NEATSwitch

Product catalog summary

Overview: The document provides detailed information on NEATSwitch, a range of miniature analog, digital, and power switches by STMicroelectronics. These switches are designed for various applications including LAN, HDMI, DVI, and mobile devices, offering features like low on-resistance, high bandwidth, and compact packaging.

Digital Switches: NEATSwitch digital switches are ideal replacements for mechanical relays in LAN applications, offering low on-resistance and wide bandwidth. Key products include:

B5S16281/B5S162861: 20-bit 2-port bus switch with low on-resistance of 5Ω and operating voltage of 4.0 to 5.5V.
STMUX1000L: Gigabit LAN switch with high bandwidth and low crosstalk, suitable for desktop and notebook applications.
STHDMI001A: HDMI/DVI digital switch with high bandwidth and low crosstalk, designed for video applications.

Analog Switches: These switches are optimized for mobile applications, offering low resistance and high bandwidth in compact packages. Notable products include:

STG3157: Low-voltage single SPDT switch with high speed and low power dissipation.
STG3684/3684A: Low-voltage dual SPDT switch with high speed and low power dissipation, available in various compact packages.

Power Switches: NEATSwitch power switches are designed for applications requiring power protection, featuring low on-resistance and efficient power management. Key products include:

ST890B/C: Single channel power switch with adjustable on-resistance.
STMPS2242/STMPS2252: Dual channel power switch with reversed current blocking.

Key Features: NEATSwitch products are characterized by:

Nano Speed: High-performance switches leveraging advanced HCMOS technology.
Efficient Power: Low RDS(on) and low Icc for reduced power dissipation.
Application Specific: Optimized for specific applications like mobile phones, video, LAN, HDMI, and DVI.
Tiny Package: Space-optimized surface mount device packages, leading in compact design.

Applications: NEATSwitch products are suitable for digital consumer electronics (DTV, STB, DVD-R), notebooks, PCs, mobile phones, and various switch applications (power, digital, analog).
