Introducing Reliathon™ The next step for utility-scale solar

The secret to scaling solar is not simply building bigger power plant components. It’s redesigning and integrating best-of-breed industry components so they work better together. To accomplish this, Suntech developed a new utility-grade module, Reliathon, and brought together key solar industry tracker and inverter partners to support the new design. The result is an alternative to the patchwork approach to utility-scale solar. The smart new design of Suntech Reliathon modules combined with pre-negotiated preferential pricing on trackers and inverters help you save time and money by driving...

Reliathon No. 3 A simple request: Tell us what you need. When we began designing a next generation solution for the utility solar market, we first went to the experts: our customers. We spent time with dozens of utility-industry insiders, asking them how they would best optimize their project development. Their biggest request, of course, was to help them increase profitability. When customers suggested criteria for their ideal solution, we got to work. The result of this customercentric approach incorporates needs that utility industry stakeholders said were most important: system...

Reliathon Modules are Power Plant Optimized Fast-Installing U Bolts U bolts fasten each module to the frame, reducing the number of small parts and fasteners—and reducing installation time. Self-Aligning Frame Interlocking frames align new, thicker modules with the mounting structure or trackers. No more vertical stabilizers. Fewer parts, less labor, lower installation costs. Integrated Grounding A built-in plate automatically grounds the frame to the mounting structure, saving time and money. No more grounding lugs or connecting copper ground wire. The new Suntech Reliathon 270-watt module...

No. 5 “We've optimized our solar trackers specifically to support the new Reliathon platform that will help accelerate utility-scale solar plant deployments. By teaming with Suntech, and going to market with an integrated solution, we're helping answer the needs of customers with a system that simplifies the installation process, and is reliable and scalable for the utility market.” Ron Corio CEO Array Technologies Reliathon Meet Suntech Reliathon Partners Tracking leader Array Technologies designed its newest tracker specifically for Reliathon. Now with 50% fewer motors per megawatt, the...

table.main {} tr.row {} td.cell {} div.block {} div.paragraph {} .font0 { font:10.00pt "Franklin Gothic Medium", sans-serif; } .font1 { font:13.00pt "Franklin Gothic Medium", sans-serif; } .font2 { font:20.00pt "Franklin Gothic Medium", sans-serif; } .font3 { font:38.00pt "Franklin Gothic Medium", sans-serif; } Lower Up-front Cost with Technology and Contract Term Innovations Modules and components designed to work together make Rellathon Systems an estimated 10% tes* expensive to purchase and install than comparable'patchwork* solutions. Just as module innovations lead to fewer small parts...

Reliathon NNoo.. 77 Power Rating Maximum Voltage No. of Cells Normal Operating Cell Temperature Tolerance Weight Cables Dimensions 260, 265, 270 watts 1000 volts 72 45 ± 2°C -0W/+5W 28 kg (62 lbs.) MC Plug Type IV 1069 mm x 1988 mm x 65 mm (42.1 x 78.2 x 2.5 inches) Reliathon Module Characteristics

Suntech Power Holdings Co., Ltd. 71 Stevenson St.,10th Floor, San Francisco, California 94105 USA T +1 415 882 9922 F +1 415 882 9923 E Reliathon.USA@suntech-power.com EN-Reliathon-Rev 2009 © 2009 Suntech Power. All rights reserved. www.suntech-power.com/reliathon
