 Product Catalog

SUMMER 2011 Product Catalog

Product catalog summary

Overview: The Summer 2011 Product Catalog from SynQor provides a comprehensive overview of their power conversion solutions, including DC-DC converters, AC-DC power supplies, and EMI filters. These products are designed for applications in telecommunications, medical, industrial, and military/aerospace sectors.

DC-DC Converters:

Isolated DC-DC Converters: Offer ultra-high efficiency up to 97%, suitable for telecom and networking applications.
Non-Isolated DC-DC Converters: Feature efficiencies up to 95%, suitable for intermediate bus architectures.
Mil-COTS and Hi-Rel Converters: Designed for military and aerospace applications, providing high reliability and efficiency.

AC-DC Power Supplies:

Medical and Industrial-Grade: High efficiency up to 93%, with universal AC input voltage and safety features.

EMI Filters: Provide significant noise attenuation and system stabilization for DC-DC converters.

Product Features:

High efficiency and wide input voltage ranges.
Protection features include input under-voltage lockout, output current limit, and thermal shutdown.
Industry-standard pin-out configurations and footprints.

Applications: Designed for telecommunications, medical equipment, industrial systems, and military/aerospace environments, known for ruggedness and compliance with industry standards.

Conclusion: SynQor's catalog showcases their commitment to providing innovative power conversion solutions for modern electronic systems across various industries.

Product Specifications:

High efficiency up to 95%.
Input voltage ranges from 9V-160V and 180V-425V.
Output power up to 600W.
Fixed frequency switching with low output noise.
No minimum load requirement.

General Specifications:

Operating temperature range: -40ºC to +100ºC.
Output voltage set point accuracy: ±1.0%.
Output voltage ripple: <1% of Vout (typical).
Switching frequency: 240 - 350kHz, with some models at 450 - 550kHz.
Transient response: <7% of Vout (typical).
Isolation voltage up to 4250Vdc.

Mechanical Features:

Industry standard pin-out configurations.
Flanged baseplate available.
Standard footprints for different brick sizes.

Protection and Control:

Input under-voltage lockout.
Output current limit and short circuit protection.
Active back bias limit.
Output over-voltage protection.
Thermal shutdown.

Safety Standards:

Basic and reinforced insulation options.
Compliance with EN 60950-1, UL 60950-1, and CAN/CSA C22.2 NO. 60950-1 standards.
CE marked for certain models.

Product Family Matrix: Includes a matrix detailing various series of converters, their input voltage ranges, maximum power, and efficiency.

Medical Grade Converters: The CFQor series is highlighted for medical applications, offering high efficiency and compliance with IEC60601-1 standards.

Product Overview: Details SynQor's Mil-COTS and Hi-Rel series of isolated DC-DC converters for military and aerospace applications.

Operational Specifications: High efficiency up to 95%, with input voltage ranges from 9-425V, designed for harsh environments.

Mechanical Features: Industry-standard pin-out configurations and footprints, with options for flanged baseplates.

Control and Protection: Features include on/off control, remote sensing, output voltage trimming, and various protection mechanisms.

Manufacturing and Safety: AS9100 and ISO 9001:2000 certified manufacturing, with rigorous testing and safety standards compliance.

Product Family Matrix: Detailed matrix of product families, input ranges, transient capabilities, and efficiencies.

Screening and Qualification: Extensive screening and qualification processes, including compliance with military standards.

Design and Compliance: Hi-Rel series designed for reliability and compliance with military specifications.

Specifications and Procedures:

Element Evaluation: Includes visual inspection, temperature cycling, and acceleration tests.
Final Electrical Test: Conducted at multiple temperatures.
Packaging: Utilizes QorSeal for protection.

Product Features:

Hi-Rel Screening: QorSeal packaging offers conduction-cooled mechanical assembly.
Isolated DC-DC Converters: High efficiency up to 96%.
Non-Isolated DC-DC Converters: High efficiency up to 95%.

General Specifications:

Operating Temperature: -40ºC to +105ºC.
Output Voltage Ripple: Less than 1.5% of Vout.
Isolation Voltage: Up to 2250Vdc.

Protection and Control:

Input Under-Voltage Lockout (UVLO).
Output Current Limit (OCP).
Thermal Shutdown (OTP).

Mechanical and Safety:

Industry Standard Configurations.
Safety Certifications: UL, TUV, and CSA standards.

Product Family and Part Numbering:

BusQor and NiQor Series: Range of input and output voltages.
Part Numbering: Detailed system for identifying product specifications.

EMI Filters:

Operational Features: High differential and common-mode noise attenuation.
Product Options: Includes input surge suppression.
Mechanical Design: Standard form factors with flanged baseplate options.

Conclusion: SynQor offers a comprehensive range of high-efficiency DC-DC converters and EMI filters, designed for reliability and compliance with industry standards.

Product Features and Specifications: SynQor offers a range of EMI filters and power interface modules designed for high reliability and efficiency.

EMI Filters: Provide high differential-mode and common-mode attenuation, suitable for continuous and transient input voltages.

ATCA Modules: Feature transient protection, auxiliary supply voltages, and a standard quarter brick package size.

AC-DC Power Supplies: The ACuQor product line offers medical and industrial-grade AC-DC converters with high efficiency.

Mechanical and Safety Specifications: Products are available in various package sizes, with safety certifications ensuring compliance with international standards.

Conclusion: SynQor's products are designed for high performance and reliability in demanding applications.

Manufacturing and Production: SynQor operates its own production lines, ensuring high volume production and quality control.

Custom Power Solutions: Offers partnerships for custom DC-DC converter designs, with in-house engineers providing quick solutions.

Design & Engineering: Employs a five-stage product development process, emphasizing reliability and performance.

Quality & Reliability: Complies with RoHS and REACH directives, conducting extensive product qualification testing.

Company Overview: Founded in 1997, SynQor is a leader in high-efficiency DC-DC converters, expanding into various markets with innovative product lines.
