streamtei<3>™ PRODUCT CATALOG At Streamtek Corp. we strive to provide our clients with superior customer service and the best quality in compressed air products. We find that building long-term customer relationships based on trust and high service standards will help us better address your needs and concerns.

Air Wipe Features • Uniform 360 degree airflow • Lightweight • Split, compact design - easy to install • Quiet • No moving parts • Air-driven - no electricity Air Wipe Applications Air Wipes Use Air Wipe to Clean, Blowoff, Dry, and Cool Cable, Pipe, Hose and Extruded Shapes. Streamtek's Air Wipes provide a laminar 360 degree airflow around circular objects. The unique split design makes it easy to clamp around surfaces. The Air Wipe is ideal for blow-off, cleaning, drying, and cooling of extruded shapes, hoses, pipes, cables, wires and more. Streamtek carries two types of Air Wipe models....

Air Wipe Applications The Model RB002A 2" Aluminum Air Wipe is used to blow excess water off extruded trim. The unique aluminum profile of the Air Wipe provided enough clearance for the trim, and enough airflow to evenly dry the trim and remove the water as it passed through the Air Wipe at high speeds. 360° Blow-Off (Extruded Profiles) The 3" Air Wipe System (Model No. RB003A) is used to blow-off excess water from an extruded plastic profile. The split design of our Air Wipe unlatches easily to eliminate tedious threading. The circular flow of air from the air wipe gives a forceful,...

Compressed Air Inlets: The Regular Air Wipe has (2) 1/4" NPTF compressed air inlets; one on each half. A general purpose PVC hose is supplied to distribute the compressed air to each side of the Air Wipe. For special order sizes 9" (229 mm) and above, each half must be supplied with it's own compressed air to ensure a uniform airflow. Mounting: There are multiple 1/4-20 tapped holes on the bottom of the Regular Air Wipe which can be used for mounting purposes. A rigid compressed air supply pipe can also support the Air Wipe! How can I mount the Air Wipe? There are two (2) ways you can mount...

Air Wipe Facts to know Easy to install, maintain, and allows for quick removal of a continuous piece. OSHA requirements for maximum noise and dead end pressure are met. Maintenance-free with the airflow easily controlled via pressure regulator. It is safe to use. Lowest Price in the industry! Find a competitors equivalent Air Wipe for less? Contact our factory and we will beat it by 20%. It's our standard policy. Specifications: Hi-Temperature Air Wipe What are the materials of construction? The Hi-Temp Stainless Steel Air Wipe features a stainless steel body, stainless steel shims,...

Drilled Pipe Air Consumption: Chart Hi-Temp Air Wipe Description Air Wipes Stainless Steel Unit Only - Up to 400°F (204°C) Pressure Regulators

We have over 15 years of experience in compressed air-o All our products are manufactured in-house. We pride ou costs low and eliminating the middle man in order to pass the our customers. We offer outstanding product quality. ex< service, and safe/secure business transactions. We are o. Friday from 900a m to 5 00pm Eastern Standard Time Our vision is to incorporate quality and effectiveness into our everyday production. We strongly stand behind our products from the moment they are produced to the moment they are taken out of use. All of our products come with an unmatched 6 year warranty...
