MADE IN USA Hi-Rel Products for the Military and Aerospace Industry Advancing the Power Curve®

±5V 05D ±12V 12D ±15V 15D MQFL-28 16-40Vin Cont. 16-50Vin 1s Trans. * Absolute Max Vin = 60V 24A/120W Total 10A/120W Total 8A/120W Total MQFL-28E 16-70Vin Cont. 16-80Vin 1s Trans. * Absolute Max Vin =100V 24A/120W Total 10A/120W Total 8A/120W Total MQFL-28V 16-40Vin Cont. 5.5-50Vin 1s Trans. * Absolute Max Vin = 60V 20A/100W Total 8A/96W Total 6.5A/98W Total MQFL-28VE 16-70Vin Cont. 5.5-80Vin 1s Trans. * Absolute Max Vin = 100V 20A/100W Total 8A/96W Total 6.5A/98W Total MQFL-270 155-400Vin Cont. 155-475Vin 0.1s Trans. * Absolute Max Vin = 550V 24A/120W Total 10A/120W Total 8A/120W Total ±5V...

PASSIVE FILTER CIRCUIT SCHEMATIC INPUT RETURN OUTPUT RETURN POSITIVE INPUT POSITIVE OUTPUT PINS 1, 2, 3 PINS 4, 5, 6 DAMPING PINS BULK 10, 11, 12 C PINS 7, 8, 9 R EMI filters are available with passive components only, or with additional active circuitry that provides surge/spikesuppression, soft start in-rush limiting, reverse-polarity protection, and enable signal passthrough. They also are available in standard and extended input voltage ranges. QorSeal TM Packaging Our unique QorSeal™ packaging approach provides a conduction-cooled mechanical assembly around an SMT constructed power...

Founded in 1997, SynQor® has become the technology, quality and service leader for high efficiency dc-dc converters for the telecom/datacom marketplace. The PowerQor®, BusQor®, DualQor®, iQor™, and NiQor® product lines, combined with SynQor’s unmatched lead-times, flexibility, design support and lowest total cost of ownership have become the benchmark sought by SynQor’s worldwide customer base. In 2004, SynQor began its successful entry into the military, medical and industrial market segments with the MilQor®, InQor® and ACuQor® product lines. These new technology leading dc-dc and ac-dc...
