12.5W 5V 2A AC-DC Desktop Power Supply

Product catalog summary

Overview: The document provides technical specifications for the SPD-A60 Series Adapter Power Supply by Sunpower Technology Corp. It includes features, specifications, protection mechanisms, environmental conditions, safety standards, and packaging details.

Features: The power supply includes overload, overvoltage, and short circuit protection, a built-in EMI filter, low ripple noise, a long-life ball bearing fan, and an LED indicator. It meets EMI EN55022, EMS EN55024, and LVD standards and comes with a one-year warranty.

Specifications:

Input: Voltage range is AC 90V to 264V with a frequency of 47 to 63 Hz. Maximum current is 1.6A at 100V AC input under full load. Inrush current is less than 30A at 115V and less than 60A at 230V AC input.
Output: Various models offer different voltage outputs ranging from 5V to 48V with corresponding maximum loads and efficiencies. Ripple noise and overvoltage protection (OVP) values are specified for each model.
Protection: Overload protection activates at 105% to 150% of the rating, with auto-recovery after fault removal. Short circuit protection also includes auto-recovery.
Environmental Conditions: Operating temperature is 0 to 55℃ with de-rating above 40℃. Storage temperature ranges from -10 to +75℃. Humidity levels for operation and storage are specified.
Safety and Compliance: The product complies with UL, CSA, TUV, IEC, and CCC safety standards, as well as FCC and EN EMI standards.

Dimensions and Packaging: The adapter measures 59.5 x 119.5 x 36.5mm. It is packaged with 72 units per carton.

Additional Notes: The enclosure color is black, with an IEC 320 C14 standard AC inlet and a DC plug with specified dimensions.

Catalog excerpts

12.5W 5V 2A AC-DC Desktop Power Supply-1

Over load, over voltage & short circuit protection Built in EMI filter, low ripple noise Built-in long life ball bearing fan 100% 50 burn-in test. With LED indicator Meet EMI EN55022 EMS EN55024 LVD standard CE > Voltage AC 90V --- 264V, Universal full range. Frequency 47 ----- 63 Hz INPUT Leakage Current <1.5mA@264V AC input Current 1.6A max@100V AC input, full load condition Inrush Current <30A@115V / <60A@230V AC input, full load condition. Cold start at 25 ambient Model No. SPD-A60-05 SPD-A60-7.5 SPD-A60-09 SPD-A60-12 Voltage 5V 7.5V 9V 12V Min. Load 0A Max. Load 8.0A 6.0A 5.6A 5.0A Regulation 5% ѱ5% 5% ѱ3% Ripple Noise(MAX.) 70mV 90mV 100mV 120mV OVP 5.8V~7.0V 8.6V~10.5V 10.35V~12.6V 13.8V~17.5V Efficiency (MIN.) 70% 72% 74% 76% OUTPUT Max Power 60W 60W 60W 60W Max Power 40W 45W 50W 60W Model No. SPD-A60-15 SPD-A60-19 SPD-A60-24 SPD-A60-48 Voltage 15V 19V 24V 48V Min. Load 0A Max. Load 4.0A 3.2A 2.5A 1.3A Regulation 3% ѱ3% 3% ѱ3% Ripple Noise(MAX.) 150mV 200mV 200mV 400mV OVP 17.3V~21V 21.85V~26.6V 27.6V~33.6V 55.2V~67.2V Efficiency (MIN.) 76% 80% 80% 80% PROTECTION Over Load Protection Over 105% ~ 150% of rating, shutdown and auto-recovery when short circuit condition has removed. > Short Circuit Protection Shutdown and auto-recovery after fault condition has been removed. Rise time <20mS OTHERS Hold up time >20mS@230V Cooling Natural cooling Environment Temperature Operating: 0~55 ; De-rating: 40 ~55 : 2.5%/ . Storage: -10~+75 Humidity Operating: 20% ~ 85%; Storage: 10% ~ 95% (non condensing) M.T.B.F. 387K hours > rd rd st st SAFETY UL 60950 3 , CSA C22.2 No.60950 3 , TUV EN 60950-1 , IEC 60950-1 , EMKO-TSE (74-SEC)207/94, CCC GB 4943(2001) standard. EMC EMS EN 55024 EMI FCC CFR PART 15 CLASS B EN 55022 CLASS B EN 61000-3-2,3 CNS 13438 CLASS B EN 61000-4-2,3,4,5,6,8,11 PACKING N.W.: --kg/1pc; 72PCs/ 2.02 Cuft3/1ctn Specifications subject to change without notice. >

Open the catalog to page 1

12.5W 5V 2A AC-DC Desktop Power Supply-2

NOTE :1. ENCLOSURE COLOR : BLACK.2. AC INLET : IEC 320 C14 STANDARD.3. DC PLUG. ( I.D.=2.5mm ; O.D.=5.5mm )4. UNIT : mm. Specifications subject to change without notice. Sunpower (UK) Ltd, Orion House, Calleva Park, Aldermaston, Berkshire, RG7 8SNTel: +44 (0)118 981 1001 Fax: +44 (0)118 981 2002 E-mail: [email protected] >

Open the catalog to page 2
