Air Knife
12Pages

streamtei<3>™ PRODUCT CATALOG At Streamtek Corp. we strive to provide our clients with superior customer service and the best quality in compressed air products. We find that building long-term customer relationships based on trust and high service standards will help us better address your needs and concerns.

Streamtek’s Air Knives are the latest innovation in reducing compressed air usage and noise levels for blowoff applications. Streamtek’s Air Knives are engineered to produce a uniform (laminar) sheet of air across its entire length with a hard-hitting force. They are made to be durable, robust, reliable and easily maintained among competitors who utilize aluminum or stainless steel. Streamtek Air Knives are ideal for superior quality cleaning, cooling, heating or decontaminating for any application. What types of Air Knives do we carry? The Regular Air Knife provides good performance with a...

Air Knives Air Knife Applications Industrial Blow-off Blow-Off Bottling Application • Cleans circuit board holes, flat sheet rubber and plastic molds. • Blows off liquid, chemicals, dirt, chips, and water prior to labeling or packaging. • Removes water, coolant, dust, and scrap in parts manufacturing and assembly operations. • Control and removal of paper dust Blow-Off Car Bodies Two (2) Model AE12SDS-1 Stainless Steel (Type 303) Regular Air Knives are used to blow-off liquid from one liter soda bottles. The elimination of the water on the bottle allows the labels to properly adhere. Before...

Streamtek's Regular Air Knife offers a more efficient and eco-friendly way to provide superior quality cleaning, drying, cooling, heating and decontaminating for any application. The Regular Air Knife produces an even laminar flow of air that turns 90 degrees through its entire length at an amplification ratio of 30:1 and air consumption of ~3.4 SCFM per inch at 80 PSIG. Our Air Knives are made from Aluminum or Stainless Steel material. How Does the Regular Air Knife Work? (A) Compressed air flows through an inlet at the end of a port and into a plenum or housing chamber in an Air...

Regular Air Knife Dimensions - Mounting is quick n' easy! Many Air Knife designs require dismantling. This reduces effectiveness and affects the airflow, and also makes them difficult to mount. Our Air Knives mount easily and the process does not affect the airflow. Flexibility air inlet(s). All Streamtek Air Knives incorporate compressed air inlets at each end and on the back for flexible choice of air input. (Stamless Steen

Aluminum: Unit Only Regular Air Knife /w pre-installed .002" Stainless Steel Shim Air Knife FAQs 1. Will the Air Knife operate with a blower? No. The Air Knife is designed to use only compressed air. Blowers are very noisy, large, and expensive with 3" to 6" connections. They simply will not produce enough force to operate our Air Knife. 2. Can I cut the Air Knife to a custom lenght? No. The Air Knife is precision-machined, cutting it would expose the internal design with no way to reseal the air knife. With that said, custom sizes can be machined upon special request. 3. Which way does the...

Stainless Steel: Unit Only Regular Air Knife /w pre-installed .002" Stainless Steel Shim What temperatures can your Air Knives withstand? Aluminum Air Knife: 275°F (1350C) Stainless steel (Type 303) Air Knife: 400°F (204°C) Stainless steel (Type 316) Air Knife: 800°F (427°C) Our team of professionals is always happy to answer any of your questions: + 1-705-7704455 or email support@stream-tek.com. * Temperatures that exceed 800°F (427°C) could produce intergranular corrosion which could eventually plug the air gap opening.

The Advanced Air Knife is an eco-friendly and energy efficient way to clean, cool and dry applications. Without using any electricity or any moving parts, the Advanced Air Knife produces a high velocity, high flow laminar sheet of air by using only a small amount of compressed air as its power source. The Advanced Air Knife provides an amplification ratio of 40:1 and air consumption of 2.9 SCFM per inch at 80 PSIG. How Does the Advanced Air Knife Work? (A) Compressed air flows through an inlet at the end of a port and into a plenum or housing chamber in an Air Knife. (B) From the plenum...

Air Knives Advanced Air Knife Performance Graphs Use the performance graphs below to better understand our advanced air knives pressure and velocity performance. If you have any questions please call our factory at 1-705-770-4455 or email support@stream-tek.com. Filter Separators remove water, dirt and rust from your compressed air system. They will prevent contaminants from damaging or plugging up your compressed air-operated products. Oil Removal Filters remove oil particulate that is commonly found in many compressed air systems. To trap submicron particles, a .03 micron element is used.

The drilled pipe is a common low-cost simple solution for blow-off needs. The chart below shows that the drilled pipe consumes almost twice the amount of air per SCFM and performs at a much lower rate in the amount of pressure supplied (PSIG). When you compare the performance of the Advanced Air Knife with the higher air consumption and energy use of the drilled pipe, the Advanced Air Knife comes out ahead. The drilled pipe runs into issues that include the potential for high noise levels, blockage, and velocity inconsistencies across the entire pipe. Over time, the drilled pipe would have...

Our knowledgeable customer service representatives offer application engineering support, and with manufacturing facilities in Canada and USA, as well as a distribution network encompassing Canada, USA, and Europe, Streamtek has the resources and tools to make your next project a success. Give us a call!

We have over 15 years of experience in compressed air-o All our products are manufactured in-house. We pride ou costs low and eliminating the middle man in order to pass the our customers. We offer outstanding product quality. ex< service, and safe/secure business transactions. We are o. Friday from 900a m to 5 00pm Eastern Standard Time Our vision is to incorporate quality and effectiveness into our everyday production. We strongly stand behind our products from the moment they are produced to the moment they are taken out of use. All of our products come with an unmatched 6 year warranty...
